Main Image
PEX2S650
Main Image
Product Images
Product Images
Product Images
Product Name 2 Port 16650 PCI-E WHQL Approved Serial Card Product Number PEX2S650 UPC 065030820417 Lifecycle status Discontinued Warranty Lifetime Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Product Title (Long) 2 Port 16650 PCI-E WHQL Approved Serial Card Bullet 1 128K transmit/receive FIFO buffer helps improve overall system performance Bullet 2 Uses 1x PCI Express lane and compatible with 1x, 2x, 4x, 8x, and 16x lanes Bullet 3 High speed serial data transfers up to 920Kbps (depending on Operating System) Bullet 4 Microsoft WHQL certified drivers Bullet 5 Supports DOS/Windows 3.x/9x/NT/ME/CE/2000/XP/2003/XP x64/2003 x64/Vista and Linux 2.4.x/2.6.x Marketing Copy Get more out of your serial devices! StarTech.com’s PEX2S650 is a PCI Express serial card with WHQL certified drivers. Great for connecting any new or old serial peripheral, with data transfer rates of up to 920 Kbits/sec. Perfect for connecting serial modems, POS devices, PDAs, digital cameras, printers, ISDN terminal adapters and more, to your system. Installation is a breeze with support for Windows® Vista, XP, Server 2003, 2000, ME, 98, 95, NT4, 3.1, DOS® and Linux®. Guarantee convenient, hassle-free connections. Backed by StarTech.com’s lifetime warranty and FREE LIFETIME tech support. Applications - Casino (video lottery terminals, slot machines)
- Consumer (modems, PDAs, digital cameras, printers)
- Environmental Control (lighting, temperature, clocks)
- Healthcare (patient monitoring equipment, nurses' stations, modems)
- Hospitality/Restaurant (credit card/debit card reader, serial printers)
- Hotel Front Desk (serial printers, bar code scanners, keyboard, mouse, receipt printer, credit/debit card reader)
- ISDN Networking
- Manufacturing (CNC machinery, process control equipment, bar code scanners, serial printers)
- POS (credit/debit card readers, receipt printers, bar code scanners, cash registers, scales)
- Security (UPS control, access key panels, video cameras, card readers, modems)
Website Search Keyword - PCI-E Serial Card
- PCI Express Serial Card
- WHQL Certified Serial Card
- RoHS
Microsoft WHQL Certified Yes Accessory Products - AT925FF
- AT925FM
- AT925SFM
- MC3MF
- MC6MF
- MXT100
- MXT100_25
- MXT100FF
- MXT100MM
- SCNM925FM
- SCNM9FF
- SCNM9FF25
- SCNM9FM
Related Products - PCI1S550
- PCI2S550
- PCI4S650DV
- PCI8S650DV
Replacement Product PEX2S1050 Operating Temperature 0-60 Product Length (mm) 151 Product Width (mm) 71 Product Weight (g) 84 Storage Temperature 20-85 TAA Compliant No General Specifications - Data Transfer Rate (max): 920 Kbits
- Compatible OS: DOS, Windows 95, 98, ME, NT; Windows XP (32-bit, 64-bit), Windows Vista (32-bit, 64-bit), Linux
- Bus Type: PCI Express 1x, compatible with 2x, 4x, 8x, and 16x lanes
- Other Specs: IRQ and I/O Address assigned by BIOS
- Data bits: 5,6,7,8
- Stop bits: 1, 1.5, 2
- Parity: Even, Odd, None, Mark, Space
- Flow Control: None, Xon/Xoff, Hardware
- Chipset: Sunix SUN1889
OS Compatibility Windows Vista Bus Type PCI Express Chipset ID Sunix - SUN1889 Carton Depth (mm) 755 Carton Height (mm) 240 Carton Quantity 50 Carton Weight Gross (g) 10700 Included in Package - 1 - 2 Port PCI-E Serial I/O Card
- 1 - Driver CD
- 1 - Instruction Manual
Package Depth (mm) 39 Package Height (mm) 142 Package Width (mm) 210 Package Weight (g) 190 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 DB-9 Serial Connector 1 (Quantity) 2 en-US Content Approved Yes Product Manager Carey Cline
