Main Image
PEXUSB312A2C2V
4 Port PCI Express USB 3 1 Gen 2 Card with 2 channels 2x U
2x USB 3.2 Gen 2 (10Gbps) Type-A | 2x USB 3.2 Gen 2 (10Gbps) Type-C
Main Image
Product Images
Product Images
Product Images
Product Images
Product Images
Product Name 4 Port PCI Express USB 3 1 Gen 2 Card with 2 channels 2x U Product Number PEXUSB312A2C2V UPC 065030887076 Lifecycle status Active Warranty 2 Years Taxonomy Product > Cards & Adapters > USB Cards Category Level 1 Computer Cards and Adapters Category Level 2 USB Cards and Extenders Category Level 3 USB-C Cards - 10Gbps Family USB-C Cards - 10Gbps - PCIe Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX051X Product Title (Ultra-Short) 4-Port USB PCIe Card Product Title (Short) 4Port USB PCIe Card 10Gbps USB 3.1 2C/2A Product Title (Medium) 4-Port USB PCIe Card, 10Gbps USB 3.1 w/ 2 Controllers, 2x USB-C & 2x USB-A ports Product Title (Standard) 4-Port USB PCIe Card, 10Gbps USB PCI Express Expansion Card w/2 Controllers, 2x USB-C & 2x USB-A ports (USB 3.2 Gen 2), TAA Product Title (Long) 4-Port USB PCIe Card - 10Gbps USB PCI Express Expansion Card w/ 2 Controllers - 2x USB-C & 2x USB-A ports (USB 3.2 Gen 2) - USB/USB-C PCI-e Card - Full Profile - TAA Product Title (AMZ) 4-Port USB PCIe Card - 10Gbps USB PCI Express Expansion Card w/ 2 Controllers - 2x USB-C & 2x USB-A ports (USB 3.2 Gen 2) - USB/USB-C PCI-e Card - Full Profile , TAA (PEXUSB312A2C2V) Title Ingram (Part 1) 4-Port USB PCIe Card - 10Gbps Title Ingram (Part 2) 2x USB-C and 2x USB-A Ports Website Product Headline 2x USB 3.2 Gen 2 (10Gbps) Type-A | 2x USB 3.2 Gen 2 (10Gbps) Type-C Bullet 1 HIGH PERFORMANCE: 4 Port USB PCIe card with dual ASM3142 controllers with up to 20Gbps total bandwidth across 4 ports; 2x USB-A (10Gbps) 2x USB-C (10Gbps) hub; Supports USB 3.2 Gen 2 Bullet 2 TRANSFER SPEEDS UP TO 10Gbps: USB-A & USB-C PCIe card adapter supports Multiple INs maintaining max bandwidth with mixed speed devices; UASP support; ideal for use with USB devices & external storage like SSDs, HDDs, NVMe drives; Works w/ USB 3.2 Gen 2/3.0/2.0 Bullet 3 OPTIONAL POWER: USB PCIe expansion card with SATA power supplies supplemental power to the USB ports (when motherboard power is insufficient) providing up to 5V 3A/15W per USB Type-C port & 5V 0.9A/4.5W per USB Type-A port Bullet 4 COMPATIBILITY: USB C add-on card installs in full-profile PCIe 3.0 (x4 slot) desktop/server; lower performance with PCI-e 2.0; Windows/Linux/macOS auto driver install (Windows 8 & up) Bullet 5 STARTECH.COM ADVANTAGE: IT professionals choice for over 30 years; These this USB-A & USB-C combo PCI Express Host Controller card is backed for 2-years by StarTech.com, including free 24/5 North America based multi-lingual tech support Bullets (Compact) 4 Port USB PCIe Card (USB 3.2 Gen 2) - 2x ASM3142 controllers up to 20Gbps total - PCI Express expansion card; 10Gbps 2x USB-A/2x USB-C - Multiple INs - For USB/USB Type-C devices/SSD/NVMe - Optional SATA power - PCI-e 3.0 x4 slot; Full profile Bullets (Consolidated) USB PCIe card with 2x ASM3142 chips for up to 20Gbps bandwidth total across 4 ports (2 ports/controller) - PCI Express adapter card (USB 3.2 Gen 2) | 10Gbps 2x USB-A / 2x USB-C hub - Expansion card supports Multiple INs maintaining max bandwidth w/mixed speed devices | For USB devices/external storage SSDs/NVMe - Optional SATA power for up to 15W per USB Type-C port and 4.5W per USB-A port - Install in PCI-e 3.0 x4 slot (desktop/server) | Full profile bracket | Windows/Linux/macOS Marketing Copy Applications - Upgrade an older PCIe equipped desktop from USB 5Gbps/480Mbps to USB 10Gbps with 2x Type-A and 2x Type-C
