Main Image
OPT2IDE
IDE to Slim Optical IDE Drive Adapter
Convert a slimline IDE optical drive connector to a desktop computer's 40-pin IDE connector
Main Image
Product Images
BOM Image
Product Name IDE to Slim Optical IDE Drive Adapter Product Number OPT2IDE UPC 065030837583 Lifecycle status Discontinued Warranty Lifetime Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Product Title (Short) IDE to Slim Optical IDE Drive Adapter Product Title (Standard) IDE to Slim Optical IDE Drive Adapter Product Title (Long) IDE to Slim Optical IDE Drive Adapter Title Ingram (Part 1) IDE to Slim Optical IDE Drive Ad Title Ingram (Part 2) apter Website Product Headline Convert a slimline IDE optical drive connector to a desktop computer's 40-pin IDE connector Bullet 1 Two screws are included for mounting to the rear of the slim drive. Bullet 2 Jumpers for setting master or slave on the IDE channel Bullet 3 Enables an ATAPI device to work on a EIDE/IDE interface Marketing Copy This IDE to Slim ATAPI or IDE Optical Drive Adapter lets you connect any slimline IDE-based optical drive to a computer using an IDE cable The adapter features a 40 pin IDE data connector for connection to the host computer, Power, and two CD Audio connections, as well as a 50-pin ATAPI device connector for slim IDE drives. Applications Connecting Slimline IDE based CD & DVD drives to IDE controllers Website Search Keyword - IDE CD Drive to IDE
- IDE CD Rom to IDE
- Slimline CD DVD Drive adapters
- optical drive adapter
- ATAPI devices
- DVD Rom
- DVDRW
- MPC2
- Slime Optical to IDE converter
Accessory Products - SLIMCDFDCAGE
- IDE100RND18
- IDE100RND24
- IDE100RND36
- IDE_
- IDE100TPO18
- IDE18BULK
- IDE66
- IDE66_24
- IDE66_36
- IDERND18CL
- IDERND24BL
- PYO2SL
- LP4SATAFMD
- PYO2S
- CDAUDIO
- CDAUDIO2
- CDAUDIO2BULK
Related Products - OPT2SATA
- SLSATAADAP
- SLSATACDADAP
Color Green Humidity 0~95% RH Operating Temperature 0°C to 50°C (32°F to 122°F) Product Length (mm) 170 Product Width (mm) 138 Product Height (mm) 26 Product Weight (g) 14 Storage Temperature -10°C to 60°C (14°F to 140°F) TAA Compliant No OS Compatibility - Windows 2000
- Windows XP
- Windows Vista
- Windows 98SE
- Linux
Carton Depth (mm) 516 Carton Height (mm) 369 Carton Quantity 100 Carton Weight Gross (g) 11200 Included in Package - 1 - Slim optical to IDE adapter
- 1 - Mounting Screws
Package Depth (mm) 27 Package Height (mm) 137 Package Width (mm) 173 Package Weight (g) 100 Packaging Description IDE to Slimline Optical IDE Adapter Packaging Description India IDE to Slimline Optical IDE Adapter Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 IDE / PATA (ATA/133) Connector 1 (Quantity) 1 Connector 2 Audio Header MPC2 (4-Pin) Connector 2 (Quantity) 1 Connector 3 SP4 / Floppy Power (4-Pin, 5V / 12V) Connector 3 (Quantity) 1 Connector 4 Slim ATAPI (50-Pin) Connector 4 (Quantity) 2 en-US Content Approved Yes Product Manager David Muzinic
