PEX1000SFP2
PCIe GbE Fiber Card w Open SFP PCIe SFP Adapter
Connect a PCI Express-based desktop or rackmount PC directly to a fiber optic network using the Gigabit SFP of your choice
Main Image
Product Images
Product Images
Product Images
Product Name PCIe GbE Fiber Card w Open SFP PCIe SFP Adapter Product Number PEX1000SFP2 UPC 065030857383 Lifecycle status Active Warranty 2 Years Taxonomy Product > Cards & Adapters > Network Cards & Adapters Category Level 1 Networking Category Level 2 Desktop and Server Network Cards Category Level 3 Fiber Cards Family PCIe Gigabit NIC - Single Port Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX026X Product Title (Ultra-Short) PCIe SFP Fiber Card Product Title (Short) PCIe GbE Fiber Network Card w/ Open SFP Product Title (Medium) PCI Express Gigabit Ethernet Fiber Network Card w/ Open SFP - PCIe SFP Adapter Product Title (Standard) PCI Express Gigabit Ethernet Fiber Network Card w/ Open SFP, PCIe SFP Network Card Adapter NIC, TAA Product Title (Long) PCI Express Gigabit Ethernet Fiber Network Card w/ Open SFP - PCIe SFP Network Card Adapter NIC - TAA Product Title (AMZ) PCI Express Gigabit Ethernet Fiber Network Card w/ Open SFP - PCIe GbE SFP Network Card Adapter NIC - Fiber Optic SFP Adapter , TAA (PEX1000SFP2) Title Ingram (Part 1) PCIe GbE Fiber Card w/ Open SFP Title Ingram (Part 2) - PCI Express SFP Fiber Adapter Website Product Headline Connect a PCI Express-based desktop or rackmount PC directly to a fiber optic network using the Gigabit SFP of your choice Bullet 1 Compatible with most Gigabit SFP modules Bullet 2 Supports Full/Half-duplex Auto-Negotiation, Auto-MDI/MDIX Bullet 3 Compliant with IEEE802.3z 1000Base-SX/LX, IEEE 802.1Q VLAN Tagging, IEEE 802.1P Layer 2 Priority Encoding, IEEE 802.3x full duplex flow control, RFC 1157 SNMP v1 Bullet 4 Jumbo Frame Support Bullet 5 Preboot Execution Environment (PXE) 2.1 Bullets (Compact) Connect a PCI Express-based desktop or rackmount PC directly to a fiber optic network using the Gigabit SFP of your choice - SFP card - Full/Half-duplex - pcie network card - PCIe Ethernet card - Gigabit Ethernet Card w/ Open SFP - Gigabit fiber NIC Bullets (Consolidated) Connect a PCI Express-based desktop or rackmount PC directly to a fiber optic network using the Gigabit SFP of your choice - PCIe GbE Fiber Network Card with Open SFP Slot - PCIe SFP Network Card Adapter NIC - PCI Express SFP Adapter - Fiber Optic Network Card - PCI Express Open SFP Card - Gigabit SFP NIC - Includes low-profile/half-height installation bracket - Compatible with most Gigabit SFP modules - Jumbo Frame Support - Supports Full/Half-duplex Auto Negotiation and Auto MDI/MDIX Marketing Copy Applications - Ideal for secure setups - a direct fiber connection means no electronic interference, which can be a problem with RJ45 network cards
- Perfect for remote embedded industrial monitoring systems, and high-speed video surveillance
- Retain full Gigabit network speeds to a remote terminal over longer distances than copper cabling
Website Search Keyword - Fiber NIC
- Fiber Network Card
- PEX1000SFP
- fiber optic card
- sfp card
- sfp adapter
- fiber adapter
- pcie sfp
- pci express sfp
- sfp gigabit adapter
- sfp nic
- sfp network card
- open sfp
- fiber open sfp
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device + accessories
Special Notes - Fiber data transfer speeds and distances are dependent on the SFP used (sold separately)
- This product is not compatible with Copper SFP modules
System and Cable Requirements Not compatible with 100Mbps SFP transceivers, Gigabit SFP transceiver required Accessory Products - SFPG1320C
- SFPG1340C
- SFPG1580C
- SFPLHSM
- SFPGLCLHSMST
- SFPGLCSXMMST
- SFPGESST
Related Products - PEX1000MMST
- PEX1000MMSC
- PEX100SFP
- PCI100MMST
- PCI100MMSC
Constrained SKU Alternatives (Limited Stock) PEX10000SFPI Power Consumption (In Watts) 3.2W Max Color Green Humidity 5~95% RH (Non-Condensing) Material Steel Operating Temperature 0°C to 45°C (32°F to 113°F) Primary Material Steel Product Length (mm) 128.000 Product Width (mm) 18.000 Product Height (mm) 118.000 Product Weight (g) 57.000 Storage Temperature -20°C to 70°C (-4°F to 158°F) TAA Compliant Yes Auto MDIX Yes Buffer Size 48 KB Compatible Networks 1000 Mbps (1 Gbps) Full Duplex Support Yes Maximum Data Transfer Rate 2000 Mbps (2 Gbps) - Full-Duplex MTBF (hours) 770,619 hours OS Compatibility - Windows 8
- Windows 7
- Windows Server 2012
- Mac OS X Mavericks (10.9)
- Linux
- Windows 10
- Windows Server 2016
- Windows Server 2019
- Windows 11
- Windows Server 2022
Bus Type PCI Express Card Type Standard Profile (LP bracket incl.) Chipset ID Industry Standards IEEE802.3z 1000BASE-SX/LX, IEEE 802.1Q VLAN tagging, IEEE 802.1P Layer 2 Priority Encoding, IEEE 802.3x full duplex flow control, RFC 1157 SNMP v1 Interface/Bridge Fiber Ethernet LED Indicators - 1 - Link (Green)
- 1 - Activity (Yellow)
Carton Depth (mm) 599 Carton Height (mm) 379 Carton Quantity 50 Carton Weight Gross (g) 10684 Included in Package - 1 - 1 Port PCI Express Gigabit SFP Network Card
- 1 - Low-Profile Bracket
- 1 - Instruction Manual
Package Depth (mm) 174 Package Height (mm) 52 Package Width (mm) 213 Package Quantity 1 Package Weight (g) 180 Packaging Description PCIe Gigabit Fiber Network Card w/ Open SFP Packaging Description India PCIe Gigabit Fiber Network Card w/ Open SFP Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 PCI Express x1 Connector 1 (Quantity) 1 Connector 2 SFP Slot Connector 2 (Quantity) 1 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2014-04-14 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge Yes Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,DE,DK,ES,EU,FR,IE,IN,IT,JP,NL,NZ,SE,SG,UK,US Primary Technology None Product Development Specialist Ray Aoki Product Information Creation Specialist (PICS) Alex Garcia Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Tech Lead Stefan Tirolese Technical Writer Andrew Richardson Technology Lifecycle None
