Main Image
PEXUSB312A3
2 Port USB 3 1 PCI e Card 2x A 10Gbps PCIe Card
USB 3.2 Gen 2 (10 Gbps) | PCI-Express 3.0 | PCIe x4 Slot | USB Type-A
Main Image
Product Images
Product Images
Product Images
Quick-Start Guide
Product Name 2 Port USB 3 1 PCI e Card 2x A 10Gbps PCIe Card Product Number PEXUSB312A3 UPC 065030887427 Lifecycle status Active Warranty Lifetime Taxonomy Product > Cards & Adapters > USB Cards Category Level 1 Computer Cards and Adapters Category Level 2 USB Cards and Extenders Category Level 3 USB-A Cards - 10Gbps Family USB-A Cards - 10Gbps Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX076X Country of Origin History (2) Malaysia Country of Origin Revision (2) XXXXXX156X Product Title (Ultra-Short) USB 3.2 Gen 2 Card Product Title (Short) 2 Port USB PCIe Card 10Gbps/port - USB-A Product Title (Medium) 2-Port USB 3.2 Gen 2 PCIe Card - USB-A SuperSpeed 10Gbps PCI Express 3.0 x4 Product Title (Standard) 2-Port USB PCIe Card 10Gbps/port - USB 3.2 Gen 2 Type-A PCI Express 3.0 x4 Host Controller Expansion Card - Windows/Linux Product Title (Long) 2-Port USB PCIe Card with 10Gbps/port - USB 3.2 Gen 2 Type-A PCI Express 3.0 x4 Host Controller Expansion Card - Add-On Adapter Card - Full/Low Profile - Windows & Linux Product Title (AMZ) 2-Port USB PCIe Card with 10Gbps/port - USB 3.2 Gen 2 Type-A PCI Express 3.0 x4 Host Controller Expansion Card - Add-On Adapter - Full/Low Profile - Windows & Linux (PEXUSB312A3) Title Ingram (Part 1) USB 3.2 Gen 2 PCIe Card - Title Ingram (Part 2) USB Type-A 10Gbps PCI Express x4 Website Product Headline USB 3.2 Gen 2 (10 Gbps) | PCI-Express 3.0 | PCIe x4 Slot | USB Type-A Bullet 1 HIGH PERFORMANCE: 2-Port USB PCIe Card with ASMedia ASM3142 host controller (PCIe 3.0 x4) has two SuperSpeed 10Gbps USB-A ports (USB 3.2 Gen 2); Speeds up to 10Gbps/port; Upgraded version of our popular USB card PEXUSB312A2 Bullet 2 MAXIMIZED USB PERFORMANCE: Add-on card supports Multiple Ins for max bandwidth when using mixed-speed devices; Supports UASP & optimized for SSDs/HDDs, NVMe, thumb drives; Supports USB 3.2 Gen 1/2.0 devices Bullet 3 POWER: USB PCI Express 3.0 expansion card w/ SATA power header supplies supplemental power to the USB ports (when motherboard power is insufficient) providing up to 4.5W (5V @ 0.9A) per USB-A port Bullet 4 COMPATIBILITY: USB PCIe adapter card installs in full or low-profile PCIe 3.0 x4 slot and up; Bracket included; Backward compatible w/ PCIe 2.0; Supports Win/Linux/macOS w/auto drivers on Win 8 & up Bullet 5 STARTECH.COM ADVANTAGE: IT professionals' choice for over 30 years; This USB-A PCI-e card for desktop is backed for life by StarTech.com, incl. free 24/5 North America based multi-lingual tech support Bullets (Compact) 2-port USB PCIe card - ASM3142 host controller for 2x USB-A ports up to 10Gbps/port - USB 3.2 Gen 2 PCI Express 3.0 x4 expansion card - Add-on adapter card supports Multiple Ins - Opt. SATA power - Full or low-profile bracket - Win/Linux/macOS Bullets (Consolidated) USB PCIe card has ASM3142 controller (PCIe 3.0 x4) w/2x USB-A ports | Up to 10Gbps/port | USB 3.2 Gen 2 expansion card | New version of PEXUSB312A2 - USB PCI Express adapter card supports Multiple INs for max bandwidth w/mixed-speed devices - UASP optimizes performance w/ SSDs/HDDs/NVMe drives | Supports USB 3.2 Gen 1/2.0 devices - SATA power header provides up to 4.5W/port - Add-on card w/ full or low-profile bracket incl. | Win/Linux/macOS and auto drivers on Win 8 and up - Lifetime warranty Marketing Copy Applications Connect high-performance devices like NVMe drives and SSDs Website Search Keyword - 10gbps pcie card
- 2 port usb card
- low profile usb card
- usb 3.1 gen 2 expansion card
- usb 3.1 gen 2 pcie card
- usb 3.2 pcie card
- usb add on card
- usb host controller card
- usb pci express card
- usb pcie adapter
- usb pcie card
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- UKCA - Environmental - United Kingdom - UK Restriction of Hazardous Substances (RoHS) 2012
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- TSCA - Environmental - United States - EPA TSCA Title VI Compliant
