MDP2DVIMM6B
6ft Mini DisplayPort to DVI Adapter - MDP to DVI
Connect a DVI display to a Mini DisplayPort-equipped PC or MAC® over a 6 foot distance – Black
Main Image
Product Images
Product Images
Product Images
Product Images
Product Name 6ft Mini DisplayPort to DVI Adapter - MDP to DVI Product Number MDP2DVIMM6B UPC 065030851466 Lifecycle status Active Warranty 3 Years Taxonomy Product > Docks, Hubs & Video Adapters > Video Adapters Category Level 1 Display and Video Adapters Category Level 2 DP and MDP Display Adapters Category Level 3 MDP to DVI Family mDP to DVI Adapter Cables Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX028X Country of Origin History (2) Vietnam Country of Origin Revision (2) XXXXXX132X Product Title (Ultra-Short) 6ft Mini DP to DVI Product Title (Short) 6ft Mini DisplayPort to DVI Cable, DVI-D Product Title (Medium) x Product Title (Standard) 6ft Mini DisplayPort to DVI Cable, Mini DP to DVI-D Adapter/Converter Cable, 1080p Video, mDP 1.2 to DVI Monitor/Display Product Title (Long) 6ft (1.8m) Mini DisplayPort to DVI Cable - Mini DP to DVI Adapter Cable - 1080p Video - Passive mDP 1.2 to DVI-D Single Link - mDP or Thunderbolt 1/2 Mac/PC to DVI Monitor Product Title (AMZ) 6ft (1.8m) Mini DisplayPort to DVI Cable - Mini DP to DVI Adapter Cable - 1080p Video - Passive mDP 1.2 to DVI-D Single Link - mDP or Thunderbolt 1/2 Mac/PC to DVI Monitor (MDP2DVIMM6B) Title Ingram (Part 1) 6 ft Mini DisplayPort to DVI Title Ingram (Part 2) Adapter - Mini DP to DVI - Black Website Product Headline Connect a DVI display to a Mini DisplayPort-equipped PC or MAC® over a 6 foot distance – Black Bullet 1 MINI DISPLAYPORT TO DVI CABLE: 6ft (1.8m) Mini DisplayPort 1.2 (HBR2) to DVI-D (digital only) single-link cable connects a DVI display | 1080p 60Hz or 4K 30Hz (monitor w/ HDMI clock rate); EDID pass-through ensures compatibility between source & display Bullet 2 HOST COMPATIBILITY: Passive video converter supports mDP++ source including Thunderbolt 1 & 2 MacBooks, MacBook Air & Mac Mini, Microsoft Surface Pro 1-6, desktops (AMD FirePro/NVidia Quadro), laptops, mini itx computers, Intel NUC & docks Bullet 3 INTEGRATED DISPLAY CABLE: Mini DisplayPort to DVI adapter cable has slim & flexible design with adapter chip built into VGA connector reducing clutter & providing a tidy install in the office, boardroom or home office Bullet 4 INCREASE PRODUCTIVITY: Connect a DVI monitor or projector, or add a second display to your workstation using the mDP to VGA display adapter cable | Supports DVI screw locking cable to prevent accidental disconnection | mDP male to DVI male Bullet 5 EASY TO USE: With no software or drivers required, the Mini DP to DVI converter cable/cord works with any OS including Windows, Ubuntu and macOS; Compatible with MiniDP devices like TB1/TB2 MacBooks with Mini DisplayPort Bullets (Compact) 6ft Passive Mini DP to DVI-D single-link cable 1080p 60Hz; mDP 1.2 HBR2; EDID - Mini DisplayPort to DVI cable converter connects mDP++ source to DVI monitor/display - Video adapter cable prevents signal loss - Works w/Thunderbolt 1/2 - OS independent Bullets (Consolidated) 6ft Mini DisplayPort to DVI-D (digital) single-link adapter cable connects a DVI display/projector/monitor | 1080p 60Hz or 4K 30Hz (monitors w/HDMI clock-rate) | EDID - Passive mDP to DVI converter cable supports Mini DisplayPort 1.2 equipped PC or Mac incl Thunderbolt 1/2 MacBook Pro/Air/Mac Mini | Workstations | Desktop Computers (AMD/Nvidia video cards) | Laptops | Docks -Integrated video adapter prevents signal loss - Mini DP to DVI cable supports DVI screw locking cord - OS independent Marketing Copy Marketing Copy (No HTML) Applications - Ideal for using your DVI monitor as a secondary display
