RK1219WALH
Wallmount Cabinet w/ Removable Side Panels
Store your servers, network and telecommunications equipment securely in this 12U wall-mountable rack
Main Image
Product Images
Product Images
Product Images
Product Images
Video Link YouTube
Video Link YouTube
Product Name Wallmount Cabinet w/ Removable Side Panels Product Number RK1219WALH UPC 065030819817 Lifecycle status Discontinued Warranty Lifetime Taxonomy Product > Legacy Discontinued Category Level 1 Racks and Enclosures Category Level 2 Wall-Mount Racks and Enclosures Category Level 3 Wall-Mount Enclosures Country of Origin Europe & Japan China Country of Origin North America China Product Title (Ultra-Short) 12U Wall Mount Rack Product Title (Short) Hinged Wall Mount Server Rack Cabinet Product Title (Standard) StarTech.com 12U 19in Hinged Wall Mount Server Rack Cabinet w/ Vented Glass Door Product Title (Long) 12U 19in Hinged Wall Mount Server Rack Cabinet w/ Vented Glass Door Title Ingram (Part 1) 12U Hinged Wall Mount Server Rac Title Ingram (Part 2) k Cabinet w/ Vented Door Website Product Headline Store your servers, network and telecommunications equipment securely in this 12U wall-mountable rack Bullet 1 Cable pass-through at rear of cabinet Bullet 2 Fan mounts for optional additional cooling Bullet 3 Sturdy steel design Bullet 4 Tempered, vented, lockable glass front door Bullet 5 Unique hinged design swings open for easy access to a your equipment Bullets (Consolidated) Store your servers network and telecommunications equipment securely in this 12U wall-mountable rack - Works with rack mount equipment like servers and network and telecommunications devices - Wall mount server rack/wall mount server cabinet/12U server rack/19" server rack/wall rack/wall mount server rack - Mount rack mount equipment to a wall - Unique hinged design swings open for easy access to a your equipment - Removable side panels with lock - Cable pass-through at rear of cabinet Marketing Copy Applications Mounting standard 19 in. networking equipment in exposed or insecure locations Website Search Keyword - wall mount
- wallmount
- wall rack
- safe rack
- security rack
- cooled rack
- cabinet
- mountable rack
- mountable case
- hinged case
- hinged rack
- hinged cabinet
- racks
- cabinets
- telecom rack
- telco
- telecommunications rack
- Server racks
Required Regulatory Compliance Marks - REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
Accessory Products - CABSHELF
- 4UDRAWER
- CABSCREWS
- CABCAGENUTS
- CABLMANAGER2
- ACFANKIT12
- PCM815SHNA
- CABCAGENT62B
- CABCAGENTS62
- CABCAGENUT2B
- CABCAGENUT6B
- CABCAGENUTS2
- CABCAGENUTS6
- CABCAGENUTSB
- CABSCREWM5
- CABSCREWM52
- CABSCREWM52B
- CABSCREWM5B
- CABSCREWM6
- CABSCREWM62
- CABSCREWM62B
- CABSCREWM6B
- CABSCREWSB
- CABSCREWSM5
- CABSCREWSM5B
- CABSCREWSM6
- CABSCREWSM6B
- CABSCRWSM62B
- RKPW081915
- RKPW161915
- C6PANEL24
- PANEL4524
- PANELHU24
- PANEL4548
- C6PANL4524
- RKPNLHS2U
- RKPNLHS4U
- RKPNLHS6U
- RKPNLHV2U
- RKPNLHV4U
- RKPNLHV6U
- RKPNLTL1U
- RKPNLTL1UV
- RKPNLTL2U
- RKPNLTL2UV
- CMBRUSH1U
- CMVELC1U
Related Products - CAB1019WALL
- RK1219WALL
Replacement Product RK12WALHM Back Door Features Secure Key Lock Color Gray Depth Capacity (Filter) 12.1 - 24 in. (306 - 609mm) Front Door Features Secure Key Lock with Reversible and Removable Front Door Internal Depth (mm) 538 Internal Width (mm) 595 Maximum Mounting Depth (mm) 393 Minimum Mounting Depth (mm) 12 Product Length (mm) 564 Product Width (mm) 559 Product Height (mm) 636 Product Weight (g) 26300 Side Panel Construction Steel TAA Compliant No Rack Weight Capacity Range Less Than 300 lbs (136kg) Weight Capacity for Racks with No Casters (g) 60000 Back Door Construction Steel Fan Options Two Optional Fans: 120 mm Frame Type Enclosed Cabinet Front Door Construction Steel with Glass Window Industry Standards EIA/ECA-310-E Mounting Hole Types Square (For Cage Nut) Mounting Rail Profile L-Shape Rack Special Features - Adjustable Mounting Rails
- Wall-Mountable
- Ships Fully Assembled
Rack Type 4-Post Rack U Height Ranges 12-26U Side Panel Construction Steel Side Panel Features Secure Key Lock with Removable Side Panels U Height 12U Wallmountable Yes Carton Depth (mm) 667 Carton Height (mm) 686 Carton Quantity 1 Carton Weight Gross (g) 29029.888 Included in Package - 1 - 12U Server Cabinet
- 2 - Sets of Keys
- 11 - M6 Screws
- 11 - M6 Cage Nuts
- 1 - Torx Tool
- 1 - Hex Key
Package Depth (mm) 667 Package Height (mm) 686 Package Width (mm) 682 Package Quantity 1 Package Weight (g) 29029.888 Packaging Description 12U 19in Hinged Wall Mount Server Cabinet Packaging Description India 12U 19in Hinged Wall Mount Server Cabinet Rack Flatpack No Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2014-06-18 Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Graphic Designer Shane Arnett Launch Markets (concatenated) CA,EU,UK,US Primary Technology None Product Information Creation Specialist (PICS) Alex Garcia Product Manager Bhuvan Uppal Product Performance Specialist Aaron Bens Product Photographer Alejandra Valencia Tech Lead Stefan Tirolese Technical Writer Andrew Richardson Technology Lifecycle Legacy Vending Machine Not Compatible with Vending Machine
