PCI1PR
1 Port Remappable PCI Parallel Adapter Card
Add a fully featured I/O mapped parallel port to your system using a PCI expansion slot
Main Image
Product Images
Product Images
Product Images
Product Name 1 Port Remappable PCI Parallel Adapter Card Product Number PCI1PR UPC 065030842617 Warranty Lifetime Taxonomy Product > Legacy Discontinued Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) 1 Country of Origin History (2) China Product Title (Long) 1 Port Remappable PCI Parallel Adapter Card Website Product Headline Add a fully featured I/O mapped parallel port to your system using a PCI expansion slot Bullet 1 Data transfer rates of up to 1.8Mbps Bullet 2 Auto-switching between EPP, ECP, SPP and BPP modes Bullet 3 Supports re-mapping of memory I/O ranges for legacy peripherals (278, 378, and 3BC legacy ISA addresses) Bullet 4 Ultra low power consumption Bullet 5 Universal PCI card supports 32/64-bit, PCI/PCI-X, 3.3/5V slots Marketing Copy Applications - Connects any parallel peripheral including printers, scanners, CD-R/RWs, Zip® drives, and memory card readers
- Install legacy peripherals such as software protection dongles, JTAG chip programmers, data acquisition, machine process control and scientific measurement systems requiring specific I/O ranges specified
Website Search Keyword - I/O
- expansion card
- parallel adapter
- remappable
- remap
- re-map
- CF78
- memory address
- 0378
- 037F
Microsoft WHQL Certified Yes Special Notes Supports re-mapping I/O to 278, 378, and 3BC legacy ISA addresses System and Cable Requirements Unused PCI slot Accessory Products - PB10
- PB6_
- PC20
- PC30
- PC50
- PTXFER15
- PTXFER6
- SC10FF
- SC10MF
- SC20MF
- SC20MM
- SC50MM
- SC6MF
- SC6MM
Related Products - PCI1P_LP
- PCI1PECP
- PCI2PECP
- PCI1P
- PCI2S1P
- PCI2S1PDV
- PCI2S1PVA
Power Consumption (In Watts) 0.033W Color Yellow Humidity 5~95% RH Operating Temperature 0°C to 60°C (32°F to 140°F) Product Length (mm) 121 Product Width (mm) 61 Product Height (mm) 13 Product Weight (g) 75 Storage Temperature -20°C to 85°C (-4°F to 185°F) TAA Compliant No FIFO 16 byte Maximum Data Transfer Rate 1.8Mbps OS Compatibility - Linux
- Windows 2000
- Windows 7
- Windows Vista
- Windows Server 2008 R2
- Windows Server 2003
- MS DOS
- Windows XP
Bus Type PCI / PCI-X (5 / 3.3V) Card Type Standard Profile (LP bracket incl.) Chipset ID Sunix - UL7512EQ Industry Standards Included in Package - 1 - Driver CD
- 1 - PCI Parallel Card
- 1 - User Manual
Connector 1 DB-25 Parallel / Serial Connector 1 (Quantity) 1 en-US Content Approved Yes
