PCISCSIU2W
Main Image
Product Name 80 MB/s PCI Ultra2 SCSI Card Product Number PCISCSIU2W UPC 065030785440 Lifecycle status Discontinued Warranty Lifetime Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX054X Product Title (Long) 80 MByte/sec. Ultra2 SCSI PCI Card Bullet 1 Dedicated onboard SCSI processing for enhanced performance and data transfer rates of up to 80 MBytes/sec Bullet 2 Includes built-in programmable automatic SCSI termination Bullet 3 Supports Command Tag Queuing, synchronous and asynchronous data transfer, as well as disconnects and reconnects Bullet 4 Built-in 32-bit RISC SCSI engine handles command queue process and all interrupts, improving performance Bullet 5 Supports SCAM Level 1 for FLASH and Serial EEPROM devices Marketing Copy Applications Connect hard drives, CD-ROM drives, DVD drives, tape drives, scanners, and more to your PC Accessory Products - SCSI320INT
- SCSI320INT5
- SCSI320INT7
- SCSI320INT9
- SCSI3INT
- SCSI3INT5
- SCSI3INT5TWS
- SCSI3INT7
- SCSI25HP68_6
- SCSI2W1EXT
- SCSI2W2EXT
- SCSI2W2EXT_3
- SCSI33PEX4
- SCSI33PEX6
Related Products - PCISCSIUW
- PCISCSI2
- PCISCSI2U
TAA Compliant No General Specifications - Device Support: Up to 15 devices
- Device Protocol: Ultra2 Wide SCSI
- On Chip FIFO: 256-byte
- OS Support: Windows 3.x/9x/ME/NT 4/2000/XP/Server 2003, DOS, Netware, Linux and OS/2
- Voltage Support: Low Voltage Differential and SE card.
Maximum Data Transfer Rate 640000000 MBytes/Sec Bus Type PCI (5 Volt) Chipset ID Initio - INIC-1060P Carton Depth (mm) 455 Carton Height (mm) 310 Carton Weight Gross (g) 14469.5848 Included in Package - 1 - ULTRA2 WIDE SCSI CARD
- 1 - CONNECTING CABLE
- 1 - DRIVER DISK
- 1 - SCSI TERMINATOR
Package Depth (mm) 55 Package Height (mm) 146 Package Width (mm) 220 Package Weight (g) 330 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 HPDB68 SCSI-3 (68-Pin) Connector 1 (Quantity) 1 Connector 2 HPDB68 SCSI-3 (68-Pin) Connector 2 (Quantity) 1 en-US Content Approved Yes Product Manager Carey Cline
