3 Port USB 2.0 and 3 Port Firewire 800 Card

Main Image

Product Name	3 Port USB 2.0 and 3 Port Firewire 800 Card
Product Number	PEX3U3F800
UPC	065030817806
Lifecycle status	Discontinued
Warranty	Lifetime
Taxonomy	Product > Legacy Discontinued
Category Level 1	Legacy Category
Category Level 2	Legacy Sub-Category
Category Level 3	Legacy Group
Country of Origin Europe & Japan	Taiwan
Country of Origin North America	Taiwan

Manual https://images.salsify.com/image/upload/s--76tfh4VP--/5ad81fb993d0358759e63079bfa2c50b5850b4c4.pdf

Product Title (Long)	3 Port USB 2.0 and 3 Port IEEE-1394b FireWire Slot Saver PCI Express Card
Bullet 1	Backward compatible with USB 1.1 devices
Bullet 2	Compliant with PCI specification 2.2
Bullet 3	Hot swap capabilities let you connect peripherals without rebooting
Bullet 4	Installs easily into a single PCI slot
Bullet 5	Three external (plus one internal) USB 2.0 ports with data transfer rates up to 480 Mbits/sec
Marketing Copy
Applications	Connect to a wide range of USB 2.0/1.1 and IEEE-1394 FireWire® devices including CD-RW/DVD-ROMs, removable hard drives, video cameras, hubs, digital camcorders/cameras and MP3 players/iPods
Website Search Keyword	iPod pci express

General Specifications	Bus Interface: PCI Express FireWire: 1 x 9 pin 1394B FireWire: 1394A & 1394B FireWire: 2 x 9 pin 1394B IEEE 1394A Devices: Up to 800 Mbits/sec PCI: PCI Express USB 1.1/1.0 Devices: Up to 12 Mbits/sec USB 2.0 Devices: Up to 480 Mbits/sec USB: 1 x 4 pin USB Type A USB: 3 x 4 pin USB Type A USB: EHCI and OHCI Compliant
Maximum Data Transfer Rate	800000000 Kbits/Sec
OS Compatibility	Windows Vista

Connector 1 FireWire 800 (9-Pin, 800Mbps, Bus Power)
Connector 1 (Quantity) 3
Connector 2 USB-A (480Mbps, 2.5W)
Connector 2 (Quantity) 4
en-US Content Approved Yes
Product Manager Carey Cline

Accessory Products	1394_10 1394_15 1394_6 1394_6FLBG 1394_6LEDBL PYO2SL USB2HAB10 USB2HAB15 USB2HAB6 USB2HAB6LEDB USB2HAB6LEDR
Related Products	CB2U2F PCISAT2F3U4

en-US Content Approved	Yes
Product Manager	Carey Cline
