Main Image
MXT101MMHQ10
10 ft Coax High Resolution VGA Monitor Cable HD15 M M
Connect your VGA monitor with the highest quality connection available
Main Image
Product Images
Product Images
Product Images
Product Images
Product Images
Product Name 10 ft Coax High Resolution VGA Monitor Cable HD15 M M Product Number MXT101MMHQ10 UPC 065030812122 Lifecycle status Active Warranty Lifetime Taxonomy Product > Cables > Video Cables Category Level 1 Cables - Other Category Level 2 DVI, VGA, Audio Cables Category Level 3 VGA Cables - High Res Family VGA Cable Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX045X Product Title (Ultra-Short) . Product Title (Short) 10 ft High Res Monitor VGA Cable Product Title (Standard) 10ft Coax High Res Monitor VGA Cable HD15 M/M Product Title (Long) 10 ft Coax High Resolution VGA Monitor Cable HD15 M/M Product Title (AMZ) 10 ft. (3 m) VGA to VGA Cable - HD15 Male to HD15 Male - Coaxial High Resolution - Durable Construction - VGA Monitor Cable (MXT101MMHQ10) Title Ingram (Part 1) 10 ft Coax High Resolution Monit Title Ingram (Part 2) or VGA Cable Website Product Headline Connect your VGA monitor with the highest quality connection available Bullet 1 Triple-coaxial + twisted-pair wire for crystal clear display Bullet 2 Durably constructed cable, with high quality HD15 connectors Bullet 3 Impedance matched at 75 Ohms for full brightness and vibrant picture color from your VGA monitor Bullet 4 High quality VGA connectors with molded PVC strain relief Bullets (Compact) . Bullets (Consolidated) Connect your VGA monitor with the highest quality connection available - 10ft VGA Cable - 10 ft VGA Video Cable - 10' VGA Monitor Cable - 10ft HD15 to HD15 Cable - 1920x1200 and above - VGA Coaxial Monitor Cable - HD15 to HD15 - Coax Monitor Cable Marketing Copy Applications - Connect a high resolution display to a Desktop PC or video switch, up to 10 feet away
- Replace a worn-out or missing VGA monitor cable with this high quality, coax VGA cable
- Supports high resolution VGA monitors (1920x1200)
Website Search Keyword - Monitor Cable
- VGA Cable
- P502-010
Required Regulatory Compliance Marks - CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- UKCA - Environmental - United Kingdom - UK Restriction of Hazardous Substances (RoHS) 2012
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- TSCA - Environmental - United States - EPA TSCA Title VI Compliant
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- Recycling - Waste - Japan - Plastic Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
- Triman/Info-Tri - Packaging - Waste - European Union - Plastic Bag
- Recycling - Waste - Japan - Paper Recycling Mark
Special Notes Pin number 9 is not populated on these connectors Related Products - MXT101MMHQ1
- MXT101MMHQ3
- MXT101MMHQ
- MXT101MMHQ20
- MXT101MMHQ25
- MXT101MMHQ30
- MXT101MMHQ35
- MXT101MMHQ40
- MXT101MMHQ45
- MXT101MMHQ50
- MXT101MMHQ55
- MXT101MMHQ60
- MXT101MMHQ65
- MXT101MMHQ70
- MXT101MMHQ75
Cable Length (mm) 3048 Color Black Humidity 0 - 80 %RH Operating Temperature 0 to 60 °C Primary Material Plastic Product Length (mm) 3048 Product Width (mm) 32 Product Height (mm) 20 Product Weight (g) 375 Storage Temperature -20 to 80 °C TAA Compliant No Wire Gauge 28 AWG Impedance (Ohm) 75 Ohm Cable Jacket Material PVC - Polyvinyl Chloride Cable Shield Material Aluminum-Mylar Foil with Braid Connector Plating Nickel Fire Rating CMG Rated (General Purpose) Number of Conductors 14 Number of Ferrites 1 Regulatory Approvals UL2919 Carton Depth (mm) 444 Carton Height (mm) 277 Carton Quantity 50 Carton Weight Gross (g) 20398 Included in Package - 1 - 10 ft Coax High Resolution VGA Monitor Cable - HD15 M/M
- 2 - Nuts
Number of Sub-Cartons 5 Package Depth (mm) 134 Package Height (mm) 34 Package Width (mm) 334 Package Quantity 1 Package Weight (g) 384 Packaging Description Coax High Res Monitor VGA Cable HD15 M/M Packaging Description India Coax High Res Monitor VGA Cable HD15 M/M Sub-Carton Depth (mm) 284 Sub-Carton Height (mm) 131 Sub-Carton Width (mm) 376 Sub-Carton Quantity 10 Sub-Carton Weight (g) 3916 Connector 1 VGA Connector 1 (Quantity) 1 Connector 2 VGA Connector 2 (Quantity) 1 Amazon Merchandising Manager Veronica Ye Artwork Due Date 2014-06-18 Buying Center - AV & Collaboration Yes Buying Center - Data Center Yes Buying Center - End User Compute Yes Buying Center - Networking & Edge No Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) BE,CA,ES,EU,IE,IN,JP,MX,NL,SE,UK,US Primary Technology None Product Development Specialist Pierre Wheeler Product Information Creation Specialist (PICS) Brian Chan Product Manager Tim North Product Performance Specialist Ray Aoki Product Photographer Caleigh Le Grand Tech Lead Justin Weaver Technical Writer Brian Chan Technology Lifecycle Mainstream Vending Machine Not Compatible with Vending Machine
