Main Image
MDP2HDMI
Mini DisplayPort to HDMI Video Converter
Connect an HDMI® enabled display to a Mini DisplayPort® equipped PC or MAC
Main Image
Product Images
Product Name Mini DisplayPort to HDMI Video Converter Product Number MDP2HDMI UPC 065030836906 Lifecycle status Active Warranty 3 Years Taxonomy Product > Docks, Hubs & Video Adapters > Video Adapters Category Level 1 Display and Video Adapters Category Level 2 DP and MDP Display Adapters Category Level 3 MDP to HDMI Family mDP to HDMI 1.3 Adapters Country of Origin Europe & Japan Vietnam Country of Origin North America Vietnam Country of Origin History (1) Vietnam Country of Origin Revision (1) XXXXXX190X Product Title (Short) Mini DisplayPort to HDMI Adapter - 1080p Product Title (Medium) x Product Title (Standard) Mini DisplayPort to HDMI Adapter, Mini DP to HDMI Video Converter for Monitor/Display, 1080p, Passive mDP 1.2 to HDMI Adapter Product Title (Long) Mini DisplayPort to HDMI Adapter - mDP to HDMI Video Converter - 1080p - Mini DP or Thunderbolt 1/2 Mac/PC to HDMI Monitor/Display/TV - Passive mDP 1.2 to HDMI Adapter Dongle - Upgraded Version is MDP2HDEC Product Title (AMZ) Mini DisplayPort to HDMI Adapter - 1080p - Mini DP to HDMI Monitor/Display/TV - Passive mDP 1.2 to HDMI Adapter Dongle Video Converter - Upgraded Version is MDP2HDEC (MDP2HDMI) Title Ingram (Part 1) Mini DisplayPort to HDMI Video A Title Ingram (Part 2) dapter Converter Website Product Headline Connect an HDMI® enabled display to a Mini DisplayPort® equipped PC or MAC Bullet 1 PERFORMANCE: mDP 1.2 to HDMI 1.4 adapter connects your mDP host to an HDMI display - 1920x1200/1080p 60Hz Video, 7.1ch Audio, HDCP 1.4, DPCP, 5" (13cm) attached cable - Upgraded version available with 12"/30cm attached cable for extended reach (MDP2HDEC) Bullet 2 HOST COMPATIBILITY: Passive Mini DP to HDMI display adapter supports mDP++ source including Thunderbolt 1 & 2 MacBooks, MacBook Air & Mac Mini, Microsoft Surface Pro 1-6, desktops (AMD FirePro/NVidia Quadro), laptops, mini itx computers, Intel NUC & docks Bullet 3 INCREASE PRODUCTIVITY: Mini DisplayPort to HDMI adapter connects an HDMI monitor, TV or projector, or add a second display to your workstation - Compact, small form factor design makes it easy to carry between home office and office Bullet 4 RELIABLE CONNECTION: MiniDisplayPort to HDMI video converter is designed with gold-plated connectors to ensure enhanced signal quality - Tested with HDMI cables up to 50ft (15m) Bullet 5 EASY TO USE: With no software or drivers required, the mDP to HDMI adapter dongle works with any OS including macOS, Windows & Ubuntu - Compatible with MiniDP devices like Microsoft Surface PCs or TB1/TB2 MacBooks Bullets (Compact) Passive Mini DisplayPort to HDMI adapter dongle - 1920x1200/1080p 60Hz/7.1 Audio/HDCP 1.4/DPCP - mDP 1.2 to HDMI 1.4 video converter - Supports mDP++ source including Thunderbolt 1/2 MacBook/Surface - Driverless - Upgraded version is MDP2HDEC Bullets (Consolidated) Upgraded version MDP2HDEC available with 1ft cable for extended reach - Mini DisplayPort to HDMI adapter supports 1920x1200 or 1080p 60Hz | mDP 1.2 to HDMI | 7.1 Audio/HDCP 1.4/DPCP - Passive Mini DP to HDMI adapter dongle supports Mini DisplayPort equipped PC or Mac incl Thunderbolt 1/2 MacBook/Air/Mini | Microsoft Surface Pro | Desktop computers/laptops/Intel NUC/docks - mDP to HDMI display adapter | Connect to HDMI monitor/TV/projector - Tested with HDMI cables up to 50' - OS independent Marketing Copy Marketing Copy (No HTML) Applications - Keep the adapter with you while you’re traveling, to connect to HDMI displays at trade shows or in hotel rooms
