Main Image
MPO12PL10M
10m MTP MPO 12 Fiber 40G OM3 Multi Mode 50 125 Aqua Ple
Plenum Rated | OFNP Fiber | Ideal for SANs, data servers, QSFP+
Main Image
Product Images
Product Images
BOM Image
Product Name 10m MTP MPO 12 Fiber 40G OM3 Multi Mode 50 125 Aqua Ple Product Number MPO12PL10M UPC 065030878999 Lifecycle status Active Warranty Lifetime Taxonomy Product > Cables > Fiber Network Cables Category Level 1 Network Cables Category Level 2 Fiber Cables Category Level 3 Multimode MPO Fiber Cables Family MPO/MTP 12 Fiber Cable Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX001X Country of Origin History (2) Vietnam Country of Origin Revision (2) XXXXXX001X Product Title (Ultra-Short) MTP Fiber Cable OFNP Product Title (Short) 10m Multimode Fiber Cable, MPO/MTP UPC Product Title (Medium) 10m (30ft) MTP(F) OM3 Multimode Fiber Optic Cable, 40G, OFNP, 50/125 Product Title (Standard) 10m (30ft) MTP(F)/PC OM3 Multimode Fiber Optic Cable, OFNP Plenum, 50/125µm, 40G, Low Insertion Loss, MPO Fiber Jumper Cord Product Title (Long) 10m (30ft) MTP(F)/PC OM3 Multimode Fiber Optic Cable, 12F Type-A, OFNP Plenum, 50/125µm LOMMF, 40G Networks, Low Insertion Loss, MPO Fiber Jumper Cord Product Title (AMZ) 10m (30ft) MTP(F)/PC OM3 Multimode Fiber Optic Cable, 50/125, 40G, Low Insertion Loss, MPO Fiber Jumper Cord Title Ingram (Part 1) Cavo in fibra ottica OM3 10m Title Ingram (Part 2) Cavo Patch Fibra OM3, 40Gb Website Product Headline Plenum Rated | OFNP Fiber | Ideal for SANs, data servers, QSFP+ Bullet 1 QUALITY CONSTRUCTION: OFNP jacket emits low-smoke and fumes if combusted; 50/125µm fiber core/cladding is immune to EMI; MTP Push-Pull Tabs with Flexible Extensions facilitates convenient installation and removal Bullet 2 OM3 FIBER CABLE: MTP/MPO Plenum-Rated OM3 Multimode Fiber Cable delivers up to 40 Gbps; This 12-fiber cable supports different networking devices at varying speeds; Ideal for high density connections to servers, switches, and Storage Area Networks (SANs) Bullet 3 SPECS: 10m (33ft); Color: Aqua (OM3); 40 Gbps; MTP(F)/PC to MTP(F)/PC; 12-Fiber Type-A Straight Pinout; 850nm or 1300nm VCSEL; Modal Bandwidth: 2000MHz•km at 850nm; Cable OD: 3.0mm; Insertion Loss: Below 0.5dB, Return Loss: 20dB; Backed for Life Bullet 4 COMPATIBILITY: OM3 Multimode cable with MTP connectors supports 40 Gbps for high-density network applications such as SANs, data servers, and QSFP+ transceivers Bullet 5 RATINGS AND RELIABILITY: Individually tested for signal integrity; Test report included with each cable; Rated for plenum and in-wall installations; 12-fiber MTP/MPO connectors with PC polished ends keeps insertion loss below 0.5dB Bullets (Compact) 10m (33ft) MTP(F)/PC to MTP(F)/PC OM3 Fiber Cable; 40 Gbps; 50/125µm Core; Bandwidth: 2000MHz·km at 850nm w/ VCSEL source; Outer Diameter: 3.0mm; OFNP-rated Jacket; Temp Range: -10 to 70°C (14 to 158°F) Bullets (Consolidated) 10m (33ft) MTP(F)/PC to MTP(F)/PC Plenum-Rated OM3 cable supporting 40 Gbps full-duplex connections - Cable individually tested for signal integrity | Ideal for high-density network applications such as SANs, data servers, and QSFP+ connections - 12-Fiber MTP/MPO Type-A Straight Pinout | 850nm or 1300nm VCSEL | Modal Bandwidth: >=2000MHz·km at 850nm OFNP Plenum-rated jacket with 50/125µm fiber core/cladding | Cord O.D.: 3.0mm | Temperature Range: -10 to 70DEG C (14 to 158DEG F) Marketing Copy Applications - Use in 10/40 Gigabit Ethernet and fiber channel applications
