Main Image
POEINJ1GW
1Port Gb PoE Injector Adapter Power over Ethernet
Deliver power and data to your Power over Ethernet device using this mountable PoE+ midspan
Main Image
Product Images
Product Images
Quick-Start Guide
Product Name 1Port Gb PoE Injector Adapter Power over Ethernet Product Number POEINJ1GW UPC 065030865500 Lifecycle status Active Warranty 2 Years Taxonomy Product > Networking > Network Switches Category Level 1 Networking Category Level 2 POE Injectors and Extenders Category Level 3 POE Injectors Family PoE Injector - Commercial Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX016X Product Title (Ultra-Short) 1PT Gigabit Midspan Product Title (Short) 1-Port Gigabit Midspan - PoE+ Injector Product Title (Medium) 1 Port Gigabit Midspan - PoE+ Injector - 802.3at and 802.3af - Wall-Mountable Product Title (Standard) 1-Port Gigabit Midspan, PoE+ Injector, 802.3at and 802.3af, Wall-Mountable, TAA Product Title (Long) 1-Port Gigabit Midspan - PoE+ Injector - 802.3at and 802.3af - TAA Product Title (AMZ) 1 Port Gigabit Midspan - PoE+ Injector - 802.3at and 802.3af - Wall-Mountable Power over Ethernet Injector Adapter , TAA (POEINJ1GW) Title Ingram (Part 1) 1 Port Gigabit PoE+ Injector Title Ingram (Part 2) Adapter - Power over Ethernet Website Product Headline Deliver power and data to your Power over Ethernet device using this mountable PoE+ midspan Bullet 1 Easily connect, power, and operate a Gigabit PoE-powered device (PD) Bullet 2 Supplies up to 30-watts power output Bullet 3 Flexible setup, with a desktop-sized, or surface-mountable housing Bullet 4 Save money by using your existing Cat5 or better Ethernet cable Bullet 5 Fast, plug-and-play setup and operation, with no configuration required Bullets (Compact) Deliver power and data to a PoE device using Ethernet cabling - Gigabit PoE+ Injector supports 802.3at & 802.3af - Wall-Mountable - Perfect for use with IP security cameras, IP phones, and wireless access points - Power a device in a remote location Bullets (Consolidated) Supply power and data connectivity to an individual Gigabit PoE device over Ethernet cabling - Compatible with Cisco Aironet 2600 Series Access Points - 1 Port Gigabit Midspan - PoE + Injector - 802.3at and 802.3af - Wall-Mountable Power over Ethernet Injector Adapter - PoE/PSE - 1000Mbps - PoE PD - Use with IP security cameras and IP phones/Wireless access points in a home office or small business - Convert an Ethernet port to a PoE+ or PoE port - Power devices in remote locations Marketing Copy Applications - Ideal for high-power PoE+ devices requiring Gigabit speeds such as PTZ (Pan, Tilt, Zoom) cameras and Wi-Fi® access points (WAP)
- Enable remote installation of touchscreens, information kiosks, and phones in locations where a power connection isn’t available
- Perfect for small and home offices, as well as SMB applications, including system integrations, and IT administration
Website Search Keyword - PoE+ Injector
- PoE Injector
- PoE Midspan
- Power over Ethernet Injector
- Power over Ethernet Midspan
- PoE PSE
- Power over Ethernet PSE
- power over ethernet power sourcing equipment
- PSE
- power sourcing equipment
- gigabit poe injector
- gigabit power over ethernet injector
- gigabit power over ethernet midspan
- gigabit power over ethernet mindspan injector
- gigabit poe injector midspan
- gigabit poe midspan
- gigabit poe midspan injector
- gigabit power over ethernet injector midspan
- poe+ midspan
- Power over Ethernet Injector midspan
- Power over Ethernet midspan Injector
Patents and Licenses Required Regulatory Compliance Marks - RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device + accessories + cords
System and Cable Requirements If your connected devices do not meet the IEEE 802.3af or IEEE 802.3at PoE standard, then the POEINJ1GW will not inject power to the connected device(s) / Ethernet cable(s) Accessory Products - NETRS2321POE
- MCM110SC2P
- MCM110ST2P
- C6PATCH100BL
- C6PATCH75BL
- C6PATCH50BL
- C6PATCH25BL
- WIRC6CMRBL
- WIRC6PATBLRL
- WIRC6PATBKRL
Related Products - POEINJ2GI
- POEINJ100
- POESPLT100
- POEINJ4G
Input Current 1.5A Input Voltage 100 - 240 AC Output Current 0.6 A Output Voltage (V) 55V DC Power Consumption (In Watts) 33 Power Source AC Adapter Included Plug Type M Center Tip Polarity Positive Color Black Humidity 10~90% RH (Non-Condensing) Material Plastic Operating Temperature 0°C to 45°C (32°F to 113°F) Primary Material Plastic Product Length (mm) 70.000 Product Width (mm) 63.000 Product Height (mm) 25.000 Product Weight (g) 50.000 Storage Temperature -20°C to 85°C (-4°F to 185°F) TAA Compliant Yes General Specifications Power Output: 48 V DC, 30 W Maximum Cable Length (mm) 100000 Maximum Data Transfer Rate 2 Gbps (Full-Duplex) Industry Standards - IEEE 802.3af PoE, IEEE 802.3at PoE+
- IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-TX), IEEE 802.3ab (1000BASE-T)
LED Indicators 1 - Power Carton Depth (mm) 404 Carton Height (mm) 266 Carton Quantity 12 Carton Weight Gross (g) 13014 Included in Package - 1 - Gigabit midspan
- 4 - screws
- 1 - quick-start guide
- 1 - Power Adapter (EU/UK/ANZ)
Package Depth (mm) 190 Package Height (mm) 76 Package Width (mm) 232 Package Quantity 1 Package Weight (g) 1030 Packaging Description 1-Port Gigabit Midspan - PoE+ Injector Packaging Description India 1-Port Gigabit Midspan - PoE+ Injector Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 RJ-45 Connector 1 (Quantity) 2 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2016-03-29 Buying Center - AV & Collaboration Yes Buying Center - Data Center No Buying Center - End User Compute No Buying Center - Networking & Edge Yes Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CH,DE,DK,ES,EU,FI,FR,IE,IT,NL,NZ,SE,UK Primary Technology None Product Development Specialist Ray Aoki Product Information Creation Specialist (PICS) Alex Garcia Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Target Development Completion Date 2016-03-08 Target Production Release 2016-04-29 Tech Lead Stefan Tirolese Technical Writer Andrew Richardson Technology Lifecycle None
