PEXPESAT2
2 Port PCI Express Dual Profile 5/12V Power eSATA Controller Adapter Card
2 Port Powered eSATA(USB2.0 + eSATA) Controller Card
Main Image
Product Images
Product Images
Product Images
Product Images
Product Name 2 Port PCI Express Dual Profile 5/12V Power eSATA Controller Adapter Card Product Number PEXPESAT2 UPC 065030836715 Warranty 2 Years Taxonomy Product > Legacy Discontinued Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) 1 Country of Origin History (2) Taiwan Product Title (Short) 2 Port PCIe Power eSATA Controller Card Product Title (Standard) StarTech.com 2 Port PCI Express Dual Profile 5/12V Power eSATA Controller Adapter Card Product Title (Long) 2 Port PCI Express Dual Profile 5/12V Power eSATA Controller Adapter Card Title Ingram (Part 1) 2 Port PCI Express 5/12V Power e Title Ingram (Part 2) SATA Controller Adapter Card Website Product Headline 2 Port Powered eSATA(USB2.0 + eSATA) Controller Card Bullet 1 Compliant with PCI Express x1 (Single Lane) Specification 1.0a Bullet 2 Native PCI Express single chipset Bullet 3 Port multiplier capable Bullet 4 Supports data transfer speeds up to 3.0 Gbps with SATA II (480Mbps with USB 2.0) Bullet 5 Supports hot-swappable device installations Marketing Copy Applications - Connects to eSATA SSD Flash drives, such as OCZ Throttle, Kangaru e-Flash drives and Ridata Racer series flash drives
- Enables you to power an external HDD enclosure that has compatible power eSATA (eSATA+USB) interface
Website Search Keyword - eSATA + USB interface card
- eSATA Controller + USB
- eSATA controller Card
- eSATA plus USB interface card
- eSATA USB Card
- eSATA USB Combo Port
- eSATA+USB
- power esata
- power esata flash drives
- power over esata
- powered esata
- usb esata combo port
- usb+esata combo
- 12v Power eSATA
- 5V Power eSATA
Microsoft WHQL Certified Yes Accessory Products - ESATAUSB3
- ESATAUSBBO
- ESATAUSBBO3
Related Products - CBESATA2
- ECESATA22
- ECESATA254
- PCIESATA2I
- PEXESATA1
- PEXESATA2
- PEXESATA2I
- ECESATUSB1
Humidity 95% RH Operating Temperature 0°C to 55°C (32°F to 131°F) Product Length (mm) 120 Product Width (mm) 67.5 Product Height (mm) 18 Product Weight (g) 45.25 Storage Temperature -20°C to 85°C (-4°F to 185°F) TAA Compliant No Maximum Data Transfer Rate 3Gbps via eSATA, 480Mbps via USB 2.0 OS Compatibility - Linux
- Windows 2000
- Windows Vista
- Windows XP
- Mac OS X
Port Multiplier Yes Bus Type PCI Express Card Type Standard Profile (LP bracket incl.) Chipset ID Silicon Image - SiI3532 LED Indicators 1 - eSATA Activity Included in Package - 1 - PCI Express 2 Port Power eSATA card
- 1 - Software and Drive CD
- 1 - Manual
- 1 - 9 pin IDC motherboard header cable M/M
- 1 - Low Profile Bracket
Connector 1 Powered eSATA (11-Pin) Connector 1 (Quantity) 2 Connector 2 IDC (9-Pin) Connector 2 (Quantity) 1 Connector 3 SP4 / Floppy Power (4-Pin, 5V / 12V) Connector 3 (Quantity) 1 en-US Content Approved Yes
