Main Image
MDP2DPDVHD
Mini DisplayPort to DisplayPort DVI HDMI
Connect your mini DisplayPort® Device to a DisplayPort®, HDMI®or DVI Display, with this Compact, All-in-One Adapter
Main Image
Product Images
Product Images
Product Images
Product Images
Quick-Start Guide
Product Name Mini DisplayPort to DisplayPort DVI HDMI Product Number MDP2DPDVHD UPC 065030844338 Lifecycle status Active Warranty 3 Years Taxonomy Product > Docks, Hubs & Video Adapters > Video Adapters Category Level 1 Display and Video Adapters Category Level 2 DP and MDP Display Adapters Category Level 3 DP and MDP Travel Adapters Family mDP to Multiport Display Adapters, 2560 x 1600 Country of Origin Europe & Japan Vietnam Country of Origin North America Vietnam Country of Origin History (1) Vietnam Country of Origin Revision (1) XXXXXX190X Product Title (Short) Mini DisplayPort to DP DVI HDMI Adapter Product Title (Medium) x Product Title (Standard) Travel A/V adapter - 3-in-1 Mini DisplayPort to DisplayPort DVI or HDMI converter Product Title (Long) Travel A/V adapter: 3-in-1 Mini DisplayPort to DisplayPort DVI or HDMI converter Product Title (AMZ) Travel A/V adapter - 3-in-1 Mini DisplayPort to DisplayPort DVI or HDMI converter (MDP2DPDVHD) Title Ingram (Part 1) Mini DisplayPort to DisplayPort Title Ingram (Part 2) DVI or HDMI Multifunction Adapter Website Product Headline Connect your mini DisplayPort® Device to a DisplayPort®, HDMI®or DVI Display, with this Compact, All-in-One Adapter Bullet 1 Adapt Mini DisplayPort to DisplayPort, HDMI or DVI Bullet 2 Compact design Bullet 3 Supports resolutions up to 2560x1600 using DisplayPort, 1920x1200 using HDMI/DVI Bullet 4 No software/drivers required Bullet 5 Compatible with Intel® Thunderbolt™ Bullets (Consolidated) Connect your mini DisplayPort Device to a DisplayPort, HDMIor DVI Display, with this Compact, All-in-One Adapter - Compatible with mDP enabled computer systems such as MacBook Air/Pro and any Surface Pro device with mDP - Mini DisplayPort Converter/Mini DisplayPort Adapter/mini DisplayPort to DP/DVI/HDMI - Connect your computer to almost any Display Marketing Copy Marketing Copy (No HTML) Applications - Ideal for digital entertainment centers, home offices, business conference rooms and trade show displays
- Use your existing DVI, HDMI® or DisplayPort® monitors with a new mini DisplayPort® device
- Perfect for IT professionals seeking a solution for connecting mixed display hardware to mini DisplayPort computers
Website Search Keyword - Mini DisplayPort to DVI
- MDP to DVI
- Mini DisplayPort to HDMI
- MDP to HDMI
- Mini DisplayPort converter
- MDP converter
- MDP to DP
- MDP Adapter
- Mini DisplayPort adapter
- light peak
- light peek
- thunder bolt
- thunderbolt
- P137-06N-HDV
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
Accessory Products - DISPLPORT1L
- DISPLPORT3L
- DISPLPORT6L
- DISPLPORT10L
- DISPLPORT15L
- DVIDDMM1
- DVIDDMM3
- DVIDDMM6
- DVIDDMM10
- DVIDDMM15
- HDMM1
- HDMM3
- HDMM6
- HDMM8
- HDMM10
- HDMM12
- HDMM15
Related Products - MDPVGDVHD4K
- MDP2HDVGA
- MDP2HDVGAW
- MDP2VGDVHDW
- DP2VGDVHD
- DP2HDVGA
Cable Length (mm) 150 Color Black Humidity 10%-85%RH Material Plastic Operating Temperature 0°C to 45°C (32°F to 113°F) Primary Material Plastic Product Length (mm) 253.800 Product Width (mm) 44.000 Product Height (mm) 15.100 Product Weight (g) 49.000 Storage Temperature -10°C to 70°C (14°F to 158°F) TAA Compliant No Audio Specifications - DisplayPort - 5.1 Channel Audio
- HDMI - 7.1 Channel Audio
- DVI - No Audio Support
HDR Support No Maximum Cable Distance To Display 15200 Maximum Digital Resolutions Maximum Supported Resolution 1080p Video Output Port - DisplayPort
- DVI
- HDMI
Active or Passive Adapter Passive Audio Yes AV Input Mini DisplayPort - 1.2 AV Output - HDMI - 1.4
- DVI-D - Single-Link
- DisplayPort - 1.2
Converter Type Travel A/V Adapters Host Connection Port Mini DisplayPort Number of Displays 1 Amount of recycled material in plastic packaging At Least 30% Carton Depth (mm) 330 Carton Height (mm) 220 Carton Quantity 100 Carton Weight Gross (g) 6592 Included in Package 1 - MDP to DP/DVI/HDMI Adapter Included In Package for Label 1 - Mdp To Dp/DVI/HDMI Converter Number of Sub-Cartons 10 Package Depth (mm) 130 Package Height (mm) 30 Package Width (mm) 129 Package Quantity 1 Package Weight (g) 56 Packaging Description Mini DisplayPort to DisplayPort DVI HDMI® Packaging Description India Mini DisplayPort to DisplayPort DVI HDMI® Sub-Carton Depth (mm) 256 Sub-Carton Height (mm) 74 Sub-Carton Width (mm) 328 Sub-Carton Quantity 10 Sub-Carton Weight (g) 588 Connector 1 Mini DisplayPort Connector 1 (Quantity) 1 Connector 2 DisplayPort Connector 2 (Quantity) 1 Connector 3 HDMI Connector 3 (Quantity) 1 Connector 4 DVI-D Dual-Link (25-Pin) Connector 4 (Quantity) 1 Amazon Merchandising Manager Kristian Haighton Artwork Due Date 2014-06-18 Buying Center - AV & Collaboration Yes Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge No Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,CO,DE,DK,ES,EU,FI,FR,HK,IE,IN,IT,JP,MX,NL,NZ,PE,SE,SG,UK,US Primary Technology None Product Development Specialist Abhinav Pathak Product Information Creation Specialist (PICS) Dan Dagenais Product Manager David Muzinic Product Performance Specialist John Mardinly Product Photographer Caleigh Le Grand Tech Lead Brian Linseman Technical Writer Dan Dagenais Technology Lifecycle Mainstream
