MXT101MMHQ75
75 ft Coax SVGA Monitor Cable HDDB15M M
Connect your VGA monitor with the highest quality connection available
Main Image
Product Images
Product Images
Product Images
Product Images
Product Images
Product Name 75 ft Coax SVGA Monitor Cable HDDB15M M Product Number MXT101MMHQ75 UPC 065030818087 Lifecycle status Discontinued Warranty Lifetime Taxonomy Product > Legacy Discontinued Category Level 1 Cables - Other Category Level 2 DVI, VGA, Audio Cables Category Level 3 VGA Cables - High Res Family VGA Cable Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX045X Product Title (Short) 75 ft Coax Monitor VGA Cable - HD15 M/M Product Title (Standard) 75ft Coax High Resolution Monitor VGA Cable - HD15 M/M Product Title (Long) 75ft Coax High Resolution Monitor VGA Cable - HD15 M/M Product Title (AMZ) 75 ft. (22.9 m) VGA to VGA Cable - HD15 Male to HD15 Male - Coaxial High Resolution - Durable Construction - VGA Monitor Cable (MXT101MMHQ75) Title Ingram (Part 1) 75 ft Coax High Resolution Monit Title Ingram (Part 2) or VGA Cable - HD15 M/M Website Product Headline Connect your VGA monitor with the highest quality connection available Bullet 1 Triple-coaxial + twisted-pair wire for crystal clear display Bullet 2 Durably constructed cable, with high quality HD15 connectors Bullet 3 Impedance matched at 75 Ohms for full brightness and vibrant picture color from your VGA monitor Bullet 4 High quality VGA connectors with molded PVC strain relief Bullets (Consolidated) Connect your VGA monitor with the highest quality connection available - Long VGA Cable/Long Monitor Cable/Projector Cable/75ft VGA Cable - Ferrite core eliminates EMI interference - Ideal for high resolution monitors 1920x1200 and above - Triple-coaxial + twisted-pair wire for crystal clear display - Molded connectors with strain relief - Connect your laptop up to 75 feet away from a projector - Compatible with ViewSonic PJD5234 / ViewSonic PJD5533W/Epson EX7220 / Epson EX5220 Marketing Copy Applications - Connect a high resolution display to a Desktop PC or video switch, up to 75 feet away
- Replace a worn-out or missing VGA monitor cable with this high quality, coax VGA cable
- Supports high resolution VGA monitors (1920x1200)
Website Search Keyword - Monitor Cable
- VGA cable
- P502075
- P502-075
Required Regulatory Compliance Marks - WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
Related Products - MXT101MMHQ1
- MXT101MMHQ3
- MXT101MMHQ
- MXT101MMHQ10
- MXT101MMHQ20
- MXT101MMHQ25
- MXT101MMHQ30
- MXT101MMHQ35
- MXT101MMHQ40
- MXT101MMHQ45
- MXT101MMHQ50
- MXT101MMHQ55
- MXT101MMHQ60
- MXT101MMHQ65
- MXT101MMHQ70
Cable Length (mm) 22865 Cable OD 9 Color Black Humidity 0 - 80 %RH Operating Temperature 0 to 60 °C Primary Material Plastic Product Length (mm) 22865.000 Product Width (mm) 0.000 Product Height (mm) 0.000 Product Weight (g) 2110.000 Storage Temperature -20 to 80 °C TAA Compliant No Wire Gauge 28 AWG Impedance (Ohm) 75 Ohm Cable Jacket Material PVC - Polyvinyl Chloride Cable Shield Material Aluminum-Mylar Foil with Braid Connector Plating Nickel Fire Rating CMG Rated (General Purpose) Number of Conductors 14 Number of Ferrites 1 Regulatory Approvals UL2919 Carton Depth (mm) 368 Carton Height (mm) 278 Carton Quantity 8 Carton Weight Gross (g) 18658 Included in Package - 1 - 75ft Coax High Resolution Monitor VGA Cable - HD15 M/M
- 2 - Nuts
Package Depth (mm) 240 Package Height (mm) 88 Package Width (mm) 247 Package Quantity 1 Package Weight (g) 2266 Packaging Description Coax High Res Monitor VGA Cable HD15 M/M Packaging Description India Coax High Res Monitor VGA Cable HD15 M/M Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 VGA Connector 1 (Quantity) 1 Connector 2 VGA Connector 2 (Quantity) 1 Amazon Merchandising Manager Veronica Ye Artwork Due Date 2014-06-18 Buying Center - AV & Collaboration Yes Buying Center - End User Compute Yes Buying Center - Networking & Edge No Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,BE,CA,DE,DK,EU,IE,MX,NL,SE,UK,US Primary Technology None Product Development Specialist Pierre Wheeler Product Information Creation Specialist (PICS) Brian Chan Product Manager Tim North Product Performance Specialist Ray Aoki Product Photographer Caleigh Le Grand Tech Lead Justin Weaver Technical Writer Brian Chan Technology Lifecycle Legacy