- Ideal for file backups, video editing, and data recovery, using high-bandwidth USB 10Gbps external storage solutions
- Expand the USB capabilities of your system with two USB-C ports and two USB-A ports, or install the card as a vital hardware component when building a new PC
Website Search Keyword - 10 gbps pcie card
- 10gbps pcie
- 10gbps pcie card
- 4 port usb 3.1 card
- 4 port usb 3.1 pcie card
- 4 port usb pci express card
- 4 port usb pcie card
- allegro pro usb 3.1 pcie
- expansion card
- express card usb 3.1
- pci card usb 3.1 gen 2
- pci e usb 3.1 card
- pci express add in card
- pci express add on card
- pci express card
- pci express expansion card
- pci express to usb
- pci express usb 3.1 card
- pci express usb 3.1 gen 2
- pci express usb card
- pci express usb controller
- pci express usb hub
- pci to usb
- pci to usb adapter
- pci to usb converter
- pci usb card
- pcie 3.0 usb card
- pcie add in card
- pcie add on card
- pcie to usb
- pcie to usb 3.1
- pcie to usb 3.2
- pcie to usb c
- pcie to usb type c
- pcie usb 3.0 card
- pcie usb 3.1
- pcie usb 3.1 card
- pcie usb 3.1 gen 2
- pcie usb 3.1 gen 2 card
- pcie usb 3.2
- pcie usb 3.2 gen 2 card
- pcie usb c card
- pcie usb card
- pcie usb hub
- usb 2.0 pcie expansion card
- usb 3 pcie card
- usb 3.0 pci card
- usb 3.0 pci expansion card
- usb 3.0 pcie expansion card
- usb 3.1 adapter card
- usb 3.1 add in card
- usb 3.1 add on card
- usb 3.1 card
- usb 3.1 controller
- usb 3.1 controller card
- usb 3.1 expansion card
- usb 3.1 gen 2 add in card
- usb 3.1 gen 2 card
- usb 3.1 gen 2 controller
- usb 3.1 gen 2 expansion card
- usb 3.1 gen 2 hub controller
- usb 3.1 gen 2 pcie
- usb 3.1 gen 2 pcie card
- usb 3.1 gen2 pcie card
- usb 3.1 hub controller
- usb 3.1 pci adapter
- usb 3.1 pci card
- usb 3.1 pci express
- usb 3.1 pci express card
- usb 3.1 pcie adapter
- usb 3.1 pcie add on card
- usb 3.1 pcie card
- usb 3.1 pci-e card
- usb 3.1 pcie card for mac
- usb 3.1 pcie card mac pro
- usb 3.1 pcie expansion card
- usb 3.1 to pcie adapter
- usb 3.1 type a card
- usb 3.1 type c card
- usb 3.1 type c pcie card
- usb 3.2 gen 2 expansion card
- usb 3.2 pci express card
- usb 3.2 pcie
- usb 3.2 pcie card
- usb c expansion card
- usb c pci e card
- usb c pci express card
- usb c pcie
- usb c to pcie
- usb card for desktop
- usb pci e card
- usb pci express card
- usb pcie expansion card
- usb to pci express adapter
- usb to pcie
- usb to pcie adapter
- usb type c expansion card
- usb type c pci express
- usb type c pcie
- usb type c to pcie
- asrock model usb 3.1/a+c card
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
Accessory Products - SATAPOWADAP
- USB31CAADP
- USB31AC1M
- USB31CUB1M
- S252BU313R
- USB3SAUB1
- USB3SAB6
