9 8ft QSFP Breakout Cable Cisco Compatible

Fiber QSFP+ Cable | 40 Gbps | Breakout AOC | Lifetime Warranty

Main Image

Product Images

Product Name	9 8ft QSFP Breakout Cable Cisco Compatible
Product Number	QSFP4X10GAO3
UPC	065030874717
Lifecycle status	Active
Warranty	Lifetime
Taxonomy	Product > Networking > SFP Transceivers
Category Level 1	Networking
Category Level 2	SFP Transceivers
Category Level 3	Cisco Compatible Cables
Family	Cisco Compatible Cables
Country of Origin Europe & Japan	China
Country of Origin North America	China
Country of Origin History (1)	Taiwan
Country of Origin Revision (1)	XXXXXX169X
Country of Origin History (2)	China
Country of Origin Revision (2)	XXXXXX056X

Product Title (Ultra-Short)	3m QSFP+ Breakout
Product Title (Short)	QSFP+ Breakout DAC QSFP-4X10G-AOC3M 3m
Product Title (Medium)	Cisco QSFP-4X10G-AOC3M Compatible QSFP+ Active Optical Breakout Cable -
Product Title (Standard)	AOC Breakout Cable for Cisco QSFP-4X10G-AOC3M - 3m 40G 1x QSFP+ to 4x SFP+ AOC Cable 40GbE QSFP+ Active Optical Fiber 9.84ft
Product Title (Long)	AOC Breakout Cable for Cisco QSFP-4X10G-AOC3M - 3m/9.84ft 40G 1x QSFP+ to 4x SFP+ AOC Cable - 40GbE QSFP+ Active Optical Fiber - 40Gbps QSFP Plus/Transceiver Module Breakout Cable - C9300 C3850
Product Title (AMZ)	AOC Breakout Cable for Cisco QSFP-4X10G-AOC3M - 3m/9.84ft 40G 1x QSFP+ to 4x SFP+ AOC Cable - 40GbE / 40Gbps QSFP Plus Transceiver Module Active Optical Fiber - C9300 C3850 (QSFP4X10GAO3)
Title Ingram (Part 1)	Cisco QSFP-4X10G-AOC3M - AOC -
Title Ingram (Part 2)	Breakout Cable - 3 m (10 ft.)
Website Product Headline	Fiber QSFP+ Cable \| 40 Gbps \| Breakout AOC \| Lifetime Warranty
Bullet 1	100% CISCO QSFP-4X10G-AOC3M COMPATIBLE QSFP+ BREAKOUT DAC: Works with Cisco switches like C9300, C3850, C9300, C9500, C3650 and others
Bullet 2	TECHNICAL SPECS: 3m (9.84ft) Active Optical Cable \| 40Gbps \| Active Optical Fiber \| 1x QSFP+ to 4x SFP+ Pluggable Connector \| PVC Cable Jacket \| Hot swappable \| MSA Compliant
Bullet 3	DESIGNED FOR SERVER ROOMS: 40GbE AOC is a convenient alternative to transceivers inside and between racks. Factory termination means high performance & reliability, with less maintenance.
Bullet 4	OUTSTANDING SUPPORT: Backed by StarTech.com for the life of the cable itself, not your equipment; our cables won't void your OEM warranty and with access to our Tech Advisors 5/24
Bullet 5	WORKS WITH MSA COMPLIANT SWITCHES: Low power 40GbE DAC also works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules and transceivers
Bullets (Compact)	100% Cisco QSFP-4X10G-AOC3M active optical breakout cable (AOC) - 3m Cable, 40Gbps, Active Optical Fiber, 1x QSFP+ to 4x SFP+ Pluggable Connector - For Cisco switches like C9300 C3850 C9300 - Hot-Swappable + MSA Compliant - Lifetime Warranty
Bullets (Consolidated)	100% Cisco QSFP-4X10G-AOC3M Compatible 40GbE direct attached breakout cable - 3m/9.84' Cable \| 40Gbps \| Active Optical Fiber \| 1x QSFP+ to 4x SFP+ Pluggable Connector \| PVC Jacket - 40GbE Low Power Transceiver Module DAC for edge networks/server rooms/data centers - For Cisco switches C9300 C3850 C9300 - Hot-Swappable and MSA Compliant - StarTech.com lifetime warranty and will not void your OEM warranty
Marketing Copy
Marketing Copy (No HTML)
Applications	Point-to-point in-rack and across-rack server or network switch connections, for up to four devices Use in 40Gb/10Gb mixed Ethernet network applications
Website Search Keyword	10gtek sfp cable 40G AOC Cable 40g cable 40G Cisco Compatible Breakout Cable 40g qsfp+ cable 40gb qsfp+ cable 40gbe cable active optical cable Active qsfp+ cable AddOn Breakout Cable AddOn qsfp to sfp+ AOC Cable Axiom Breakout Cable Axiom qsfp to sfp+ Breakout Cable cisco active optical cable Cisco AOC Cable Cisco qsfp to sfp+ Cisco QSFP-4X10G-AOC3M cisco sfp cable dac cable direct attach cable fan out cable fanout cable mini gbic cable Proline Breakout Cable Proline qsfp to sfp+ qsfp cable qsfp sfp+ adapter qsfp to sfp adapter qsfp to sfp+ breakout cable QSFP+ Active Cable QSFP+ Active Optical 4 to 1 Cable qsfp+ breakout qsfp+ breakout cable qsfp+ cable qsfp+ to 4 sfp+ qsfp+ to sfp+ sfp cable sfp dac sfp dac cable sfp direct attach cable sfp fiber cable sfp fiber optic cable sfp optical cable sfp to sfp cable sfp twinax cable transceiver cable twinax cable

