R2CCR-1M-USB-CABLE
1m USB-C to Right Angle USB-C 2.0 Cable
Connect and charge USB Type-C devices with a rugged right-angle cable
Main Image
Enhanced Images
Product Images
Product Images
Product Images
Product Images
Product Name 1m USB-C to Right Angle USB-C 2.0 Cable Product Number R2CCR-1M-USB-CABLE UPC 065030893572 Lifecycle status Active Warranty Lifetime Taxonomy Product > Cables > USB & Thunderbolt Cables Category Level 1 USB and Thunderbolt Cables Category Level 2 USB-C Cables Category Level 3 USB-C Cables - USB 2.0 Charge & Sync Rugged Family USB 2.0 Rugged - Angle Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX171X Country of Origin History (2) Vietnam Country of Origin Revision (2) XXXXXX184X Product Title (Ultra-Short) USB C Charging Cable Product Title (Short) 3ft USB C Charging Cable Angled 60W PD Product Title (Medium) 3ft/1m USB C Charging Cable Right Angle, Heavy Duty Fast Charge Cable 60W PD Product Title (Standard) 3.3ft (1m) USB-C Fast Charging Cable, Rugged, Right-Angled, Charge & Sync, 60W (3A) PD, USB 2.0, TPE Jacket and Aramid Fiber Product Title (Long) 3ft (1m) USB-C Fast Charging Cable, Rugged, Right-Angled, Charge & Sync, 60W (3A) PD, USB 2.0, TPE Jacket and Aramid Fiber - USB C Charging Cord Product Title (AMZ) 3.3ft (1m) USB-C Fast Charging Cable, Rugged, Right-Angled, Charge & Sync, 60W (3A) PD, USB 2.0, TPE Jacket Title Ingram (Part 1) 1mUSB-C Charging Cable Fast Title Ingram (Part 2) Charge - Right Angle USBC Cable Website Product Headline Connect and charge USB Type-C devices with a rugged right-angle cable Bullet 1 RIGHT ANGLE USB-C CABLE: 3ft (1m) USB C charging cable features a right angle USB-C connector - Ideal for tight spots allowing the cable to run flush with the device - Reduces strain on the port and connector vs. a straight angled cable Bullet 2 RUGGED DESIGN: USB Type-C cable reinforced with aramid fiber for increased tensile strength - Tested to withstand 10000+ insertions and 5000+ bend cycles at 180° angle - Durable TPE jacket and strain reliefs resist damage from repeated use Bullet 3 FAST CHARGE AND SYNC: Supports Power Delivery up to 60W at 3A for fast charging from a USB port or Quick Charge enabled port/power adapter - High quality cord designed to charge and sync USB-C devices - Use with USB-C ports and 18W/30W/45W/60W chargers Bullet 4 USB-C COMPATIBILITY: Heavy duty data transfer cable allows you to charge and sync your USB Type C devices including iPad Pro, Samsung Galaxy, One Plus, Google Pixel; (*Please note that USB 2.0 cables do not support video) Bullet 5 SPECS: Length: 3ft (1m) - Color: Black - Connectors: Male USB-C to Male USB-C - Performance: USB 2.0 - Braid Material: Aramid Fiber - Power: Up to 60W/3A - Jacket Type: TPE - Shielding: EMI Protection with Aluminum/Mylar - Backed for Life Bullets (Compact) 3ft (1m) USB C to right-angled USB type-C charging cable for convenient peripheral connection - Up to 60W Power Delivery 3A for fast charging - Heavy duty male-to-male USB 2.0 cord with extended strain reliefs capable of 5000 bend cycles Bullets (Consolidated) Black 3ft USB-C charging cable features right angle C connector that reduces strain on the port and allows cable to run flush with device - Heavy duty rugged USB 2.0 Type-C cable with TPE jacket provides flexible connection in tight spaces - High quality cord tested to 10000+ insertion cycles and up to 5000+ bend cycles at 180DEG angle - Up to 60W Power Delivery 3A for fast charging from USB port or Quick Charge power adapter - USB C data cable works with iPad Pro/iPad Mini/Google Pixel 6/Pro Marketing Copy Marketing Copy (No HTML) Required Regulatory Compliance Marks - CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
Related Products - R2ACR-15C-USB-CABLE
- R2ACR-1M-USB-CABLE
- R2ACR-2M-USB-CABLE
- R2ACR-30C-USB-CABLE
- R2CCR-15C-USB-CABLE
- R2CCR-2M-USB-CABLE
- R2CCR-30C-USB-CABLE
Power Delivery 60W Cable Length (mm) 1000 Cable OD 3.1 Color Black Connector Style Right Angle to Straight Humidity 0%~85% Operating Temperature 0 to 50°C (32 to 122°F) Product Length (mm) 1000.000 Product Width (mm) 28.000 Product Height (mm) 6.000 Product Weight (g) 26.000 Storage Temperature 0 to 50°C (32 to 122°F) TAA Compliant No Wire Gauge 22/32 AWG Maximum Cable Length (mm) 1000 USB Speed USB 2.0 (480Mbps) USB Type and Rate USB 2.0 (480Mbps) Video Support No Cable Jacket Material TPE - Thermoplastic Elastomers Cable Shield Material Aluminum-Mylar Foil with Braid Connector Plating Gold and Nickel Connectors Combo USB-C to USB-C Host or Charger Connector USB-C Peripheral Connector USB-C Amount of recycled material in plastic packaging At Least 30% Carton Depth (mm) 439 Carton Height (mm) 297 Carton Quantity 300 Carton Weight Gross (g) 10494 Included in Package 1 - USB-C to Angled USB-C Cable Included In Package for Label 1 - USB-C to Angled USB-C Cable Number of Sub-Cartons 30 Package Depth (mm) 210 Package Height (mm) 11 Package Width (mm) 126 Package Quantity 1 Package Weight (g) 30 Packaging Description 3ft/1m USB-C to Right Angle USB-C 2.0 Cable Packaging Description India 1m USB-C to Right Angle USB-C 2.0 Cable Sub-Carton Depth (mm) 158 Sub-Carton Height (mm) 52 Sub-Carton Width (mm) 243 Sub-Carton Quantity 10 Sub-Carton Weight (g) 320 Connector 1 USB-C (480Mbps, 2.5W) Connector 1 (Quantity) 1 Connector 2 USB-C (480Mbps, 2.5W) Connector 2 (Quantity) 1 A+ Not Required Amazon Merchandising Manager Veronica Ye Application Photos Uploaded Artwork Due Date 2021-11-24 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge No Digital Content Due Date 2022-07-19 Enhanced Gallery Required Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level - 2 Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,DE,DK,ES,FI,FR,HK,IE,IN,IT,JP,MX,NL,NZ,PE,SE,SG,UK,US Primary Technology USB-C Product Development Specialist Pierre Wheeler Product Information Creation Specialist (PICS) Brian Chan Product Manager Tim North Product Performance Specialist Aaron Bens Product Photographer Caleigh Le Grand Target Development Completion Date 2021-11-17 Target Production Release 2022-02-14 Tech Lead Justin Weaver Technical Writer Brian Chan Technology Lifecycle Mainstream Video Not Required
