MCM110SC2GB
Fiber Media Converter Multi Mode - RJ45 to SC 2 km
Convert and extend a 10/100 Mbps Ethernet connection up to 2 km over Multi Mode SC fiber
Main Image
Product Images
Product Images
Product Images
BOM Image
Product Name Fiber Media Converter Multi Mode - RJ45 to SC 2 km Product Number MCM110SC2GB UPC 065030836524 Lifecycle status Active Warranty 2 Years Taxonomy Product > Networking > Ethernet Media Converters Category Level 1 Networking Category Level 2 Ethernet Media Converters Category Level 3 Multi Mode Family Media Converters - MCM Series Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Product Title (Short) Ethernet to Fiber Media Converter SC Product Title (Standard) 10/100 Ethernet to Multi Mode Fiber Media Converter SC 2 km, TAA Product Title (Long) 10/100 Ethernet to Multi Mode Fiber Media Converter SC 2 km - TAA Title Ingram (Part 1) 10/100 Ethernet to Multi Mode Fi Title Ingram (Part 2) ber Media Converter SC 2km Website Product Headline Convert and extend a 10/100 Mbps Ethernet connection up to 2 km over Multi Mode SC fiber Bullet 1 Supports a maximum multi mode fiber optic cable distance of 2 km Bullet 2 Compatible with most 3COM™, Cisco™, Lucent™ and Nortel™ networks Bullet 3 Supports transparent Q-in-Q double tagged frames Bullet 4 Supports Link Fault Pass through (LFP) Bullet 5 Supports IEEE 802.1q Tag VLAN pass thru Marketing Copy Applications - Extend your Ethernet connection up to 2km away using fiber optics
- Designed for large, higher speed bandwidth that has a demanding work groups that require expansion of fast Ethernet Network
- Connect via fiber optics two or more building on the same campus
- Connect remote sub-networks to larger fiber optic networks/backbones
Website Search Keyword - transparent link
- Ethernet fiber extender
- Fiber Optic transmitter
- Long distance ethernet
- Media Converter
- multi mode fiber
- Mutimode fiber converter
- RJ45 to SC
Required Regulatory Compliance Marks - CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- UKCA - Environmental - United Kingdom - UK Restriction of Hazardous Substances (RoHS) 2012
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- TSCA - Environmental - United States - EPA TSCA Title VI Compliant
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- Triman/Info-Tri - Manual - Waste - European Union - Print Paper
- Triman/Info-Tri - Product - Waste - European Union - EEE Device + accessories
- Triman/Info-Tri - Packaging - Waste - European Union - Paper Box + plastic bag + Paper/foam divider/tray
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
- FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
Accessory Products - 50FIBSCSC10
- FIBSCSC10
- FIBSCSC15
- M45PATCH10BL
- M45PATCH15BL
- M45PATCH25BL
- M45PATCH6BL
- SVA12M2NEUA
- SVA12M5NA
Related Products - 110VDSLEXTGB
- ET1000MMSMGB
- ET90110SCGB
- ET90110STGB
- MCM110ST2GB
Input Voltage 100 - 240 AC Output Current 0.2A Output Voltage (V) 12V DC Power Consumption (In Watts) 2.4 Power Source AC Adapter Included Plug Type M Center Tip Polarity Positive Color Black Humidity 10~90% RH Operating Temperature 0°C to 50°C (32°F to 122°F) Product Length (mm) 95 Product Width (mm) 75 Product Height (mm) 20 Product Weight (g) 90.5 Storage Temperature -10°C to 70°C (14°F to 158°F) TAA Compliant Yes Fiber Operating Mode Half/Full-Duplex Fiber Type Multi Mode Maximum Data Transfer Rate 10/100Mbps Max Transfer Distance 2 km (1.2 mi) MTBF (hours) 65,000 Hours Wavelength 1310nm Fiber Connector SC Industry Standards - IEEE 802.3 10BASE-T
- IEEE 802.3u 100BASE-FX
- IEEE 802.3u 100BASE-TX
LED Indicators - 1 - Ethernet Link & Activity (ON - Fiber Link ok, Blinking - Activity on Fiber Link)
- 1 - FEF [Far End Fault](On - Fault Detected, Off - No Fault
- 1 - Fiber Link & Activity (On - Fiber Link ok, Blinking - Activity on Fiber Link)
- 1 - Full ( Full duplex / Half duplex)
- 1 - Power
- 1 - Speed (10 or 100 Mbps)
Power over Ethernet No Wave Division Multiplexing (WDM) No Carton Depth (mm) 390 Carton Height (mm) 300 Carton Quantity 1 Carton Weight Gross (g) 8000 Included in Package - 1 - Media Converter
- 1 - Power Adapter
- 1 - User's Manual
- 1 - EU power plug
- 1 - UK power plug
Package Depth (mm) 145 Package Height (mm) 65 Package Width (mm) 175 Package Quantity 1 Package Weight (g) 280 Packaging Description 10/100 Mbps Ethernet to SC Fiber Converter 2km Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 SC Duplex Fiber Connector 1 (Quantity) 1 Host Connector 1 RJ-45 Host Connector 1 (Quantity) 1 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2014-06-18 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute No Buying Center - Networking & Edge No Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) EU,IE,NL,UK Primary Technology None Product Development Specialist Ray Aoki Product Information Creation Specialist (PICS) Alex Garcia Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Tech Lead Stefan Tirolese Technical Writer Andrew Richardson Technology Lifecycle None
