PR12GI-NETWORK-CARD
1 Port PCI Express 2 5Gbps Ethernet RJ45 Network Adapter Car
PCIe network card with Intel® I225-V chip features multi-Gigabit speeds with NBASE-T support
Main Image
Product Images
Product Images
Product Images
Product Images
Product Images
Product Images
BOM Image
Quick-Start Guide
Product Name 1 Port PCI Express 2 5Gbps Ethernet RJ45 Network Adapter Car Product Number PR12GI-NETWORK-CARD UPC 065030906203 Lifecycle status Active Warranty 2 Years Weighted Opportunity 21895 Taxonomy Product > Cards & Adapters > Network Cards & Adapters Category Level 1 Networking Category Level 2 Desktop and Server Network Cards Category Level 3 Ethernet Cards Country of Origin Europe & Japan Malaysia Country of Origin North America Malaysia Country of Origin History (1) Malaysia Country of Origin Revision (1) XXXXXX156X Product Title (Ultra-Short) 2.5G Network Card Product Title (Short) 2.5Gbps PCIe Network Card, Ethernet NIC Product Title (Medium) 1-Port 2.5Gbps NBASE-T PCIe Network Card, Computer Network Card, Intel® I225 NIC Product Title (Standard) 1-Port 2.5G NBASE-T PCIe Network Card, Computer Network Interface Card, Intel®I225-V; Single-Port Ethernet, Multi-Gigabit NIC Product Title (Long) 1-Port 2.5Gbps NBASE-T PCIe Network Card, Intel® I225-V, Single-Port Computer Network Card, Ethernet MultiGigabit NIC, PCI Express Server LAN Card Product Title (AMZ) 1-Port 2.5Gbps PCIe Network Card, Computer Network Card, Intel® I225-V, Multi-Gigabit Ethernet Interface Card Title Ingram (Part 1) 2.5G PCIe Network Card - Title Ingram (Part 2) NBASE-T Ethernet NIC Website Product Headline PCIe network card with Intel® I225-V chip features multi-Gigabit speeds with NBASE-T support Bullet 1 1-PORT 2.5G ETHERNET CARD: High-performance PCIe 2.5Gbps network card with Intel I225-V chip; Multi-Gigabit; Leverage existing Cat5e/Cat6 (or better) cabling; NBASE-T compatible (802.3bz); PCI Express 2.0 x1 Bullet 2 IT MANAGEMENT: Intel vPro for remote management and troubleshooting; PXE boot enabled for centralized OS deployment and updates; 9K jumbo frame for reduced packet overhead; Remote system boot via WoL; VLAN support for efficient network management Bullet 3 BUILD QUALITY: LAN card features built-in heat sink to keep the controller chip cool for optimal performance, LED indicators for link status/speed, and LAN transformers to maintain signal quality and reduce EMI for reliable communications Bullet 4 COMPATIBILITY: 2.5GBASE-T variable speed options (2.5G/1G/100M/10M) with auto-negotiation; Multi-Gigabit PC network interface card is compatible with Windows, Windows Server, VMware, and Linux; Low-profile bracket included for hardware compatibility Bullet 5 THE IT PRO'S CHOICE: Designed and built for IT Professionals, this 2.5Gbps Network Card is backed for two years, including free lifetime 24/5 multi-lingual technical assistance Bullets (Compact) 1-Port 2.5Gbps interface NIC; PCIe network card w/ Intel I225-V; Supports NBASE-T, Multi-Gigabit speeds, Intel vPro, PXE boot, 9K jumbo, WoL, PCI Express 2.0; LAN card includes low-profile bracket; Ethernet card supports Windows, Linux Bullets (Consolidated) - 1-Port 2.5Gbps PoE network card with Intel I225-V chip; Supports NBASE-T and multi-Gigabit speeds (2.5G/1G/100M/10M) w/ auto-negotiation - Ethernet NIC with Intel vPro® support; PXE boot/9K jumbo/VLAN/WoL/QoS - 2.5GBASE-T PCIe network interface card features Link/Activity indicators; LAN transformer for reliable communication and reduced EMI - Compatible with Windows/Windows Server/Linux; PCI Express 2.0 x1; Includes a low-profile bracket Marketing Copy Marketing Copy (No HTML) Applications - Add high-speed data transfer to a desktop for large file transfers, video streaming, and real-time computing
