Main Image
PR12GIP-NETWORK-CARD
1 Port PCI Express 2 5Gbps 802 3at PoE Network Adapter Card
Add a Power-over-Ethernet (PoE) 2.5Gbps Port to a PCI Express-enabled Computer
Main Image
Product Images
Product Images
Product Images
Product Images
BOM Image
Quick-Start Guide
Product Name 1 Port PCI Express 2 5Gbps 802 3at PoE Network Adapter Card Product Number PR12GIP-NETWORK-CARD UPC 065030903493 Lifecycle status Active Warranty 2 Years Weighted Opportunity 27404 Taxonomy Product > Cards & Adapters > Network Cards & Adapters Category Level 1 Networking Category Level 2 Desktop and Server Network Cards Category Level 3 Ethernet Cards Country of Origin Europe & Japan Malaysia Country of Origin North America Malaysia Country of Origin History (1) Malaysia Country of Origin Revision (1) XXXXXX156X Product Title (Ultra-Short) PoE Network Card Product Title (Short) 1-Port 2.5Gbps PoE Network PCIe Card Product Title (Medium) 1-Port 2.5Gbps PoE Network Card, Intel I225-V, 802.3af/at PoE+ Ethernet NIC Product Title (Standard) 1-Port 2.5Gbps PCI Express PoE Network Card, Intel I225-V, PCIe 802.3af/at PoE+ Multi-Gigabit NIC, SATA Powered Ethernet Card Product Title (Long) 1-Port 2.5Gbps NBASE-T PoE Network Card, Intel I225-V, 802.3af/at PoE+ Multi-Gigabit NIC, PCI Express Server LAN Card, SATA Powered Desktop Ethernet Interface - Supports Windows, Linux Product Title (AMZ) 1-Port 2.5Gbps NBASE-T PoE Network Card, Intel I225-V, 802.3af/at PoE+ Multi-Gigabit NIC, PCI Express Server LAN Card, SATA Powered Desktop Ethernet Interface (PR12GIP-NETWORK-CARD) Title Ingram (Part 1) 1-Port 2.5Gbps Network Card - Title Ingram (Part 2) PCIe 802.3af/at PoE+ Ethernet NIC Website Product Headline Add a Power-over-Ethernet (PoE) 2.5Gbps Port to a PCI Express-enabled Computer Bullet 1 2.5G POE ETHERNET CARD: High-performance PCIe 2.5Gbps network card with Intel I225-V chip; Leverage existing Cat5e/Cat6 cabling (or better) without the use of a Power over Ethernet injector; NBASE-T compatible (802.3bz); PCI Express 2.0 x1 Bullet 2 POE+ COMPLIANT: Ethernet NIC provides up to 30W PSE and 25.5W PD at 48V DC to a connected device; Supports IEEE 802.3af (PoE) and 802.3at (PoE+) to power remote devices such as access points, RFID readers, and IP cameras Bullet 3 IT MANAGEMENT: Intel vPro for remote management and troubleshooting; PXE boot enabled for centralized OS deployment and updates; 9K jumbo frame for reduced packet overhead; Remote system boot via WoL; VLAN support for efficient network management Bullet 4 BUILD QUALITY: LAN card features built-in heatsink to keep controller chips running cool and for optimal performance, LED indicators for link status/speed, and LAN transformers maintain signal quality and reduced EMI for reliable communication Bullet 5 COMPATIBILITY: 2.5GBASE-T variable speed options (2.5G/1G/100M/10M) with auto-negotiation; Multi-gigabit network interface card for PC is compatible with Windows, Windows Server, and Linux; Low profile bracket included for hardware compatibility Bullets (Compact) 2.5Gbps PoE network card w/ Intel® I225V supports 802.3af/at PoE+ up to 30W PSE and 25.5W PD at 48V DC; NBASE-T, Multi-Gigabit Ethernet, Intel vPro, PXE boot, PCI Express 2.0; Incl. low-profile bracket; Supports Windows, Linux Bullets (Consolidated) - 2.5Gbps PoE network card with Intel I225-V chip; Supports NBASE-T and multi-Gigabit speeds (2.5G/1G/100M/10M) w/ auto-negotiation - Supports 802.3af/at PoE+ up to 30W PSE and 25.5W PD at 48V DC - 2.5GBASE-T Ethernet card with Intel vPro® support; PXE boot/9K jumbo/VLAN/WoL/QoS - PCIe network interface card features Link/Activity indicators; LAN transformer for reliable communication and reduced EMI - Compatible with Windows/Linux; PCI Express 2.0 x1; Includes a low-profile bracket Marketing Copy Marketing Copy (No HTML) Applications - Connect Power over Ethernet enabled IP cameras, phones, or Wireless Access Points