- USB3SPLATE
Related Products - PEXUSB3S2EI
- PEXUSB311EI
- PEXUSB312C
- PEXUSB311A1C
- PEXUSB312A
- PEXUSB3S44V
- ECUSB3S11
- PEXUSB312A1C1H
- PEXUSB314A2V2
- PEXUSB312C3
- PEXUSB312A3
Color Red Humidity 15~90% RH (Non-condensing) Operating Temperature 0°C to 70°C (32°F to 158°F) Primary Material PCB Product Length (mm) 124.000 Product Width (mm) 122.000 Product Height (mm) 18.000 Product Weight (g) 78.000 Storage Temperature -20°C to 80°C (-4°F to 176°F) TAA Compliant Yes Maximum Data Transfer Rate 10Gbps MTBF (hours) 1,677,495 Hours OS Compatibility - Linux
- Windows 8
- Windows 7
- Windows 10
- Windows Server 2012
- Windows Server 2016
- Windows Server 2019
- macOS Catalina (10.15)
- macOS Mojave (10.14)
- macOS High Sierra (10.13)
- macOS Big Sur (11.0)
- Windows Server 2012 R2
- Windows 11
- macOS Monterey (12.0)
- macOS Ventura (13.0)
- Windows Server 2022
- macOS Sonoma (14.0)
- macOS Sequoia (15.0)
- macOS Tahoe (26.0)
Total USB Power Output UASP Support Yes USB Speed USB 3.2 Gen 2 (10Gbps) USB Type and Rate USB 10Gbps Bus Type PCI Express Card Type Standard Profile Chipset ID - ASMedia - ASM3142
- ASMedia - ASM2806
Industry Standards - PCI Express Base Specification Rev. 3.0
- USB 3.2 Specifications
- UASP (USB Attached SCSI Protocol) Rev. 1.0
Interface/Bridge PCI Express IO Card Port Style Integrated on Card USB Port Type - USB-A
- USB-C
Carton Depth (mm) 374 Carton Height (mm) 500 Carton Quantity 60 Carton Weight Gross (g) 10500 Included in Package - 1 - PCI Express USB Card
- 1 - Full Profile Bracket (Installed)
- 1 - Product Documentation
Included In Package for Label - 1 - PCI Express USB Card
- 1 - Full Profile Bracket (Installed)
- 1 - Product Documentation
Number of Sub-Cartons 6 Package Depth (mm) 142 Package Height (mm) 34 Package Width (mm) 175 Package Quantity 1 Package Weight (g) 144 Packaging Description 4-Port USB 3.2 (10Gbps) Card - 2 Controllers Packaging Description India 4-Port USB 10Gbps Card - 2 Controllers Sub-Carton Depth (mm) 358 Sub-Carton Height (mm) 155 Sub-Carton Width (mm) 168 Sub-Carton Quantity 10 Sub-Carton Weight (g) 160 Connector 1 PCI Express x4 Connector 1 (Quantity) 1 Connector 2 USB-A (10Gbps, 4.5W) Connector 2 (Quantity) 2 Connector 3 USB-C (10Gbps, 4.5W) Connector 3 (Quantity) 2 Connector 4 SATA (15-Pin) Connector 4 (Quantity) 1 Actual Inbox Documents Created Compliance Insert Amazon Merchandising Manager Veronica Ye Artwork Due Date 2020-11-05 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute No Buying Center - Networking & Edge Yes Digital Content Due Date 2021-05-20 Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett ID Label Silkscreened or a Label No ID label Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,DE,DK,ES,FI,FR,IE,IN,IT,JP,NL,SE,SG,UK,US Primary Technology - USB-C
- USB 3.2 Gen 2 / 10Gbps
Product Development Specialist Scott Dunlop Product Information Creation Specialist (PICS) Alex Garcia Product Manager Natalie Goodale Product Performance Specialist Aaron Bens Product Photographer Alejandra Valencia Target Development Completion Date 2021-01-15 Target Production Release 2021-02-04 Tech Lead Brian Linseman Technical Writer Alex Garcia Technology Lifecycle None