- Upgrade to 2.5Gbps Ethernet to increase network efficiency in enterprise environments
Website Search Keyword - 2.5 gbps ethernet
- 2.5gbase t nic
- computer network card
- desktop ethernet card
- ethernet network interface card
- multi gigabit nic
- nbase t network card
- pci express 2.1
- pci express lan card
- pcie network card
- server nic card
Required Regulatory Compliance Marks - CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- Triman/Info-Tri - Packaging - Waste - European Union - Paper Box + plastic bag
- Triman/Info-Tri - Product - Waste - European Union - EEE Device + accessories
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
Special Notes - Intel NIC Teaming is supported only on Windows Server OS (e.g., Server 2012, 2016) and not on desktop versions like Windows 10 or 11. Accessory Products - N6PATCH3BK
- N6PATCH5BL
- N6PATCH5BK
- N6PATCH10BK
- N6PATCH15BL
- 45PATCH10BK
- 45PATCH3BK
- 45PATCH6BK
- RJ45PATCH15
Related Products - PR22GI-NETWORK-CARD
- PR42GI-NETWORK-CARD
- PR12GIP-NETWORK-CARD
- MR12GI-NETWORK-CARD
Power Source Bus Powered Color Black Humidity 5% - 90% RH Operating Temperature 5°C - 50°C (41°F - 122°F) Product Length (mm) 120.700 Product Width (mm) 89.350 Product Height (mm) 15.000 Product Weight (g) 36.000 Storage Temperature ‐10°C - 70°C (14°F - 158°F) TAA Compliant No Auto MDIX Yes Compatible Networks 2.5G/1G/100Mbps/10Mbps Full Duplex Support Yes Jumbo Frame Support 9K max. Maximum Data Transfer Rate 2.5 Gbps OS Compatibility - Windows 11
- Windows 10
- Windows Server 2019
- Windows Server 2022
- Linux
PXE Yes Wake-On-LAN (WOL) Yes Bus Type PCI Express Card Type Standard Profile (LP bracket incl.) Chipset ID Intel - I225-V Industry Standards Interface/Bridge RJ45 (2.5G Ethernet) LED Indicators Carton Depth (mm) 448 Carton Height (mm) 329 Carton Quantity 40 Carton Weight Gross (g) 5850 Included in Package - 1 - PCIe Network Card
- 1 - Low-profile Bracket
- 1 - Quick-start Guide
Included In Package for Label - 1 - Quick-Start Guide
- 1 - Low-Profile Bracket
- 1 - PCIe Network Card
Package Depth (mm) 216 Package Height (mm) 36 Package Width (mm) 150 Package Weight (g) 128 Packaging Description 1-Port PCIe 2.5G Ethernet Network Adapter Card - Intel Packaging Description India 1-Port PCIe 2.5G Ethernet Network Converter Card - Intel Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 PCI Express x1 Connector 1 (Quantity) 1 Connector 2 RJ-45 Connector 2 (Quantity) 1 A+ Not Required Actual Inbox Documents Created QSG in the box Amazon Merchandising Manager Kathleen Marshall Application Photos Uploaded Artwork Due Date 2023-11-30 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge Yes Comparable SKU Comment 1-port 2.5G PCIe Realtek card Comparable SKU 2 Comment 2-port 2.5G PCIe Intel card Digital Content Due Date 2024-01-15 Enhanced Gallery Not Required Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,BE,CA,CH,DE,DK,ES,FI,FR,IE,IN,IT,JP,NL,SE,UK,US Product Development Specialist Alex Sikora Product Information Creation Specialist (PICS) Alex Garcia Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Target Development Completion Date 2023-10-27 Target Production Release 2023-11-03 Tech Lead Stefan Tirolese Technical Writer Alex Garcia Technology Lifecycle None Video Not Required
