S355BU33ERM
5 Bay USB 3.0 Removable Hard Drive Enclosure
Connect five hot-swappable 2.5/3.5" SATA III hard drives to your computer externally through USB 3.0 with UASP or eSATA
Main Image
Product Images
Product Images
Product Images
Product Images
BOM Image
Product Name 5 Bay USB 3.0 Removable Hard Drive Enclosure Product Number S355BU33ERM UPC 065030859295 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 Data Storage Category Level 2 External Drive Enclosures Category Level 3 SATA Enclosures - USB-A 5Gbps Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX014X Product Title (Ultra-Short) 5-Bay HDD Enclosure Product Title (Short) USB 3.0 / eSATA 5-Bay SATA HDD Enclosure Product Title (Medium) USB 3.0 / eSATA 5-Bay Hot-Swap 2.5/3.5” SATA III Hard Drive Enclosure with UASP Product Title (Standard) USB 3.0 / eSATA 5-Bay Hot-Swap 2.5/3.5” SATA III Hard Drive Enclosure with UASP – 5-Bay SATA 6 Gbps Enclosure for HDD / SSD Product Title (Long) USB 3.0 / eSATA 5-Bay Hot-Swap 2.5/3.5” SATA III Hard Drive Enclosure with UASP – 5-Bay SATA 6 Gbps Enclosure for HDD / SSD Product Title (AMZ) 5 bay SATA 6Gbps drive enclosure for SSD/HDD - USB 3.0 / eSATA 2.5/3.5” SATA III Hard Drive Enclosure with UASP (S355BU33ERM) Title Ingram (Part 1) eSATA / USB 3.0 Hot-Swap 5-Bay Title Ingram (Part 2) SATA Hard Drive Enclosure w/ UASP Website Product Headline Connect five hot-swappable 2.5/3.5" SATA III hard drives to your computer externally through USB 3.0 with UASP or eSATA Bullet 1 Supports SATA III (6 Gbps) and UASP for optimal performance Bullet 2 Supports both 2.5" and 3.5" form factor hard drives (HDD) and solid state drives (SSD) Bullet 3 eSATA or USB host connection Bullet 4 Five individual drive bays Bullet 5 Built-in cooling fan Bullets (Consolidated) Connect five hot-swappable 2.5/3.5" SATA III hard drives to your computer externally through USB 3.0 with UASP or eSATA - Compatible with USB and eSATA enabled laptop and desktop computers and 2.5in and 3.5in SATA hard drives - External Hard Drive Enclosure/USB 3.0 eSATA HDD Enclosure/5 Bay Hard Drive Enclosure/USB 3.0 or eSATA Back-up Drives - Built-in cooling fan - Expand the storage capacity of a small form factor system or laptop - Add a 5-bay hot-swap enclosure to a server or workstation Marketing Copy Marketing Copy (No HTML) The 5 bay SSD/HDD enclosure lets you access five individual 2.5" or 3.5" hard drives simultaneously, through a single eSATA or USB port connection to your laptop or desktop computer. For fast performance and efficient data transfers, you can connect the external USB 3.0 hard drive enclosure to your computer through either eSATA or USB 3.0. The USB 3.0 eSATA HDD enclosure supports full SATA III data transfer rates up to 6 Gbps, when connected through eSATA. When connected through USB 3.0, the SATA 6Gbps drive enclosure supports transfer speeds up 5 Gbps plus support for UASP, which performs up to 70% faster than conventional USB 3.0 when paired with a UASP-enabled host controller. With support for the fastest drive technologies available including SATA III (6 Gbps), hybrid drives and solid-state drives (SSD), the 5 bay SSD/HDD enclosure helps you save time through optimized performance from your external storage. For optimal drive performance and longevity, the external USB 3.0 hard drive enclosure features a built-in fan, which helps cool your drives while ensuring maximum heat dissipation. To ensure compatibility with your computer system, the USB 3.0 eSATA HDD enclosure supports all of the leading operating systems, including Microsoft Windows (8/7/Vista/XP/Server 2008/Server 2003), Apple OSX (10.9/10.8/10.7/10.6), Linux, and Google Chrome OS. The SATA 6Gbps drive enclosure is backed by a StarTech.com 2-year warranty and free lifetime technical support. Applications - Add a 5-bay hot-swap enclosure to a server or workstation computer, for a removable backup solution