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- Triman/Info-Tri - Manual - Waste - European Union - Print Paper
- Triman/Info-Tri - Product - Waste - European Union - EEE Device + accessories
- Triman/Info-Tri - Packaging - Waste - European Union - Paper Box + plastic bag + Paper/foam divider/tray
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
System and Cable Requirements - PCI Express enabled computer or server with a PCI Express x4 slot or higher (x8, x16)
- Optional SATA power connector
- The maximum throughput of this card is limited by the bus interface. PCI Express Gen 1.0 max throughput is 2.5Gbps. PCI Express Gen 2.0 and Gen 3.0 max throughput is 10Gbps
Accessory Products - USB31AC1M
- SATAPOWADAP
- USB3SAB10
- S251BPU313
- S351BU313
- USB3SAA6
- USB3SAUB1
- USB3SAB6
- USB3AUB2MS
- ST7300USB3B
- ST7300U3M
- USB3AU1MLS
- USB3AU1MRS
- USB3AUB1MS
- USB3CAB1M
- USB3CAUB1M
- RUSB2AC1MB
Related Products - PEXUSB311A1C
- PEXUSB311EI
- PEXUSB3S42
- PEXUSB3S7
- PEXUSB3S2EI
- PEXUSB3S44V
- PEXUSB3S3GE
- ECUSB3S11
- PEXUSB312A1C1H
- PEXUSB312C3
- PEXUSB314A2V2
- PEXUSB312A2C2V
- PEXUSB311AC3
- PEXUSB313A1C
Color Black Humidity 20%~80% RH Operating Temperature 5°C to 50°C (41°F to 122°F) Product Length (mm) 100.000 Product Width (mm) 120.000 Product Height (mm) 19.000 Product Weight (g) 65.000 Storage Temperature -20°C to 60°C (-4°F to 140°F) TAA Compliant No Maximum Data Transfer Rate 10Gbps OS Compatibility - Linux
- Windows 7
- Windows 8.1
- Windows 10
- Windows Server 2012 R2
- Windows Server 2016
- Windows Server 2019
- macOS High Sierra (10.13)
- macOS Mojave (10.14)
- macOS Catalina (10.15)
- Windows 8
- macOS Big Sur (11.0)
- Windows 11
- macOS Monterey (12.0)
- macOS Ventura (13.0)
- Windows Server 2022
- macOS Sonoma (14.0)
- macOS Sequoia (15.0)
- macOS Tahoe (26.0)
Total USB Power Output 4.5W (5V @ 0.9A) nominal, per port - Current draw above 2.0A (10W) will initiate Over-Current Protection UASP Support Yes USB Speed USB 3.2 Gen 2 (10Gbps) USB Type and Rate USB 10Gbps Bus Type PCI Express Card Type Standard Profile (LP bracket incl.) Chipset ID ASMedia - ASM3142 Industry Standards - USB 3.2 Specification
- PCI Express Base Specification Rev. 3.0
- Intel xHCI Specification Rev. 1.1
- UASP (USB Attached SCSI Protocol) Rev. 1.0
Interface/Bridge PCI Express x4 IO Card Port Style Integrated on Card USB Port Type USB-A Carton Depth (mm) 452 Carton Height (mm) 317 Carton Quantity 40 Carton Weight Gross (g) 6214 Included in Package - 1 - USB 3.1 Card
- 1 - Low-Profile Bracket
- 1 - Quick Start Guide
- 1 - Full-Profile Bracket (Pre-Installed)
Included In Package for Label - 1 - Quick Start Guide
- 1 - Low-Profile Bracket
- 1 - USB 3.1 Card
- 1 - Full-Profile Bracket (Pre-Installed)
Package Depth (mm) 216 Package Height (mm) 35 Package Width (mm) 146 Package Quantity 1 Package Weight (g) 140 Packaging Description 2-Port USB 3.1 Card - 10Gbps per port - 2x USB-A - PCIe Packaging Description India 2-Port USB 3.1 Card - 10Gbps per port - 2x USB-A - PCIe Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 PCI Express x4 Connector 1 (Quantity) 1 Connector 2 USB-A (10Gbps, 4.5W) Connector 2 (Quantity) 2 Connector 3 SATA (15-Pin) Connector 3 (Quantity) 1 Amazon Merchandising Manager Veronica Ye Artwork Due Date 2020-09-24 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute No Buying Center - Networking & Edge Yes Digital Content Due Date 2021-01-07 Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett ID Label Silkscreened or a Label No ID label Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,DE,DK,ES,FI,FR,IE,IN,IT,JP,NL,NZ,SE,SG,UK,US Primary Technology None Product Development Specialist Scott Dunlop Product Information Creation Specialist (PICS) Alex Garcia Product Manager Natalie Goodale Product Performance Specialist Aaron Bens Product Photographer Alejandra Valencia Target Development Completion Date 2020-03-26 Target Production Release 2020-09-24 Tech Lead Brian Linseman Technical Writer Alex Garcia Technology Lifecycle None
