PCISATA2F3
Main Image
Product Name 2 SATA and 3 IEEE1394 Firewire PCI Card Product Number PCISATA2F3 UPC 065030805124 Lifecycle status Discontinued Warranty Lifetime Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX051X Product Title (Long) 2 Port Serial ATA and 3 Port IEEE-1394 FireWire Slot Saver PCI Card Bullet 1 Bullet 2 Two independent Serial ATA channels supports up to 2 Serial ATA hard drives Bullet 3 Compliant with Serial ATA specification V1.0 Bullet 4 Includes features like Serial ATA to PCI interrupt masking and Watch Dog Timer for fault resiliency Bullet 5 Marketing Copy Applications Connect to a wide range of internal and external FireWire® and SATA devices including CD-RW/DVD-ROMs, removable hard drives, video cameras, digital camcorders/cameras and MP3 players/iPods Website Search Keyword HardToFind Accessory Products - 1394_6
- 1394_10
- 1394_15
- SATA18
- SATA24
- SATA36
- 1394_6LEDBL
- SATA24BLUV
Related Products - PCISAT2F3U4
- PCI3UV22F
TAA Compliant No General Specifications - Internal Ports: 2 x 7-pin (female) Serial ATA ports
- Data Transfer Rate: Up to 150 MBytes/sec
- Standards: Serial ATA specification version 1.0 compliant
- FIFO: 256 Bytes/port
- External Ports: 2 x 6-pin (female)1394a ports, 1 x 4-pin i.link (female) 1394a port
- Data Transfer Rate: Up to 400 Mbits/sec
- Standards: IEEE 1394a-2000 & OHCI Rev 1.1 compliant
- Form Factor: Full-Sized or Low Profile PCI Card
- Onboard power connector (with included cable) draws extra power from your computer’s power supply if necessary
- Minimum Processor Requirements: PC - Intel Pentium 2 at 400MHz or faster, Intel Celeron at 900MHz or faster, AMD Athlon of any speed
- OS Support: Windows 98SE/ME/2000/XP/Server 2003 and up
Maximum Data Transfer Rate 1200000000 MBytes/Sec OS Compatibility Windows Vista Bus Type PCI (5 Volt) Carton Depth (mm) 347 Carton Height (mm) 487 Carton Quantity 40 Carton Weight Gross (g) 10400 Package Depth (mm) 48 Package Height (mm) 160 Package Width (mm) 220 Package Weight (g) 230 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 FireWire 400 (6-Pin, 400Mbps, Bus Power) Connector 1 (Quantity) 2 Connector 2 SATA (7-Pin) Connector 2 (Quantity) 2 Connector 3 FireWire 400 (4-Pin, 400Mbps, No Bus Power) Connector 3 (Quantity) 1 en-US Content Approved Yes Product Manager Carey Cline