- Connect 40Gbps MPO/MTP devices such as fiber patch panels, hubs, switches, media converters, and routers
- Supports 40GBASE-SR4 and 100GBASE-SR10 in applicable parallel optics networks
Website Search Keyword - 40g fiber cable
- 40g mpo cable
- fiber cable
- fiber optic cable
- fiber optic patch cord
- fiber patch cable
- mpo 12 to mpo 12
- mpo 12 cable
- mpo cable
- mpo connector
- mpo fiber cable
- mpo fiber connector
- mpo fiber optic cable
- mpo mtp cable
- mpo to mpo
- mpo to mpo cable
- mtp cable
- mtp connector
- mtp fiber cable
- mtp fiber connector
- mtp fiber optic cable
- mtp to mtp
- mtp to mtp cable
- multimode fiber cable
- multimode fiber connector
- multimode fiber patch cable
- om3 fiber cable
- om3 fiber optic cable
- plenum rated cable
- N844-10M-12-P
Required Regulatory Compliance Marks - EU RIC + Italian Sorting - Packaging - Waste - European Union - Plastic - Low-Density Polyethylene
- Triman/Info-Tri - Packaging - Waste - European Union - Plastic Bag
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- UKCA - Environmental - United Kingdom - UK Restriction of Hazardous Substances (RoHS) 2012
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
Related Products - MPO12PL1M
- MPO12PL2M
- MPO12PL3M
- MPO12PL5M
Cable Length (mm) 10000 Color Aqua Primary Material Plastic Product Length (mm) 10000 Product Width (mm) 14 Product Height (mm) 7 Product Weight (g) 86 TAA Compliant No Fiber Type Multi Mode Cable Jacket Material Low Smoke Zero Halogen Cable Type Straight-Through Classification OM3 Fiber Cable Type Multifiber Fiber Classification OM3 Fiber Size 50/125 Fire Rating OFNP Plenum Rated Carton Depth (mm) 195 Carton Height (mm) 240 Carton Quantity 20 Carton Weight Gross (g) 2400 Included in Package 1 - fiber optic cable Number of Sub-Cartons 2 Package Depth (mm) 199 Package Height (mm) 24 Package Width (mm) 170 Package Quantity 1 Package Weight (g) 94 Packaging Description Plenum-Rated Fiber Optic Cable - 40Gb - Push/Pull-Tab Packaging Description India Plenum-Rated Fiber Optic Cable - 40Gb - Push/Pull-Tab Sub-Carton Depth (mm) 235 Sub-Carton Height (mm) 101 Sub-Carton Width (mm) 253 Sub-Carton Quantity 10 Sub-Carton Weight (g) 952 Connector 1 MPO / MTP Fiber Connector 1 (Quantity) 1 Connector 2 MPO / MTP Fiber Connector 2 (Quantity) 1 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2018-01-19 Buying Center - AV & Collaboration No Buying Center - Data Center Yes Buying Center - End User Compute No Buying Center - Networking & Edge Yes Digital Content Due Date 2018-01-19 Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) CA,DK,EU,IE,JP,UK,US Primary Technology None Product Development Specialist Brian Ha Product Information Creation Specialist (PICS) Brian Chan Product Manager Tim North Product Performance Specialist Ray Aoki Product Photographer Caleigh Le Grand Target Development Completion Date 2017-11-24 Target Production Release 2018-01-19 Tech Lead Justin Weaver Technical Writer Brian Chan Technology Lifecycle Mainstream
