Main Image
MASFP1GBTXST
Gb RJ45 Copper SFP - MA-SFP-1GB-TX Compatible
10/100/1000 Mbps | Copper | RJ45 | 100 m (328 ft) | Lifetime Warranty
Main Image
Product Images
Product Images
Product Name Gb RJ45 Copper SFP - MA-SFP-1GB-TX Compatible Product Number MASFP1GBTXST UPC 065030869461 Lifecycle status Active Warranty Lifetime Taxonomy Product > Networking > SFP Transceivers Category Level 1 Networking Category Level 2 SFP Transceivers Category Level 3 Cisco Compatible Family Cisco Meraki Compatible - 1G SFP Modules - Copper Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX091X Product Title (Ultra-Short) MA-SFP-1GB-TX SFP Product Title (Short) Cisco Meraki MA-SFP-1GB-TX Comp. SFP Product Title (Medium) Cisco Meraki MA-SFP-1GB-TX Compatible SFP Copper Module -10/100/1000BASE-TX - Product Title (Standard) Cisco Meraki MA-SFP-1GB-TX Compatible SFP Module - 1000BASE-T - 10/100/1000 Mbps SFP to RJ45 Cat6/Cat5e Transceiver - 100m Product Title (Long) Cisco Meraki MA-SFP-1GB-TX Compatible SFP Module - 1000BASE-T - SFP to RJ45 Cat6/Cat5e - 10/100/1000 Mbps - RJ-45 100m - Cisco Meraki MS225, MX400, MS250 Product Title (AMZ) Cisco Meraki MA-SFP-1GB-TX Compatible SFP Module - 1000BASE-T - SFP to RJ45 Cat6/Cat5e - 10/100/1000 Mbps - RJ-45 100m - Cisco Meraki MS225, MX400, MS250 (MASFP1GBTXST) Title Ingram (Part 1) Cisco Meraki MA-SFP-1GB-TX Title Ingram (Part 2) Comp -Copper SFP Module - Website Product Headline 10/100/1000 Mbps | Copper | RJ45 | 100 m (328 ft) | Lifetime Warranty Bullet 1 100% CISCO MERAKI MA-SFP-1GB-TX COMPATIBLE: Works with Cisco Meraki switches like MS225, MX400, MS250, MS350, MX84 and others Bullet 2 TECHNICAL SPECS: 1000BASE-T | 1 Gbps | Copper | RJ-45 Connector | Distances up to 100m (328ft) Bullet 3 TESTED FOR OEM HOST COMPATIBILITY: Hot-swappable in Cisco routers and switches Bullet 4 THE IT PRO’S CHOICE: Designed and built for IT Professionals, this SFP module is backed for life (lifetime of module, not network switch), including free lifetime 24/5 multi-lingual technical assistance. Bullet 5 WORKS WITH MSA COMPLIANT SWITCHES: Also works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules Bullets (Compact) Cisco Meraki MA-SFP-1GB-TX Compatible SFP - 1000BASE-T 1 Gbps - 1GbE Module - 10/100/1000 Mbps Copper Transceiver - 100m (328ft) - RJ-45 Connector - Hot-Swappable & MSA Compliant - Lifetime Warranty Bullets (Consolidated) Cisco Meraki MA-SFP-1GB-TX Compatible SFP 1000BASE-T (1 Gbps) Gigabit Ethernet - Copper - Up to 100m (328') - RJ-45 Connector - For Cisco Meraki switches like: MS225 MX400 MS250 MS350 MX84 MX600 MX450 MS425 - Hot-Swappable and MSA Compliant - Backed by a StarTech.com lifetime warranty on the module itself not the life of the OEM switch/router and will not void your OEM warranty Marketing Copy Marketing Copy (No HTML) Applications - Replacing defective or damaged SFP modules in Cisco Meraki switches and routers
- Expand your network to remote segments
Website Search Keyword - Cisco Meraki MA-SFP-1GB-TX Compatible SFP
- 1000Base-T SFP
- MA-SFP-1GB-TXCompatible SFP
- Cisco Meraki MA-SFP-1GB-TX
- 1000Base
- Cisco Meraki
- Cisco compatible SFP
- SFP Module
- GBIC Module
- MSA
- MA-SFP-1GB-TX compatible SFP
- RJ45 copper SFP
- RJ45 GbE SFP
- Gigabit copper SFP
- 1000Base-TX SFP
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- UL Recognized - Safety - Electrical - Canada / United States - cURus Recognised Component Mark
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- CE - Safety - Electrical - European Union - Low Voltage Directive (LVD) 2014/35/EU
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
System and Cable Requirements - MSA or Cisco Meraki compliant SFP port
- For use in 1 Gigabit networking equipment and media converters
Accessory Products - N6PATCH10BL
- N6PATCH25BL
- N6PATCH50BL
- N6PATCH100BL
- PEX1000SFP2
- IES101002SFP
- IES101GP2SFW
- IES101G2SFPW
- MCM1110SFP
Input Voltage 3.3V DC Output Voltage (V) 3.3V DC Power Consumption (In Watts) < 1.3 W Color Silver Humidity 5~95% RH Material Aluminum Operating Temperature 0°C to 70°C (32°F to 158°F) Primary Material Aluminum Product Length (mm) 68.000 Product Width (mm) 18.000 Product Height (mm) 13.800 Product Weight (g) 21.000 Storage Temperature -40°C to 85°C (-40°F to 185°F) TAA Compliant No Auto MDIX Yes Compatible Networks 10/100/1000 Mbps Digital Diagnostics Monitoring Support No Fiber Operating Mode Full-Duplex Fiber Type Copper Maximum Data Transfer Rate 1000 Mbps Max Transfer Distance 100m [328ft] MTBF (hours) 4,655,371 hours Fiber Connector RJ-45 Industry Standards - IEEE 802.3u 100BASE-TX
- IEEE 802.3ab 1000BASE-T
- IEEE 802.3i 10BASE-T
OEM Part Number MA-SFP-1GB-TX SFP Compatible Brand Cisco Meraki Carton Depth (mm) 349 Carton Height (mm) 358 Carton Quantity 120 Carton Weight Gross (g) 6738 Included in Package 1 - SFP transceiver Package Depth (mm) 93 Package Height (mm) 33 Package Width (mm) 114 Package Quantity 1 Package Weight (g) 50 Packaging Description Gb Copper SFP - MA-SFP-1GB-TX Compatible - RJ45 Packaging Description India Gb Copper SFP - MA-SFP-1GB-TX Compatible - RJ45 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Host Connector 1 RJ-45 Host Connector 1 (Quantity) 1 Host Connector 2 RJ-45 Host Connector 2 (Quantity) 1 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2016-12-06 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute No Buying Center - Networking & Edge Yes Digital Content Due Date 2016-12-23 Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level - 1 Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,DE,DK,ES,EU,FR,IE,IN,IT,JP,MX,NL,NZ,SE,SG,UK,US Primary Technology None Product Development Specialist Ray Aoki Product Information Creation Specialist (PICS) Alex Garcia Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Target Development Completion Date 2016-12-09 Target Production Release 2016-12-09 Tech Lead Stefan Tirolese Technical Writer Andrew Richardson Technology Lifecycle None