- Connect your BOYD laptop to an HDMI office hot desk or boardroom projector
- Use your HDMI monitor as a secondary display
Website Search Keyword - Adapter
- Converter
- DisplayPort
- HDMI
- Video
- apple
- mac
- Light Peak
- Light Peek
- Thunder Bolt
- thunderbolt
- MSPMDP2HD
- P137-06N-HDMI
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
System and Cable Requirements DP++ port (DisplayPort ++) required on video card or video source (DVI and HDMI pass-through must be supported) Accessory Products - HDMM1
- HDMM3
- HDMM6
- HDMM8
- HDMM10
- RHDMM2MP
- HDMM15
- HDMM20
- HDDVIMM3
- HDMIDVIMM6
- HDMIDVIMM10
- HDMIDVIMM15
- HDMIDVIMM20
- HDDVIMM25
- HDMMV2M
Related Products - MDP2HD4KSW
- MDP2HD4KS
- MDP2HDMM1MB
- MDP2HD4K60S
- MDP2HDMIUSBA
- MDP2HDS
- MDP2HDW
- MDP2HDMM2MB
- MDP2HDMM1MW
- MDP2HDMM2MW
- MDP2HDMM3MB
- MDP2HDMM5MB
Constrained SKU Alternatives (Limited Stock) - MDP2HDW
- MDP2HDEC
Cable Length (mm) 130 Color Black Humidity 10%-85%RH Operating Temperature 0°C to 45°C (32°F to 113°F) Primary Material Plastic Product Length (mm) 76.200 Product Width (mm) 40.000 Product Height (mm) 15.000 Product Weight (g) 20.000 Storage Temperature -10°C to 80°C (14°F to 176°F) TAA Compliant No Audio Specifications HDMI - 7.1 Channel Audio HDR Support No Maximum Cable Distance To Display 15200 Maximum Digital Resolutions 1920x1200 / 1080p Maximum Supported Resolution 1080p Video Output Port HDMI Active or Passive Adapter Passive Audio Yes AV Input Mini DisplayPort - 1.2 AV Output HDMI - 1.4 Chipset ID NXP Semiconductors PTN3361B Converter Type Adapters Host Connection Port Mini DisplayPort Number of Displays 1 Amount of recycled material in plastic packaging At Least 30% Carton Depth (mm) 508 Carton Height (mm) 229 Carton Quantity 220 Carton Weight Gross (g) 7548 Included in Package 1 - Mini-DisplayPort to HDMI converter Included In Package for Label 1 - Mini-DisplayPort to HDMI converter Number of Sub-Cartons 22 Package Depth (mm) 199 Package Height (mm) 20 Package Width (mm) 107 Package Quantity 1 Package Weight (g) 30 Packaging Description Mini DisplayPort® to HDMI® Video Adapter Packaging Description India Mini DisplayPort to HDMI Video Converter Sub-Carton Depth (mm) 293 Sub-Carton Height (mm) 55 Sub-Carton Width (mm) 221 Sub-Carton Quantity 10 Sub-Carton Weight (g) 298 Connector 1 Mini DisplayPort Connector 1 (Quantity) 1 Connector 2 HDMI Connector 2 (Quantity) 1 Amazon Merchandising Manager Kristian Haighton Artwork Due Date 2014-06-18 Buying Center - AV & Collaboration Yes Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge No Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,CO,DE,DK,ES,EU,FI,FR,HK,IE,IN,IT,JP,MX,NL,NZ,PE,SE,SG,UK,US Primary Technology None Product Development Specialist Abhinav Pathak Product Information Creation Specialist (PICS) Dan Dagenais Product Manager David Muzinic Product Performance Specialist John Mardinly Product Photographer Caleigh Le Grand Tech Lead Brian Linseman Technical Writer Andrew Richardson Technology Lifecycle Legacy