- Provide power to remote powered devices that require a PoE power source
- Add multi-gigabit connectivity to a desktop or server
Required Regulatory Compliance Marks - CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- Triman/Info-Tri - Packaging - Waste - European Union - Paper Box + plastic bag
- Triman/Info-Tri - Product - Waste - European Union - EEE Device + accessories
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
Special Notes - Intel NIC Teaming is supported only on Windows Server OS (e.g., Server 2012, 2016) and not on desktop versions like Windows 10 or 11. Accessory Products - N6PATCH3BK
- N6PATCH5BL
- N6PATCH5BK
- N6PATCH10BK
- N6PATCH15BL
- 45PATCH10BK
- 45PATCH3BK
- 45PATCH6BK
- RJ45PATCH15
Related Products - ST1000PEXPSE
- ST2000PEXPSE
- ST4000PEXPSE
- PR22GIP-NETWORK-CARD
Output Voltage (V) 48 DC Power Source Bus Powered Color Black Humidity 5% - 90% RH Operating Temperature 0°C to 55°C (32°F to 131°F) Product Length (mm) 119.000 Product Width (mm) 54.000 Product Height (mm) 16.000 Product Weight (g) 62.000 Storage Temperature ‐10°C - 70°C (14°F - 158°F) TAA Compliant No Auto MDIX Yes Compatible Networks 2.5G/1G/100Mbps/10Mbps Full Duplex Support Yes Jumbo Frame Support 9K max. Maximum Data Transfer Rate 2.5Gbps OS Compatibility - Windows 11
- Windows 10
- Windows Server 2019
- Windows Server 2022
- Linux
Promiscuous Mode Yes PXE Yes Wake-On-LAN (WOL) Yes Bus Type PCI Express Card Type Standard Profile (LP bracket incl.) Chipset ID Intel - I225-V Industry Standards Interface/Bridge RJ45 (2.5G Ethernet) LED Indicators Carton Depth (mm) 440 Carton Height (mm) 318 Carton Quantity 40 Carton Weight Gross (g) 6840 Included in Package - 1 - Network Card
- 1 - Low Profile Bracket
- 1 - Quick-Start Guide
Included In Package for Label - 1 - Quick-Start Guide
- 1 - Low Profile Bracket
- 1 - Network Card
Package Depth (mm) 156 Package Height (mm) 38 Package Width (mm) 216 Package Weight (g) 150 Packaging Description 1-Port PCIe 2.5GBase-T Ethernet PoE Network Adapter Card - Intel Packaging Description India 1-Port PCIe 2.5GBase-T Ethernet PoE Network Converter Card - Intel Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 PCI Express x1 Connector 1 (Quantity) 1 Connector 2 RJ-45 Connector 2 (Quantity) 1 Connector 3 SATA (15-Pin) Connector 3 (Quantity) 1 A+ Not Required Actual Inbox Documents Created QSG in the box Amazon Merchandising Manager Kathleen Marshall Application Photos Not Required Artwork Due Date 2023-11-10 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge Yes Comparable SKU Comment Realtek 2.5G NIC with PoE Comparable SKU 2 Comment 2-port Realtek 1G NIC with PoE Digital Content Due Date 2023-12-15 Enhanced Gallery Required Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett ID Label Silkscreened or a Label No ID label Launch Markets (concatenated) AT,AU,BE,CA,CH,DE,DK,ES,FI,FR,IE,IN,IT,JP,NL,NZ,SE,UK,US Product Development Specialist Alex Sikora Product Information Creation Specialist (PICS) Alex Garcia Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Caleigh Le Grand Target Development Completion Date 2023-10-06 Target Production Release 2023-10-31 Tech Lead Stefan Tirolese Technical Writer Alex Garcia Technology Lifecycle None Video Not Required
