RK419WALVSGB
Horizontal Wall Mountable Server Rack 4U 19in
Wall-mount your server or networking equipment horizontally or vertically
Main Image
Product Images
Product Images
Product Images
Product Images
Product Images
Product Images
Video Link YouTube
Product Name Horizontal Wall Mountable Server Rack 4U 19in Product Number RK419WALVSGB UPC 065030845748 Lifecycle status End of Life Warranty Lifetime Taxonomy Product > Legacy Discontinued Category Level 1 Racks and Enclosures Category Level 2 Wall-Mount Racks and Enclosures Category Level 3 Vertical Wall-Mount Brackets Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX094X Product Title (Short) 4U Horizontal Wall Mountable Server Rack Product Title (Standard) 4U 19in Secure Horizontal Wall Mountable Server Rack with 2 Fans Product Title (Long) 4U 19in Secure Horizontal Wall Mountable Server Rack - 2 Fans Included Product Title (AMZ) 4U 19in Secure Horizontal Wall Mountable Server Rack - 2 Fans Included (RK419WALVSGB) Title Ingram (Part 1) 4U 19in Secure Horizontal Wall M Title Ingram (Part 2) ountable Server Rack 2 Fans Website Product Headline Wall-mount your server or networking equipment horizontally or vertically Bullet 1 Compatible with most 19in wide rack-mountable equipment Bullet 2 Constructed to meet the EIA-RS310 19in rack standards Bullet 3 Solid steel construction Bullet 4 Includes optional 4U steel plate which acts as a shelf, allowing the rack to be used as a wall case for any non-rackmount equipment Bullet 5 Wall mounting holes are 16in center to center, for greater stability and mounting to standard wall studs Marketing Copy Applications - Ideal for small and medium businesses requiring small, secure rack solutions dispersed throughout the organization
- Install a large server anywhere in an office without a full server room, while protecting against unauthorized access
- Perfect for installing network switches out of the way and high up on a wall in a branch office, warehouse, or retail supercenter
- Securely mount servers and telecommunication equipment flush against the wall
Website Search Keyword - 19" rack
- blade server rack
- computer rack
- equipment rack
- horizontal wall rack
- mountable server case
- side mount
- vertical rack
- wall case
- wall chassis
- wall mount rack
- wall rack
- locking rack
- locking cabinet
- locking case
- locking wall case
- secure rack
- security rack
- safe rack
- locked rack
Required Regulatory Compliance Marks - WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
Accessory Products - CABCAGENUTS
- CABLMANAGER2
- CABSCREWM6
- CABSCREWS
- CABCAGENT62B
- CABCAGENTS62
- CABCAGENUT2B
- CABCAGENUT6B
- CABCAGENUTS2
- CABCAGENUTS6
- CABCAGENUTSB
- CABSCREWM5
- CABSCREWM52
- CABSCREWM52B
- CABSCREWM5B
- CABSCREWM62
- CABSCREWM62B
- CABSCREWM6B
- CABSCREWSB
- CABSCREWSM5
- CABSCREWSM5B
- CABSCREWSM6
- CABSCREWSM6B
- CABSCRWSM62B
- C6PANEL24
- PANEL4524
- PANELHU24
- PANEL4548
- C6PANL4524
Related Products - CAB1019WALL
- RK119WALLV
- RK1219WALH
- RK1219WALHM
- RK1219WALL
- RK219WALLV
- RK219WALVO
- RK319WALLV
- RK419WALLV
- RK619WALVS
- RK619WALL
- RK812WALLO
- RK419WALVO
Color Black Depth Capacity (Filter) Greater Than 24 in. (610mm) Front Door Features Secure Key Lock with Removable Front Door Internal Depth (mm) 585.2 Internal Width (mm) 485 Maximum Mounting Depth (mm) 520.7 Product Length (mm) 644.000 Product Width (mm) 721.000 Product Height (mm) 219.000 Product Weight (g) 19900.000 Side Panel Construction Steel TAA Compliant Yes Rack Weight Capacity Range Less Than 300 lbs (136kg) Weight Capacity for Racks with No Casters (g) 68000 Fan Options Two Fans Included: 120 mm Frame Type Enclosed Cabinet Front Door Construction Steel Industry Standards EIA/ECA-310-E Mounting Hole Types Square (For Cage Nut) Mounting Rail Profile L-Shape Rack Special Features - Grounding Lug(s)
- Lockable Top Hatch
- Wall-Mountable
- Ships Fully Assembled
Rack Type 2-Post Rack U Height Ranges 1-5U Side Panel Construction Steel U Height 4U Wallmountable Yes Carton Depth (mm) 710 Carton Height (mm) 288 Carton Quantity 1 Carton Weight Gross (g) 23080 Included in Package - 24 - #10-32 Screws
- 1 - RK419WALVS 4U Wallmount Rack
- 1 - Set of Keys
- 1 - UK to EU Plug Converter
- 24 - #10-32 Cage Nuts
Package Depth (mm) 710 Package Height (mm) 288 Package Width (mm) 774 Package Quantity 1 Package Weight (g) 23080 Packaging Description 4U Secure Horizontal Wall Mount Server Rack Packaging Description India 4U Secure Horizontal Wall Mount Server Rack Rack Flatpack No Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2014-06-18 Buying Center - AV & Collaboration No Buying Center - End User Compute No Buying Center - Networking & Edge Yes Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) EU,UK Primary Technology None Product Information Creation Specialist (PICS) Alex Garcia Product Manager Bhuvan Uppal Product Performance Specialist Aaron Bens Product Photographer Alejandra Valencia Tech Lead Stefan Tirolese Technical Writer Andrew Richardson Technology Lifecycle None Vending Machine Not Compatible with Vending Machine
