PEXUSB3S42V
4Port PCIe USB 3 0 Controller Card w 2 Channels
Add four USB 3.0 (USB 3.2 Gen 1) ports with two independent channels, LP/SATA power, and charging support to your PC through a PCI Express slot
Main Image
Product Images
Product Images
Product Images
BOM Image
Product Name 4Port PCIe USB 3 0 Controller Card w 2 Channels Product Number PEXUSB3S42V UPC 065030854597 Lifecycle status Active Warranty 2 Years Taxonomy Product > Cards & Adapters > USB Cards Category Level 1 Computer Cards and Adapters Category Level 2 USB Cards and Extenders Category Level 3 USB-A Cards - 5Gbps Family USB-A Cards - 5Gbps - PCIe Country of Origin Europe & Japan Malaysia Country of Origin North America Malaysia Country of Origin History (1) China Country of Origin Revision (1) XXXXXX076X Country of Origin History (2) Malaysia Country of Origin Revision (2) XXXXXX156X Product Title (Ultra-Short) 4 Pt PCIe USB 3 Card Product Title (Short) 4 Port PCIe USB 3.0 Card w/ 2 Channels Product Title (Medium) 4 Port PCI Express USB 3.0 Card w/ 2 Dedicated 5Gbps Channels - UASP - SATA/LP4 Product Title (Standard) 4 Port PCI Express (PCIe) SuperSpeed USB 3.0 Card Adapter w/ 2 Dedicated 5Gbps Channels - UASP - SATA / LP4 Power Product Title (Long) 4 Port PCI Express PCIe SuperSpeed (5Gbps) USB 3.0 Card Adapter w/ 2 Dedicated 5Gbps Channels - UASP - SATA / LP4 Power Product Title (AMZ) 4-Port USB 3.0 PCI Express Card Adapter - PCIe SuperSpeed USB 3.0 Expansion Card w/ 2 Dedicated 5Gbps Channels (PEXUSB3S42V) Title Ingram (Part 1) 4Port PCIe USB 3.0 Controller Title Ingram (Part 2) Card w/ 2 Independent Channels Website Product Headline Add four USB 3.0 (USB 3.2 Gen 1) ports with two independent channels, LP/SATA power, and charging support to your PC through a PCI Express slot Bullet 1 UASP support across all four ports Bullet 2 Backward compatible with USB 2.0 and USB 1.0/1.1 devices Bullet 3 Includes a Low-Profile/half-height installation bracket Bullet 4 Hot-swap feature to connect/disconnect devices without powering down the system Bullet 5 Supports up to 10 Gbps total transfer bandwidth - Up to 5 Gbps per two ports Bullets (Consolidated) Add four USB 3.2 Gen 1 ports with two independent channels LP/SATA power and charging support to your PC through a PCI Express slot - Compatible with HP Pro 4300/Dell OptiPlex 3010 - 4 Port PCIe USB 3.2 Gen 1 Card w/ 2 Dedicated 5Gbps Channels/USB 3.2 Gen 1 UASP Card - USB 3.2 Gen 1 Controller - USB 3.2 Gen 1 Expansion Card with UASP/SATA Powered USB 3.2 Gen 1 Adapter Card w/ 2 channels and up to 5 Gbps of bandwidth per channel - USB 3.2 Gen 1 PCIe Card with USB Battery Charging Specification 1.2 (Apple Mode device charging only) Marketing Copy Marketing Copy (No HTML) The 4-Port USB 3.0 PCIe card lets you add four USB 3.0 ports with two dedicated 5 Gbps channels to your PCIe x4-enabled PC. This independent port architecture improves USB 3.0 performance by transferring data on two individual channels to your computer, giving you faster file transfers. By employing a second host controller chipset, the transmission channel is shared across two ports rather than four. Dedicating up to 5 Gbps for each set of two ports reduces performance bottlenecks, and effectively doubles your total available to bandwidth to 10 Gbps. Enhanced with UASP support, this USB 3.0 PCI Express Card Adapter performs up to 70% faster than conventional USB 3.0 when paired with a UASP supported enclosure. For high-power USB devices, this USB 3.0 add-on card includes an optional SATA or LP4 power connector to connect to your system power supply and deliver up to 900mA of power per port to USB 3.0 bus-powered devices (500mA for USB 2.0). The USB 3.0 expansion card also supports USB Battery Charging Specification 