PCI2S5502
2 Port 16550 PCI Serial Card - 2nd Version
PCI | RS-232 Serial | 2-Port | Lifetime Warranty
Main Image
Product Images
Product Images
Product Images
Product Images
Product Images
Product Images
Product Images
Product Images
Product Images
BOM Image
Product Name 2 Port 16550 PCI Serial Card - 2nd Version Product Number PCI2S5502 UPC 065030891318 Lifecycle status Discontinued Warranty Lifetime Taxonomy Product > Legacy Discontinued Category Level 1 Computer Cards and Adapters Category Level 2 Serial Cards, Adapters and Extenders Category Level 3 Serial Host Adapter Cards Family 16550 PCie Serial Cards Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX072X Product Title (Ultra-Short) 2pt PCI Serial Card Product Title (Short) 2-Port PCI RS232 Serial Adapter Card DB9 Product Title (Medium) 2-Port PCI RS232 Serial Adapter Card - PCI Serial Port Expansion Controller Product Title (Standard) 2-Port PCI RS232 Serial Adapter Card, Dual Serial DB9 Ports, Expansion/Controller Card, Windows/Linux, Standard/Low Profile Product Title (Long) 2-Port PCI RS232 Serial Adapter Card - PCI Serial Port Expansion Controller Card - PCI to Dual Serial DB9 Card - Standard (Installed) & Low Profile Brackets - Windows/Linux Product Title (AMZ) 2-Port PCI RS232 Serial Adapter Card - PCI Serial Port Expansion Controller Card - PCI to Dual Serial DB9 Card - Standard (Installed) & Low Profile Brackets - Windows/Linux (PCI2S5502) Title Ingram (Part 1) 2-Port PCI RS232 Serial Adapter Title Ingram (Part 2) Port Expansion Controller Card Website Product Headline PCI | RS-232 Serial | 2-Port | Lifetime Warranty Bullet 1 2 PORT PCI RS232 SERIAL ADAPTER CARD: Controller card w/ 16C550 UART based on ASIX MCS9865, 2x DB9 ports w/bi-directional RS232 speeds up to 115.2Kbps/port, 256 byte FIFO buffer & 9th data bit | Upgraded version of our popular cards PCI2S550_LP & PCI2S550 Bullet 2 TECH SPECS: Speeds up to 115.2Kbps | 16C550 UART | 256 byte FIFO buffer | 5,6,7,8 and 9 bit character | Even, Odd, No, Space or Mark Parity | Auto IRQ & IO assignment | Supports IRQ Sharing | ASIX MCS9865 Chip Bullet 3 VERSATILE APPLICATIONS: Dual Serial Port PCI Card for PCI desktops/servers used in point of sale terminals, PLCs, CNC Machines, control/automation in factories, scientific sensors, medical equipment, scanners, oscilloscope Bullet 4 STANDARD PROFILE & LOW PROFILE BRACKET: PCI multiport serial COM card installs using 1x standard bracket (pre-installed) or 2x low profile brackets (incl); Supports Windows 7 and up, Linux 2.6.x to 5.x Bullet 5 STARTECH.COM ADVANTAGE: IT professionals choice for over 30 years; PCI RS-232 Serial expansion card is backed for life by StarTech.com, incl. free 24/5 North America based multi-lingual tech support Bullets (Compact) Dual port PCI RS232 serial adapter card 16C550 UART/ASIX MCS9865 - Expansion/controller card with speeds up to 115.2Kbps/COM port | 256 byte FIFO | 9th data bit - Even/Odd/No/Space/Mark Parity - Standard bracket (low profile incl) - Windows/Linux Bullets (Consolidated) Dual Port PCI RS232 Serial Adapter Card w/16C550 UART using ASIX MCS9865; Upgraded version of our popular PCI2S550_LP/PCI2S550 - DB9 Serial Controller card with Bi-directional RS-232 speeds up to 115.2Kbps/COM port | 256 byte FIFO and 9th data bit - Even/Odd/No/Space/Mark Parity | Auto IRQ/IO assignment | IRQ Sharing - Expansion card installs using 1x standard bracket (pre-installed) or 2x low profile brackets (incl) - Windows 7+/Linux 2.6.x-4.x - Use in PLCs/CNCs/automation/medical/scanners Marketing Copy Applications Connect point of sale terminals, serial printers, PLCs, scientific sensors, medical equipment, scanners and oscilloscopes to your computer via the added serial ports Website Search Keyword - 2 port pci card
