Main Image
SAT3520UERGB
Main Image
Product Images
Product Images
Product Images
Product Images
Product Name 3.5in eSATA USB Dual SATA External HDD Enclosure Product Number SAT3520UERGB UPC 065030832861 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX005X Product Title (Short) 3.5 eSATA USB Dual SATA External HDD Product Title (Standard) 3.5in eSATA USB Dual SATA Hard Drive Enclosure Product Title (Long) 3.5in Silver eSATA USB Dual SATA External Hard Drive Enclosure w/ RAID Title Ingram (Part 1) 3.5in eSATA USB Dual SATA RAID E Title Ingram (Part 2) xternal Hard Drive Enclosure Bullet 1 Supports up to two SATA drives Bullet 2 Supported RAID modes: 0, 1, JBOD, Spanning (BIG), SAFE33 and SAFE50 Bullet 3 Software GUI or on-board DIP switch RAID configuration Bullet 4 SATA revision 2 compliant eSATA interface, with support for transfer rates up to 3 Gbps Bullet 5 High Speed USB 2.0 compliant host interface, with support for transfer rates up to 480 Mbps Marketing Copy Applications - Add external RAID storage solution without worrying about driver or software support
- Businesses requiring external RAID storage for data redundancy
- External storage that is easily transferable between different computer systems
- Large volume external storage for backups/archiving
- Video editing or photography professional/enthusiasts working with very large file sizes
Website Search Keyword - external hard drive enclosure
- 1.5 trabyte tb
Special Notes A port multiplier compatible eSATA port or card is required to use eSATA Accessory Products - USB2HAB6
- USB2HAB10
- PCI220USB
- PEX400USB2
- PEXESATA1
- PEXESATA2I
- CBESATA2
- ECESATA22
- ESATA3
- SATA2ESATA6
- ESATAPLATE1
- ESATAPLATE2
Related Products - SAT3520U2RGB
- SAT3540ERGB
Color Silver TAA Compliant No General Specifications - Enclosure Type: Aluminum
- LED Indicators: Power, HD1, HD2
- Support SATA 1.0 & 2.0 Specification
- AC input: 100-240 VAC
- Drive Type Compatibility: SATA, SATA II, SATA III hard drives
- Fans: 1x 50mm
- Supports JBOD, RAID 0,1, Spanning (JBOD or BIG) + SAFE33/55
- Maximum Data Transfer Rate:
- eSATA - 3 Gbps
- USB 2.0 - 480 Mbps
- Power Adapter Included: Yes (12V 4.2A) 50W with UK Std. Power Cord
- Drive Size: Tested up to 4.0 TB ( 2.0 TB for each bay)
- Chipset: Silcon Image SIL5744
OS Compatibility - Windows ME
- Windows 2000
- Windows XP
- Windows Server 2003
- Windows 7
- Windows Server 2008 R2
- Mac OS X
- Linux
RAID Yes Compatible Drive Types SATA Fans Included? Yes/No Yes Interface/Bridge USB 2.0 Number of Drives 2 Carton Depth (mm) 480 Carton Height (mm) 280 Carton Quantity 6 Carton Weight Gross (g) 13680 Included in Package - 1 - Aluminum Enclosure
- 1 - Instruction Manual
- 1 - Plastic Stand
- 1 - eSATA Cable
- 1 - USB Cable
- 1 - Screw Kit
- 1 - Power Adapter + Power Cord
Package Depth (mm) 155 Package Height (mm) 185 Package Width (mm) 265 Package Weight (g) 2080 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-B (480Mbps, 2.5W) Connector 1 (Quantity) 1 Connector 2 eSATA (7-Pin) Connector 2 (Quantity) 1 en-US Content Approved Yes Product Manager David Muzinic