1.2 (Apple Mode only). The USB 3.0 PCI express card adapter is compliant with USB 3.0 standards while offering backward compatibility with existing USB 2.0 / 1.1 devices. For added versatility, the USB 3.1 PCIe card is equipped with a standard profile bracket and includes a low-profile/half-height bracket for installation in small form-factor computers. This 4-Port USB 3.0 PCIe card is backed by a StarTech.com 2-year warranty and free lifetime technical support. Applications - Upgrade an older PCIe-based system to USB 3.2 Gen 1 connectivity and UASP support to fully utilize USB 3.2 Gen 1 devices
- Expand the USB capabilities of your system with four external ports for connecting additional external hard drives, CD/DVD drives, MP3 players, printers, scanners, webcams, game controllers, digital cameras, etc. to a computer system
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
- EU RIC + Italian Sorting - Packaging - Waste - European Union - Corrugated Fiberboard
- Triman/Info-Tri - Packaging - Waste - European Union - Paper Box + plastic bag + Paper/foam divider/tray
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
System and Cable Requirements Available PCI Express x4 or greater slot Accessory Products - USB3SAB10BK
- ST4300USBM
- SAT2510BU3
- SATDOCKU3S
- ST4300USB3
- USB3SSATAIDE
- USB3SAB3BK
- SAT3510BU3
- USB3SAB6BK
- USB3AAEXT10M
- USB3AAEXT3M
- USB3AAEXT5M
Related Products - PEXUSB3S4
- PEXUSB3S4V
- PEXUSB3S400
- PEXUSB3S2E2I
- PEXUSB3S44V
Input Voltage 12V DC Output Voltage (V) 12V DC Color Black Humidity 5~85% RH Material Steel Operating Temperature 0°C to 50°C (32°F to 122°F) Primary Material Steel Product Length (mm) 167 Product Width (mm) 15 Product Height (mm) 120 Product Weight (g) 90 Storage Temperature -20°C to 60°C (-4°F to 140°F) TAA Compliant No Maximum Cable Length (mm) 3000 Maximum Data Transfer Rate 5Gbps per 2 ports - 10Gbps Total OS Compatibility - Windows 8
- Windows Server 2012
- Windows 10
- Windows 7
- Windows Server 2016
- Windows Server 2019
- Windows 11
- Windows Server 2022
UASP Support Yes USB Speed USB 3.2 Gen 1 (5Gbps) USB Type and Rate USB 3.0 (5Gbps) Bus Type PCI Express Card Type Standard Profile (LP bracket incl.) Chipset ID Renesas/NEC - µPD720202 Industry Standards Interface/Bridge USB 3.2 Gen 1 (5Gbps) IO Card Port Style Integrated on Card USB Port Type USB-A Carton Depth (mm) 375 Carton Height (mm) 315 Carton Quantity 40 Carton Weight Gross (g) 8700 Included in Package - 1 - 4 Port PCIe USB Card
- 1 - Instruction Manual
- 1 - Driver CD
- 1 - Low Profile Bracket
Included In Package for Label - 1 - Low Profile Bracket
- 1 - Driver CD
- 1 - 4 Port PCIe USB Card
- 1 - Instruction Manual
Package Depth (mm) 142 Package Height (mm) 41 Package Width (mm) 207 Package Weight (g) 199 Packaging Description 4 Port PCIe USB 3.0 Card w/ 2 Dedicated Channels Packaging Description India 4 Port PCIe USB 3.0 Card w/ 2 Dedicated Channels Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 PCI Express x4 Connector 1 (Quantity) 1 Connector 2 USB-A (5Gbps, 4.5W) Connector 2 (Quantity) 4 Connector 3 LP4 / Molex Power (4-Pin, 5V / 12V) Connector 3 (Quantity) 1 Connector 4 SATA (15-Pin) Connector 4 (Quantity) 1 Amazon Merchandising Manager Veronica Ye Artwork Due Date 2013-10-07 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute No Buying Center - Networking & Edge Yes Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,DE,DK,ES,EU,FR,IE,IN,IT,JP,MX,NL,NZ,SE,SG,UK,US Primary Technology None Product Information Creation Specialist (PICS) Alex Garcia Product Manager Natalie Goodale Product Performance Specialist Aaron Bens Product Photographer Alejandra Valencia Tech Lead Brian Linseman Technical Writer Andrew Richardson Technology Lifecycle None
