NM9FF
DB9 Null Modem Serial Adapter F F
Cost-effective way of converting a straight through cable into a null modem cable
Main Image
Product Images
Product Images
BOM Image
Product Name DB9 Null Modem Serial Adapter F F Product Number NM9FF UPC 065030815789 Lifecycle status Active Warranty Lifetime Taxonomy Product > Cables > Serial, Parallel and PS2 Cables Category Level 1 Cables - Other Category Level 2 Serial, Parallel and PS2 Cables Category Level 3 Serial Cable Adapters Family No Family Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX067X Product Title (Short) Serial Null Modem Adapter - F/F Product Title (Standard) DB9 RS232 Serial Null Modem Adapter - F/F Product Title (Long) DB9 RS232 Serial Null Modem Adapter - F/F Product Title (AMZ) DB9 RS232 Serial Null Modem Adapter - F/F - Null modem adapter - DB-9 (F) to DB-9 (F) (NM9FF) Title Ingram (Part 1) DB9 RS232 Serial Null Modem Adap Title Ingram (Part 2) ter - F/F Website Product Headline Cost-effective way of converting a straight through cable into a null modem cable Bullet 1 DB-9 Female to DB-9 Female Bullets (Consolidated) F/F - Null modem adapter - DB-9 (F) to DB-9 (F) - for P/N: PCI2S232485I - PCI8S950LP - SV1115IPEXGB - SV1115IPEXT - SV1110IPEXT-KIT - SV1110IPEXGB Marketing Copy Required Regulatory Compliance Marks - WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
Color White Primary Material Plastic Product Length (mm) 50 Product Width (mm) 33.6 Product Height (mm) 15 Product Weight (g) 31 TAA Compliant No Screw Lock Yes Serial/Parallel Cable Type Null Modem (RS232) Carton Depth (mm) 310 Carton Height (mm) 346 Carton Quantity 500 Carton Weight Gross (g) 20230 Included in Package 1 - DB9 RS232 Serial Null Modem Adapter - F/F Included In Package for Label 1 - DB9 Rs232 Serial Null Modem Converter - F/F Number of Sub-Cartons 50 Package Depth (mm) 90 Package Height (mm) 125 Package Width (mm) 0.07 Package Quantity 1 Package Weight (g) 36 Packaging Description DB9 RS232 Serial Null Modem Adapter - F/F Packaging Description India DB9 RS232 Serial Null Modem Converter - F/F Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Quantity 10 Sub-Carton Weight (g) 388 Connector 1 DB-9 Serial Connector 1 (Quantity) 1 Connector 2 DB-9 Serial Connector 2 (Quantity) 1 Amazon Merchandising Manager Veronica Ye Artwork Due Date 2014-06-18 Buying Center - AV & Collaboration Yes Buying Center - Data Center No Buying Center - End User Compute No Buying Center - Networking & Edge Yes Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,BE,CA,CH,DE,DK,ES,EU,FR,IE,IN,IT,NL,SE,SG,UK,US Primary Technology None Product Development Specialist Alex Sikora Product Information Creation Specialist (PICS) Brian Chan Product Manager Tim North Product Performance Specialist Ray Aoki Product Photographer Caleigh Le Grand Tech Lead Justin Weaver Technical Writer Brian Chan Technology Lifecycle Mainstream
