SAT3540ERGB
4 Drive eSATA External SATA Drive Enclosure
InfoSafe 4 Drive eSATA External SATA Multi RAID HD Enclosure
Main Image
Product Images
Product Images
Product Name 4 Drive eSATA External SATA Drive Enclosure Product Number SAT3540ERGB UPC 065030832045 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX005X Product Title (Short) 4 Drive eSATA External HDD Enclosure Product Title (Long) 3.5in Silver 4 Drive eSATA RAID External Hard Drive Enclosure Title Ingram (Part 1) 3.5 4 Drive eSATA RAID External Title Ingram (Part 2) Hard Drive Enclosure Website Product Headline InfoSafe 4 Drive eSATA External SATA Multi RAID HD Enclosure Bullet 1 80mm internal fan for enhanced hard drive cooling Bullet 2 Each hard drive bay is hot swappable featuring removable hard drive trays Bullet 3 LEDs to detect Hard Drive activity Bullet 4 Supports data transfer rates up to 3 Gbps Bullet 5 Supports up to four 3.5" SATA I/II Hard Drives, 2 Terabytes each Marketing Copy Applications - Digital/Multimedia file archiving
- DVD Authoring
- JBOD Disk Farms
- Large Audio projects
- Managing large music & image libraries
- Professional grade Audio and Video Editing
- Reliably managing large business databases
- Secure backup
- Video streaming
Website Search Keyword - External Hard Drive Enclosure
- External Hard Drive
Special Notes - The maximum supported partition size for 32-bit Windows systems is 2 TB. Windows cannot detect multiple drives in any RAID mode if the total size exceeds 2TB. Hard drives in non-RAID mode (JBOD) are supported up to 2TB.
Accessory Products - ECESATA22
- ESATA3
- ESATA6
- PEXESATA1
- PEXESATA2
- PEXESATA2I
- SATA2ESATA6
- USB2ESATA
Related Products - ESATCASE2
- SAT2510U2E
- SAT5210U2EGB
Color Silver Product Length (mm) 230 Product Width (mm) 170 Product Height (mm) 146 Product Weight (g) 3400 TAA Compliant No General Specifications - Chipset:
- Comes with a eSATA cable and eSATA to PCI-Express Host Card
- Enclosure Type: Aluminum
- Enclosure: Sil4726
- Fan: 1x 80mm Ball Bearing Fan
- Hard Drive Support: Up to 4 x 2 Terabyte SATA II hard drives in RAID 1
- Host Card: Sil3531
- Power Supply: 12V 8.33A (100-240V, 100w)
OS Compatibility - Linux
- Mac OS X
- Windows 98SE
- Windows ME
- Windows 2000
- Windows XP
- Windows 2003
- Windows Vista
- Windows 7
RAID Yes Compatible Drive Types SATA Fans Included? Yes/No Yes Interface/Bridge eSATA Number of Drives 4 Carton Depth (mm) 550 Carton Height (mm) 290 Carton Quantity 4 Carton Weight Gross (g) 19480 Included in Package - 1 - Drive Enclosure
- 1 - Driver CD
- 1 - eSATA Cable
- 1 - Instruction Manual
- 1 - PCI Express Controller Card
- 1 - Power Supply
- 1 - Screw Kit
Package Depth (mm) 180 Package Height (mm) 270 Package Width (mm) 270 Package Weight (g) 4570 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 eSATA (7-Pin) Connector 1 (Quantity) 1 en-US Content Approved Yes Product Manager David Muzinic