- 2 port pci rs232 serial adapter card
- 2 port pci rs232 serial adapter card with 16550 uart
- 2 port serial card
- db9 card
- db9 pci card
- dual port serial card
- dual serial port pci card
- low profile serial card
- moxa pci serial card
- pc serial card
- pci adapter card
- pci card rs232 serial ports
- pci rs232
- pci rs232 card
- pci rs232 serial adapter card
- pci serial
- pci serial adapter
- pci serial card
- pci to rs232 card
- pci to serial port
- PCI2S550
- PCI2S550_LP
- rs232 card
- rs232 pci card
- rs232 serial adapter
- rs232 serial adapter card
- rs232 serial card
- serial adapter card
- serial card
- serial controller card
- serial expansion card
- serial port adapter card
- serial port card
- serial port expansion card
- serial port pci
- serial port pci card
- startech serial card
Microsoft WHQL Certified Yes Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
Accessory Products - NM9MF
- MXT1003
- MXT100
- MXT106
- SCNM9FF1MBK
- SCNM9FF2MBK
Related Products - PEX1S953LP
- PEX2S953
- PEX2S953LP
- PEX4S953LP
- PEX1S1P950
- PEX4S953
- PEX8S1050
- PEX8S1050LP
- PCI1S550
- PCI2S550
Color Black Humidity 10~90% RH Operating Temperature 0°C to 70°C (32°F to 158°F) Product Length (mm) 133.600 Product Width (mm) 21.600 Product Height (mm) 120.000 Product Weight (g) 57.000 Storage Temperature -20°C to 85°C (-4°F to 185°F) TAA Compliant No Data Bits 5, 6, 7, 8, 9 FIFO 256 Bytes Flow Control None, Xon/Xoff, RTS/CTS Max Baud Rate 115.2 Kbps OS Compatibility - Windows 8
- Windows Server 2012
- Linux
- Windows 7
- Windows 10
- Windows Server 2016
- Windows Server 2019
- Windows 11
- Windows Server 2022
Parity None, Odd, Even, Space, Mark Stop Bits 1, 1.5, 2 Supported Serial Protocol RS-232 Bus Type PCI Card Type Standard Profile (LP bracket incl.) Chipset ID ASIX - MCS9865 Industry Standards 16C550 (RS-232) Interface/Bridge PCI / PCI-X (5 / 3.3V) IO Card Port Style Integrated on Card Carton Depth (mm) 360 Carton Height (mm) 340 Carton Quantity 40 Carton Weight Gross (g) 6580 Included in Package - 1 - PCI Serial Card
- 1 - Full Profile Bracket (Installed)
- 2 - Low Profile Brackets
- 1 - Quick-Start Guide
Number of Sub-Cartons 4 Package Depth (mm) 142 Package Height (mm) 30 Package Width (mm) 170 Package Quantity 1 Package Weight (g) 130 Packaging Description 2 Port PCI RS232 Serial Card with 16C550 UART Packaging Description India 2 Port PCI RS232 Serial Card with 16C550 UART Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Quantity 10 Sub-Carton Weight (g) 0 Connector 1 PCI / PCI-X Connector 1 (Quantity) 1 Connector 2 DB-9 Serial Connector 2 (Quantity) 2 Amazon Merchandising Manager Veronica Ye Artwork Due Date 2020-12-17 Buying Center - AV & Collaboration No Buying Center - End User Compute No Buying Center - Networking & Edge Yes Digital Content Due Date 2021-06-02 Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett ID Label Silkscreened or a Label No ID label Launch Markets (concatenated) AU,BE,CA,DE,DK,ES,FR,IT,JP,NL,NZ,SE,SG,UK,US Primary Technology None Product Development Specialist Scott Dunlop Product Information Creation Specialist (PICS) Alex Garcia Product Manager Natalie Goodale Product Performance Specialist Aaron Bens Product Photographer Alejandra Valencia Target Development Completion Date 2020-12-31 Target Production Release 2021-01-21 Tech Lead Brian Linseman Technical Writer Alex Garcia Technology Lifecycle None