- Expand the storage capabilities of a small form factor/embedded system or laptop, with external drives
- Adding external storage capacity for video editing or photo editing stations, making it easier to work with very large file sizes
- Creating additional backup/archive storage
- Turn unused SATA hard drives into additional external data storage
Website Search Keyword - 5 bay hard drive enclosure
- 3.5 hard drive
- hot swap
- drive tray
- external enclosure
- eSATA
- USB
- UASP
- SATA 6 Gbps
- SATA III
- SATA 3
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- CE - Safety - Electrical - European Union - Low Voltage Directive (LVD) 2014/35/EU
Accessory Products - USB3SAB10BK
- USB3SEXT5DKB
- USB3SAB1MRA
- USB3SAB2MRA
- USB3SAB3
- USB3SAB3BK
- USB3SAB1
- USB3SEXTAA6
- ECESAT32
- PEXESAT32
- PEXESAT322I
- PEXSAT31E1
Related Products - S3520WU33ER
- S3520BU33ER
- S352BMU3N
- S352BU33HR
- S352BU33RER
- S352U2RER
- S352U2RERC
- SAT3540U2E
- SAT3520U2ER
- SAT3520U2R
- SAT3540ER
- SAT3550ESR
- SAT5210U2E
- S358BU33ERM
Input Voltage 5V DC / 12V DC (internal 100-230V) Output Voltage (V) 5 DC Color Black Humidity 10% ~ 90% non-condensing Operating Temperature 5°C to 55°C (41°F to 131°F) Product Length (mm) 281.000 Product Width (mm) 151.000 Product Height (mm) 215.000 Product Weight (g) 4000.000 Storage Temperature -40°C to 70°C (-40°F to 158°F) TAA Compliant Yes Air Flow Rate 35CFM General Specifications Hot Swap Capability Yes Max Drive Capacity Currently tested with up to 6TB 7200 RPM hard drives Maximum Data Transfer Rate 6 Gbps Noise Level 20.4 dBA OS Compatibility OS Independent Port Multiplier Yes RAID No SATA Type and Rate eSATA (6 Gbps) UASP Support Yes USB Type and Rate USB 3.0 (5Gbps) Bus Type USB 3.2 Gen 1 (5Gbps) Chipset ID Compatible Drive Types SATA Fan Bearing Type Sleeve Bearing Fans 1 - 120 mm Fans Included? Yes/No Yes Interface/Bridge USB 3.0 & eSATA LED Indicators - 5 - Drive Activity / Interface LED
- 1 - Power LED
- 1 - HDD Ready LED
- 1 - USB / eSATA LED
Number of Drives 5 Carton Depth (mm) 417 Carton Height (mm) 368 Carton Quantity 4 Carton Weight Gross (g) 22090 Included in Package - 1 - USB 3.0 / eSATA SSD/HDD Enclosure
- 5 - 2.5/3.5” drive trays (preinstalled)
- 1 - SATA to eSATA full profile bracket
- 1 - eSATA cable
- 1 - USB 3.0 cable
- 1 - 2.5/3.5” drive installation screw kit
- 3 - Power cables (NA/UK/EU)
- 1 - Instruction manual
Package Depth (mm) 323 Package Height (mm) 212 Package Width (mm) 346 Package Weight (g) 5260 Packaging Description USB 3.0/eSATA 5 SATA 2.5/3.5” HDD Enclosure Packaging Description India USB 3.0/eSATA 5 SATA 2.5/3.5” HDD Enclosure Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 SATA (7-Pin + 15-Pin) Connector 1 (Quantity) 5 Host Connector 1 USB-B (5Gbps, 4.5W) Host Connector 1 (Quantity) 1 Host Connector 2 eSATA (7-Pin) Host Connector 2 (Quantity) 1 Amazon Merchandising Manager Veronica Ye Artwork Due Date 2014-07-31 Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Graphic Designer Shane Arnett Launch Markets (concatenated) AU,BE,CA,DE,DK,ES,EU,FR,IT,NL,NZ,SE,UK,US Primary Technology None Product Development Specialist Pierre Wheeler Product Information Creation Specialist (PICS) Brian Chan Product Manager Tony Parackal Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Tech Lead Justin Weaver Technical Writer Brian Chan Technology Lifecycle None Vending Machine Not Compatible with Vending Machine
