O1210I-NETWORK-CARD
2 Port Open SFP OCP 3 0 10G Network Adapter Card Intel
Enhance a server or workstation's capabilities with dual 10 Gigabit fiber or copper connectivity using the SFP transceivers of your choice
Main Image
Product Images
Product Images
Product Images
Product Images
Product Images
Product Images
Quick-Start Guide
Product Name 2 Port Open SFP OCP 3 0 10G Network Adapter Card Intel Product Number O1210I-NETWORK-CARD UPC 065030900645 Lifecycle status Active Warranty 2 Years Weighted Opportunity 25750 Taxonomy Product > Cards & Adapters > Network Cards & Adapters Category Level 1 Networking Category Level 2 Desktop and Server Network Cards Category Level 3 Fiber Cards Family OCP 3.0 10G Network Cards Country of Origin Europe & Japan Malaysia Country of Origin North America Malaysia Country of Origin History (1) Malaysia Country of Origin Revision (1) XXXXXX156X Product Title (Ultra-Short) 2-Port SFP+ OCP Card Product Title (Short) 2-Port SFP+ OCP Network Card, Intel X710 Product Title (Medium) 2-Port 10Gbps SFP+ OCP 3.0 Server Network Card, Intel X710, NIC, Windows/Linux Product Title (Standard) 2-Port 10Gbps SFP+ OCP 3.0 Server Network Card, Intel X710, SFF 4C+ Compatible, Dual-Port OCP NIC, Windows/Linux Compatible Product Title (Long) 2-Port 10Gbps SFP+ OCP 3.0 Server Network Card with Intel X710, SFF 4C+ Compatible, Dual-Port OCP NIC, Works with Windows & Linux Product Title (AMZ) 2-Port 10Gbps SFP+ OCP 3.0 Server Network Card, Intel X710, SFF 4C+ Compatible, Dual-Port OCP NIC, Windows/Linux Title Ingram (Part 1) 2-Port SFP+ OCP Network Card - Title Ingram (Part 2) 10Gbps Server NIC, Intel X710 Website Product Headline Enhance a server or workstation's capabilities with dual 10 Gigabit fiber or copper connectivity using the SFP transceivers of your choice Bullet 1 10G OCP NETWORK CARD: 10Gbps Network Interface Card w/Intel X710-BM2 Controller adds 2x open SFP+ slots to a server, enhancing connectivity options/network performance; Ideal for high-speed, low-latency connections (e.g., virtualization, cloud computing) Bullet 2 REDUCED DOWNTIME: Network Adapter Card uses the OCP (Open Compute Project) 3.0 port (168-Pin 4C+), developed for servers to reduce size, increase port density, and provide hot-swappable capabilities for simplified maintenance and upgrades Bullet 3 UNLOCKED SFP+ SLOTS: Works with any single-mode/multimode MSA-compliant or branded SFP or SFP+ modules, active optical cables (AOC), or direct attach copper cables (DAC); Optical fiber allows for longer cable runs than copper cabling while eliminating EMI Bullet 4 Bullet 5 IT MANAGEMENT: Network Virtualization offloads reduce CPU overhead, enhancing virtualized network efficiency; PXE boot enables centralized OS deployment/updates; 9K jumbo frames for reduced packet overhead; VLAN support for efficient network management Bullets (Compact) 10G NIC w/Intel X710-BM2 adds 2x SFP+ slots; OCP 3.0 port for compact design, simplified maintanence; Network Card works with SFP+ modules/AOC/DAC, 1000Base-T/SX/LX/EX and 10GBase-T/SR/LR/CR; Windows/Linux; Supports PXE boot, 9K jumbo frames, VLAN Bullets (Consolidated) - 10Gbps Network Interface Card w/Intel X710-BM2 adds 2x open SFP+ slots to a server - NIC uses the OCP (Open Compute Project) 3.0 port (168-Pin 4C+) developed to reduce size and provide simplified maintenance and upgrades - Works with single-mode/multimode MSA-compliant or branded SFP+ modules/active optical cables (AOC)/direct attach copper cables (DAC); Supports 1000Base-T/SX/LX/EX and 10GBase-T/SR/LR/CR - Works with Windows Server/Windows/Linux - Supports PXE boot/9K jumbo frames/WoL/VLAN Marketing Copy Marketing Copy (No HTML) Applications - Create a high-speed and flexible network infrastructure in data centers or enterprise networks
