Main Image
NETRS232_4GB
Main Image
Product Name 4 Port RS-232 Serial to Ethernet Product Number NETRS232_4GB UPC 065030817837 Lifecycle status Discontinued Warranty Lifetime Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan Canada Country of Origin North America Canada Product Title (Long) 4 Port RS-232 Serial Ethernet IP Adapter (Device Server, Console Server) Bullet 1 Browser based configuration of network settings, serial port line settings, UART transmit and receive buffer trigger levels and serial port flow control Bullet 2 Comes complete with Ether Link Manager software making serial device configuration easy Bullet 3 Data transfer rates of up to 115.2 Kb/sec per port Bullet 4 Remote Telenet configuration Bullet 5 Supports the following network protocols: IP, HTTP, ICMP, TCP, TFTP and UDP Marketing Copy Applications - Environmental Control (lighting, temperature, clocks)
- Hospital (monitoring equipment, nurses' stations)
- Hospitality/Restaurant (credit card/debit card reader, serial printers)
- Hotel Front Desk (serial printers, bar code scanners, keyboard, mouse, receipt printer, credit/debit card reader)
- Manufacturing (CNC machinery, process control equipment, bar code scanners, serial printers)
- POS (credit/debit card readers, receipt printers, bar code scanners, cash registers, scales)
- Security (UPS control, access key panels, video cameras, card readers)
Special Notes All modes other than Driver Mode operate independently of the operating system Accessory Products - AT925FM
- GC9SF
- M45PATCH100B
- M45PATCH50BL
- SC10MF
- SC6MF
- SC6MM
- SCNM9FF
- SCNM9FM
Related Products - NETRS232_1
- NETRS232_2
Center Tip Polarity Positive Cable Length (mm) 152.4 Color Beige Operating Temperature 0° to 70° C Product Length (mm) 130 Product Width (mm) 95 Product Height (mm) 44 Product Weight (g) 472 TAA Compliant No Maximum Data Transfer Rate 115200 Kbits/Sec OS Compatibility - Windows 7
- Windows 8
Industry Standards - HTTP
- ICMP
- TCP/IP
- TFTP
- UDP
Carton Depth (mm) 458 Carton Height (mm) 320 Carton Quantity 22 Carton Weight Gross (g) 15960 Package Depth (mm) 80 Package Height (mm) 152 Package Width (mm) 184 Package Weight (g) 820 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 DB-9 Serial Connector 1 (Quantity) 4 Connector 2 RJ-45 Connector 2 (Quantity) 1 en-US Content Approved Yes Product Manager Daryl Hunt