- Connect your existing DVI display device (monitor, projector) to a Mini DisplayPort output device
Website Search Keyword - DisplayPort to DVI Adapter
- Mini DisplayPort to DVI
- Mini DisplayPort DVI Adapter
- DisplayPort to DVI
- Apple DisplayPort
- Apple Mini DisplayPort
- Mac Mini DisplayPort
- Macbook Mini DisplayPort
- mac
- apple
- Light Peak
- Light Peek
- Thunder Bolt
- P586-006-DVI-V2
- P586-006-DVI
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- Triman/Info-Tri - Manual - Waste - European Union - Print Paper
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
- UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
- Triman/Info-Tri - Packaging - Waste - European Union - Plastic Bag
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
System and Cable Requirements DP++ (DisplayPort++) port required from video card or video source for DVI and HDMI® signal pass-through Related Products - MDP2DVIMM3B
- MDP2DVIMM10B
- MDP2DVIS
- MDP2DVI3
- MDP2DVIW
- MDP2DVI
- MDP2DVID
- MDP2DVIMM6
- MDP2DVIMM3BS
- MDP2DVIMM6BS
- MDP2DVIMM10W
- MDP2DVIMM6WS
- MDP2DVIMM6W
- MDP2DVIMM3W
- MDP2DVIMM3WS
- MDPHDDVIKIT
Constrained SKU Alternatives (Limited Stock) MDP2DVIMM6 Cable Length (mm) 1828.8 Color Black Humidity 40%-85%RH Operating Temperature 0°C to 60°C (32°F to 140°F) Primary Material Plastic Product Length (mm) 1830 Product Width (mm) 40 Product Height (mm) 15 Product Weight (g) 106 Storage Temperature -10°C to 70°C (14°F to 158°F) TAA Compliant No Audio Specifications DVI - No Audio Support HDR Support No Maximum Cable Length (mm) 1828.8 Maximum Digital Resolutions 1920x1200 / 1080p Maximum Supported Resolution 1080p MTBF (hours) 2,405,577 hours Video Output Port DVI Wide Screen Supported Yes Active or Passive Adapter Passive Audio No AV Input Mini DisplayPort - 1.2 AV Output DVI-D - Single-Link Chipset ID NXP - 3361 Converter Type Cable Adapters Host Connection Port Mini DisplayPort Number of Displays 1 Amount of recycled material in plastic packaging At Least 30% Carton Depth (mm) 456 Carton Height (mm) 424 Carton Quantity 150 Carton Weight Gross (g) 18542 Included in Package 1 - Mini DisplayPort® to DVI Adapter Included In Package for Label 1 - Mini Displayport® To DVI Converter Number of Sub-Cartons 15 Package Depth (mm) 199 Package Height (mm) 24 Package Width (mm) 161 Package Quantity 1 Package Weight (g) 110 Packaging Description 6ft (1.8m) Mini DisplayPort to DVI Adapter Packaging Description India 6ft (1.8m) Mini DisplayPort to DVI Converter Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Quantity 10 Sub-Carton Weight (g) 0 Connector 1 Mini DisplayPort Connector 1 (Quantity) 1 Connector 2 DVI-D Dual-Link (25-Pin) Connector 2 (Quantity) 1 Amazon Merchandising Manager Kristian Haighton Artwork Due Date 2013-05-07 Buying Center - AV & Collaboration Yes Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge No Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,DE,DK,ES,EU,FI,FR,HK,IE,IN,IT,JP,NL,NZ,SE,SG,UK,US Primary Technology None Product Development Specialist Abhinav Pathak Product Information Creation Specialist (PICS) Dan Dagenais Product Manager David Muzinic Product Performance Specialist John Mardinly Product Photographer Caleigh Le Grand Tech Lead Brian Linseman Technical Writer Dan Dagenais Technology Lifecycle Legacy