- Dual ports allow for redundancy and load balancing, enhancing network reliability and performance
Website Search Keyword - OCP Card
- SFP+ Network Card
- SFP+ Network Adapter Card
- OCP Network Card
- OCP NIC
- OCP NIC 3.0
Required Regulatory Compliance Marks - Triman/Info-Tri - Product - Waste - European Union - EEE Device
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- Triman/Info-Tri - Packaging - Waste - European Union - Paper Box + plastic bag
Special Notes - Intel NIC Teaming is supported only on Windows Server OS (e.g., Server 2012, 2016) and not on desktop versions like Windows 10 or 11. Accessory Products - SFP10GSRST
- SFPCMM3M
Related Products - OR41GI-NETWORK-CARD
- PEX20000SFPI
Power Source Bus Powered Color Black Humidity 5% ~ 90% RH Operating Temperature 0°C - 60°C (32°F - 140°F) Product Length (mm) 132.000 Product Width (mm) 85.000 Product Height (mm) 15.000 Product Weight (g) 104.000 Storage Temperature -10°C - 70°C (14°F - 158°F) TAA Compliant No Compatible Networks 1Gbps / 10Gbps Fiber Type - Single Mode / Multi Mode
- Copper
Full Duplex Support Yes General Specifications - VMDq Support
- SR-IOV Support
- Dynamic Device Personalization (DDP)
- Data Plane Development Kit (DPDK)
- Network Virtualization Offloads (NVO) including VxLAN, GENEVE, NVGRE, and VxLAN-GPE with Network Service Headers (NSH)
Jumbo Frame Support 9K max. Maximum Data Transfer Rate 10Gbps OS Compatibility - Windows Server 2012
- Windows Server 2012 R2
- Windows Server 2016
- Windows Server 2019
- Windows Server 2022
- Windows 10
- Windows 11
- Linux
Promiscuous Mode Yes PXE Yes Wake-On-LAN (WOL) Yes Bus Type OCP 3.0 Card Type OCP (Open Compute Project) Chipset ID Intel X710-BM2 Industry Standards Interface/Bridge - Fiber (10 Gigabit Ethernet)
- Fiber Ethernet
IO Card Port Style Integrated on Card LED Indicators Carton Depth (mm) 370 Carton Height (mm) 315 Carton Quantity 40 Carton Weight Gross (g) 7600 Included in Package - 1 - Network Card
- 1 - Quick-Start Guide
Package Depth (mm) 146 Package Height (mm) 36 Package Width (mm) 217 Package Weight (g) 166 Packaging Description 2-Port OCP 3.0 10G Open SFP+ Network Card - Intel Packaging Description India 2-Port OCP 3.0 10G Open SFP+ Network Card - Intel Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 SFP+ Slot Connector 1 (Quantity) 2 Host Connector 1 OCP NIC 3.0 4C+ Connector (168-Pin, SFF-TA-1002) Host Connector 1 (Quantity) 1 A+ Not Required Actual Inbox Documents Created QSG in the box Amazon Merchandising Manager Kathleen Marshall Application Photos Not Required Artwork Due Date 2024-04-30 Buying Center - AV & Collaboration No Buying Center - Data Center Yes Buying Center - End User Compute No Buying Center - Networking & Edge Yes Comparable SKU Comment PCIe 10G dual open SFP+, T12 $473K, T12 Sell thru Qty 1556 Comparable SKU 2 Comment PCIe 10G dual Digital Content Due Date 2024-06-10 Enhanced Gallery Not Required Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett ID Label Silkscreened or a Label Sticker label - 37x20mm Launch Markets (concatenated) AT,BE,CA,CH,DE,DK,ES,FI,FR,IE,IN,IT,JP,NL,SE,UK,US Product Development Specialist Alex Sikora Product Information Creation Specialist (PICS) Dan Dagenais Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Target Development Completion Date 2024-03-22 Target Production Release 2024-04-30 Tech Lead Stefan Tirolese Technical Writer Dan Dagenais Technology Lifecycle None Video Not Required
