PEX13943
4 Port PCIe IEEE 1394a FireWire 400 Adapter Card
Add 4 FireWire port to a desktop computer through PCI Express
Main Image
Product Images
Product Images
BOM Image
Product Name 4 Port PCIe IEEE 1394a FireWire 400 Adapter Card Product Number PEX13943 UPC 065030823852 Lifecycle status Discontinued Warranty Lifetime Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX072X Product Title (Short) 4 Port PCIe 1394a FireWire Adapter Card Product Title (Standard) StarTech.com 3 + 1 Internal Port PCI Express FireWire adapter Card PEX13943 - FireWire adapter - PCI Express x1 - Firewire - 3 ports Product Title (Long) 4 Port PCI Express 1394a FireWire Adapter Card - 3 External 1 Internal Product Title (AMZ) 4 Port PCI Express 1394a FireWire Adapter Card - 3 External 1 Internal - PCI Express 1394a - PCIe 400 FireWire Card (PEX13943) Title Ingram (Part 1) 4 Port PCI Express 1394a FireWir Title Ingram (Part 2) e Adapter Card - 3 Ext 1 Int Website Product Headline Add 4 FireWire port to a desktop computer through PCI Express Bullet 1 3 external, 1 shared internal FireWire400 port, with supported data transfer rates up to 400 Mbps Bullet 2 Compliant with IEEE 1394a - 2000, 1394-1995 standards and OpenHCI 1.0/1.1 Bullet 3 Includes Low Profile installation bracket Bullet 4 PCI Express base specification 1.0a compliant Bullet 5 Plug-and-Play and hot-swap compatible Marketing Copy Applications - Add a high-speed FireWire port to a full or small form factor desktop without any FireWire ports
- Connect a digital camera to a desktop with a PCI Express slot to download photos and video
- Connect a external FireWire hard drive or optical drive to a PCI Express-enabled system
Website Search Keyword - pci express
- PCIe firewire 400
- 1394a
Microsoft WHQL Certified Yes Special Notes If internal port is used, one external port will be disabled. Only three ports will function simultaneously. System and Cable Requirements Unused PCI slot Accessory Products - 1394_10
- 1394_15
- 1394_46_10
- 1394_46_15
- 1394_46_6
- 1394_6
- FIRE46FM
Related Products - PCI1394_2LP
- PCI1394_4
- PCI1394B_3
- PEX1394B3
Product Length (mm) 90 Product Width (mm) 19 Product Height (mm) 70 Product Weight (g) 60 TAA Compliant No Maximum Data Transfer Rate 400 Mbps OS Compatibility - Windows Server 2012
- Mac OS X Mavericks (10.9)
- Windows 7
- Windows 8
Bus Type PCI Express Card Type Standard Profile (LP bracket incl.) Chipset ID Renesas/NEC - D72874 Industry Standards - IEEE 1394/1394a
- OHCI
Interface/Bridge FireWire 400 (1394a) Carton Depth (mm) 515 Carton Height (mm) 320 Carton Quantity 40 Carton Weight Gross (g) 6700 Included in Package - 1 - PCI Express FireWire Card
- 1 - Instruction Manual
- 1 - Low Profile Bracket
Package Depth (mm) 68 Package Height (mm) 180 Package Width (mm) 172 Package Weight (g) 110 Packaging Description 4 Port PCIe 1394a FireWire Card Packaging Description India 4 Port PCIe 1394a FireWire Card Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 PCI Express x1 Connector 1 (Quantity) 1 Connector 2 FireWire 400 (6-Pin, 400Mbps, Bus Power) Connector 2 (Quantity) 3 Connector 3 FireWire 400 (6-Pin, 400Mbps, Bus Power) Connector 3 (Quantity) 1 en-US Content Approved Yes Product Manager Rafal Gwozdz