Required Regulatory Compliance Marks

FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
RCM - EMC/EMI - Australia/New Zealand - RCM Mark
WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
Triman/Info-Tri - Product - Waste - European Union - EEE Device
EU RIC + Italian Sorting - Packaging - Waste - European Union - Corrugated Fiberboard
Triman/Info-Tri - Packaging - Waste - European Union - Paper Box + plastic bag + Paper/foam divider/tray
Recycling - Waste - Japan - Paper Recycling Mark
Recycling - Waste - Japan - Plastic Recycling Mark
CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement

Related Products
QSFP4X10GAO5
QSFP4X10GAO7
QSFP4X10AO15
Power Consumption (In Watts) < 1.5 W (per end)

Cable Length (mm)	3000
Color	Aqua
Material	Steel
Operating Temperature	0°C to 70°C (32°F to 158°F)
Primary Material	Steel
Product Length (mm)	3140.000
Product Width (mm)	14.000
Product Height (mm)	12.000
Product Weight (g)	200.000
Storage Temperature	-40°C to 80°C (-40°F to 158°F)
TAA Compliant	No

Compatible Networks 40 Gbps
Maximum Data Transfer Rate 40Gbps for QSFP+ / 10Gbps for SFP+
Cable Jacket Material PVC - Polyvinyl Chloride
Cable Type Active Optical Cable
SFP Compatible Brand Cisco

Carton Depth (mm)	255
Carton Height (mm)	295
Carton Quantity	10
Carton Weight Gross (g)	4250
Included in Package	1 - QSFP+ to 4x SFP+ cable
Number of Sub-Cartons	2
Package Depth (mm)	250
Package Height (mm)	20
Package Width (mm)	330
Package Quantity	1
Package Weight (g)	230
Packaging Description	QSFP-4X10G-AOC3M Compatible - AOC Breakout - QSFP+ to 4x SFP+
Packaging Description India	QSFP-4X10G-AOC3M Compatible - AOC Breakout - QSFP+ to 4x SFP+
Sub-Carton Depth (mm)	0
Sub-Carton Height (mm)	0
Sub-Carton Width (mm)	0
Sub-Carton Quantity	5
Sub-Carton Weight (g)	0

Connector 1 QSFP+ (40Gbps)
Connector 1 (Quantity) 1
Connector 2 SFP+ (10Gbps)
Connector 2 (Quantity) 4

Amazon Merchandising Manager	Kathleen Marshall
Artwork Due Date	2017-09-01
Buying Center - AV & Collaboration	No
Buying Center - Data Center	Yes
Buying Center - End User Compute	No
Buying Center - Networking & Edge	Yes
Digital Content Due Date	2017-11-24
Enhanced Gallery Designer	Catherine Almeida
en-US Content Approved	Yes
Focus Rank	Level 0 - Not Applicable
Graphic Designer	Shane Arnett
Launch Markets (concatenated)	AT,AU,BE,CA,CH,DE,DK,ES,EU,FI,FR,IE,IN,IT,JP,NL,NZ,SE,UK,US
Primary Technology	None
Product Development Specialist	Ray Aoki
Product Information Creation Specialist (PICS)	Alex Garcia
Product Manager	Rob Fleck
Product Performance Specialist	Ray Aoki
Product Photographer	Alejandra Valencia
Target Development Completion Date	2017-10-13
Target Production Release	2017-11-24
Tech Lead	Stefan Tirolese
Technical Writer	Alex Garcia
Technology Lifecycle	None
Vending Machine	Not Compatible with Vending Machine

Compatible Networks	40 Gbps
Maximum Data Transfer Rate	40Gbps for QSFP+ / 10Gbps for SFP+

Cable Jacket Material	PVC - Polyvinyl Chloride
Cable Type	Active Optical Cable
SFP Compatible Brand	Cisco

Connector 1	QSFP+ (40Gbps)
Connector 1 (Quantity)	1
Connector 2	SFP+ (10Gbps)
Connector 2 (Quantity)	4
