SATDOCKU2EGB
2.5"/3.5" eSATA/USB 2.0 SATA HDD Dock
Easily connect and swap a 2.5in or 3.5in SATA hard drive through USB or eSATA
Main Image
Product Images
Product Images
Product Images
Product Images
Product Name 2.5"/3.5" eSATA/USB 2.0 SATA HDD Dock Product Number SATDOCKU2EGB UPC 065030834865 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan China Country of Origin North America China Product Title (Short) eSATA USB to SATA External HDD Dock Product Title (Standard) StarTech.com eSATA USB to SATA External HDD Dock for 2.5 or 3.5in - Storage controller - 2.5" / 3.5" shared - SATA-300 - 300 MBps - Hi-Speed USB / eSATA-300 - black Product Title (Long) eSATA USB to SATA External HDD Dock for 2.5 or 3.5in Title Ingram (Part 1) eSATA USB to SATA External HDD D Title Ingram (Part 2) ock for 2.5 or 3.5in Website Product Headline Easily connect and swap a 2.5in or 3.5in SATA hard drive through USB or eSATA Bullet 1 Top slot loading design with drive door Bullet 2 Power/Activity LED indicator Bullet 3 SATA revision 2 compliant eSATA host interface, with support for transfer rates up to 3 Gbps Bullet 4 High Speed USB 2.0 compliant host interface, with support for transfer rates up to 480 Mbps Bullet 5 Compatible with SATA revision 1/2/3 (1.5/3.0/6.0 Gbps) drives Marketing Copy Applications - Access spare or removed 2.5/3.5" drives quickly to retrieve data from
- Data recovery specialists who need quick access to drives for imaging
- Backup data quickly to an external drive for archiving
- Technicians who regularly test or benchmark different hard drives and need to swap between them
- Take advantage of new laptops and desktops with USB 3.0 connectivity
Website Search Keyword - 2.5/3.5
- Convenient
- Dual
- eSATA/USB
- removable
- USB to SATA External HDD Dock
- hot swap
- SATHDOCKU2GB
- SATADOCKU2E
Accessory Products - ESATA3
- ESATA6
- USB2HAB10
- USB2HAB6
- HDDSLEV25
- HDDSLEV35
- SAT2IDEADP
- HDDCASE25BK
- HDDCASE25BL
- HDDCASE25GN
- HDDCASE25WH
- HDDCASE25YW
- HDDCASE25OR
Related Products - SAT3510BUEGB
- SATDOCK2UEGB
- SATDOCKU2GB
- SAT3540ERGB
- SAT2510U2REM
- SAT2510BU2
- SAT3510U2GB
- SAT3510U2BGB
- SAT3510U2REM
- UNI3510UEBGB
Replacement Product SDOCKU33EF Input Voltage 230 AC Output Current 2A Output Voltage (V) 12V DC Power Source AC Adapter Included Plug Type M Center Tip Polarity Positive Color Black Material Plastic Product Length (mm) 140 Product Width (mm) 91 Product Height (mm) 55 Product Weight (g) 221 TAA Compliant No Insertion Rating 15, 000 cycles Max Drive Capacity Currently tested with up to 4TB 5400 RPM 3.5" hard drives and 1TB 5400 RPM 2.5" hard drive OS Compatibility - Linux
- Mac OS X
- Windows 98SE
- Windows ME
- Windows 2000
- Windows XP
- Windows Server 2003
- Windows Vista
- Windows 7
- Windows Server 2008 R2
SATA Type and Rate SATA II (3 Gbps) UASP Support No USB Type and Rate USB 2.0 (480Mbps) Chipset ID JMicron - JM20336 Compatible Drive Types SATA Fans Included? Yes/No No Interface/Bridge USB 2.0 & eSATA LED Indicators 1 - Power/Activity Number of Drives 1 Carton Depth (mm) 190 Carton Height (mm) 380 Carton Quantity 1 Carton Weight Gross (g) 9600 Included in Package - 1 - eSATA Cable
- 1 - Instruction Manual
- 1 - Power Adapter
- 1 - SATA hard drive docking station
- 1 - USB Cable
Package Depth (mm) 92 Package Height (mm) 172 Package Width (mm) 164 Package Weight (g) 840 Packaging Description USB 2.0/eSATA to 2.5"/3.5" SATA HDD Dock Packaging Description India USB 2.0/eSATA to 2.5"/3.5" SATA HDD Dock Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 SATA (7-Pin + 15-Pin) Connector 1 (Quantity) 1 Host Connector 1 USB-B (480Mbps, 2.5W) Host Connector 1 (Quantity) 1 Host Connector 2 eSATA (7-Pin) Host Connector 2 (Quantity) 1 en-US Content Approved Yes Product Manager David Muzinic
