P10Q4A-USB-CARD
4-Port USB-A 10Gbps Quad Bus PCIe Card
Add four USB Type-A ports with four independent 10Gbps channels to a computer via a PCI Express slot
Main Image
Product Images
Product Images
Product Images
Product Images
Product Images
Product Images
Quick-Start Guide
Product Name 4-Port USB-A 10Gbps Quad Bus PCIe Card Product Number P10Q4A-USB-CARD UPC 065030912198 Lifecycle status Pending Warranty 2 Years Weighted Opportunity 0 Taxonomy Product > Cards & Adapters > USB Cards Category Level 1 Computer Cards and Adapters Category Level 2 USB Cards and Extenders Category Level 3 USB-A Cards - 10Gbps Family USB-A Cards - 10Gbps Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX051X Product Title (Ultra-Short) 4-Port USB-A Card Product Title (Short) 4-Port USB-A PCIe Card, USB 3.2 10Gbps Product Title (Medium) 4-Port USB-A PCIe Card, USB 3.2 10Gbps, 4x USB Controllers, PCI Express, TAA Product Title (Standard) 4-Port USB-A PCIe Card, USB 3.2 10Gbps, USB PCI Express Expansion Card, 4x Independent USB Controllers, TAA-Compliant Product Title (Long) 4-Port USB-A PCIe Card, USB 3.2 10Gbps, PCI Express 3.0 Expansion Card, 4x Independent USB Controllers, Windows/Linux/macOS, TAA-Compliant Product Title (AMZ) 4-Port USB-A 10Gbps PCIe Card, 4x Independent USB 3.2 Controllers, PCI Express 3.0 Expansion Card, TAA Title Ingram (Part 1) 4-Port USB-A PCIe Expansion - Title Ingram (Part 2) USB 3.2 10Gbps, PCI Express, TAA Website Product Headline Add four USB Type-A ports with four independent 10Gbps channels to a computer via a PCI Express slot Bullet 1 Bullet 2 Bullet 3 Bullet 4 Bullet 5 Bullets (Compact) Add four USB-A ports for up to 40Gbps combined bandwidth via this PCIe expansion card - Independent controllers enable up to 10Gbps per port - Plug-and-play Windows macOS Linux - PCI Express 3.0 x4; Full-profile bracket - SATA power for 10W per port Bullets (Consolidated) Add four USB-A ports to a desktop or server with up to 40Gbps of combined bandwidth with his PCIe expansion card - Independent controllers (USB 3.2 Gen 2) per port support up to 10Gbps each for consistent performance with multiple connected devices - Plug-and-play compatibility with Windows macOS and Linux - For PCI Express 3.0 x4 or larger slots; Ships with full-profile bracket - Auxiliary SATA power input provides up to 5V 2A 10W per port for stable operation for bus-powered peripherals Marketing Copy Marketing Copy (No HTML) Applications - Upgrade a desktop or server with four USB-A ports, each with it's own dedicated 10Gbps
- Ideal for transferring large files, real-time editing of high-resolution photos and videos on external storage, off-loading media from mobile devices, using high-resolution video capture devices, tethered photography equipment, or high-speed USB network adapters
Required Regulatory Compliance Marks - CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- UKCA - Environmental - United Kingdom - UK Restriction of Hazardous Substances (RoHS) 2012
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- Triman/Info-Tri - Manual - Waste - European Union - Print Paper
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
- EU RIC + Italian Sorting - Packaging - Waste - European Union - Corrugated Fiberboard
- Triman/Info-Tri - Packaging - Waste - European Union - Paper Box + plastic bag
Accessory Products - USB31CCV1M
- USB31CCV50CM
- UCC-3M-10G-USB-CABLE
- HB31C2A2CB
- 10G8A2CS-USB-C-HUB
Related Products - P10Q4C-USB-CARD
- P10Q4C-USB-CARD-LP
- P5Q4A-USB-CARD
- PEXUSB3S44V
- PS4C3IA3-USB-C-CARD
- PEXUSB312A1C1H
- PEXUSB312A2C2V
- PEXUSB314A2V2
- PEXUSB312A3
- PEXUSB311AC3
- PEXUSB312C3
Power Delivery 15W Power Source Bus Powered Color Red Primary Material PCB Product Length (mm) 140 Product Width (mm) 20 Product Height (mm) 120 Product Weight (g) 106 TAA Compliant Yes Fast Charge Ports (BC 1.2) Yes Maximum Data Transfer Rate 10Gbps OS Compatibility - Windows 11
- Windows 10
- Windows Server 2022
- Windows Server 2019
- macOS Tahoe (26.0)
- macOS Sonoma (14.0)
- Linux
- Windows Server 2025
Total USB Power Output 10W max per port UASP Support Yes USB Speed USB 3.2 Gen 2 (10Gbps) USB Type and Rate USB 10Gbps Card Type Standard Profile Chipset ID - ASMedia - ASM3142
- ASMedia - ASM2812X
Industry Standards PCI Express 3.0 Interface/Bridge PCI Express IO Card Port Style Integrated on Card USB Port Type USB-A Included in Package - 1 - PCIe USB Card
- 1 - Product Documentation
Included In Package for Label - 1 - PCIe USB Card
- 1 - Product Documentation
Packaging Description 4-Port USB-A PCIe Card - 10Gbps - 4 Dedicated USB Controllers - PCIe 3.0 x4 Packaging Description India 4-Port USB-A PCIe Card - 10Gbps - 4 Dedicated USB Controllers - PCIe 3.0 x4 Connector 1 USB-A (10Gbps, 4.5W) Connector 1 (Quantity) 4 Connector 2 SATA (15-Pin) Connector 2 (Quantity) 1 Host Connector 1 PCI Express x4 Host Connector 1 (Quantity) 1 A+ Not Required Actual Inbox Documents Created Compliance Insert & EN/DE QSG Amazon Merchandising Manager Veronica Ye Amazon Only SKU No Amazon Visual Content Level Diamond Application Photos Uploaded Artwork Due Date 2025-10-24 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute No Buying Center - Networking & Edge Yes Comparable SKU Comment 4 Port USB 3.0 PCIe Card w/ 4 Dedicated 5Gbps Channels (USB 3.2 Gen 1) - UASP - SATA / LP4 Power - PCI Express Adapter Card Comparable SKU 2 Comment 4-Port USB PCIe Card - 10Gbps USB 3.2 Gen 2 Type-A PCI Express Expansion Card with 2 Controllers - 4x USB-A - USB PCIe Add-On Adapter Card - Windows/Mac/Linux Digital Content Due Date 2025-12-23 Enhanced Gallery Not Required Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Brooke Taylor ID Label Silkscreened or a Label Sticker label - custom size - requires size population below Launch Markets (concatenated) AT,AU,BE,CA,CH,DE,DK,ES,FI,FR,HK,IE,IN,IT,JP,MX,NL,NZ,SE,SG,UK,US Primary Technology USB 3.2 Gen 2 / 10Gbps Priority New Product Medium Product Development Specialist Yipeng Zhang Product Information Creation Specialist (PICS) Alex Garcia Product Manager Natalie Goodale Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Target Development Completion Date 2025-09-30 Target Production Release 2025-10-07 Tech Lead Stefan Tirolese Technical Writer Alex Garcia Technology Lifecycle Latest Video Not Required
