SATDOCKU2EU
2.5 in.-3.5 in. USB 2.0 SATA HDD Dock
Easily connect and swap a 2.5in or 3.5in SATA hard drive through USB
Main Image
Product Images
Product Images
Product Images
Product Images
Product Name 2.5 in.-3.5 in. USB 2.0 SATA HDD Dock Product Number SATDOCKU2EU UPC 065030834872 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 Data Storage Category Level 2 Drive Docking Stations Category Level 3 HDD Docking Stations - 5Gbps Country of Origin Europe & Japan China Country of Origin North America China Product Title (Short) USB to SATA External HDD Docking Station Product Title (Standard) StarTech.com USB to SATA External HDD Docking Station for 2.5 or 3.5in Hard Drive - Storage controller - 2.5"/3.5" shared - SATA-300 - 300 MBps - Hi-Speed USB - black Product Title (Long) USB to SATA External HDD Docking Station for 2.5 or 3.5in Hard Drive Title Ingram (Part 1) USB to SATA External HDD Docking Title Ingram (Part 2) Station 2.5 or 3.5in Website Product Headline Easily connect and swap a 2.5in or 3.5in SATA hard drive through USB Bullet 1 Top slot loading design with drive door Bullet 2 Power/Activity LED indicator Bullet 3 High Speed USB 2.0 compliant host interface, with support for transfer rates up to 480 Mbps Bullet 4 Compatible with SATA revision 1/2/3 (1.5/3.0/6.0 Gbps) drives Bullet 5 Supports 2.5" or 3.5" form factor hard drives (HDD) and solid state drives (SSD) Marketing Copy Applications - Access spare or removed 2.5/3.5" drives quickly to retrieve data from
- Data recovery specialists who need quick access to drives for imaging
- Backup data quickly to an external drive for archiving
- Technicians who regularly test or benchmark different hard drives and need to swap between them
- Take advantage of new laptops and desktops with USB 3.0 connectivity
Website Search Keyword - 2.5/"3.5"
- Adapter
- Hard Drive
- SATHDDDOCKU2
- USB to SATA External HDD Dock
- hot swap
Required Regulatory Compliance Marks FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference Accessory Products - PCI220USB
- PEX400USB2
- USB2HAB10
- USB2HAB6
- HDDSLEV25
- HDDSLEV35
- SAT2IDEADP
- HDDCASE25BK
- HDDCASE25BL
- HDDCASE25GN
- HDDCASE25OR
- HDDCASE25WH
- HDDCASE25YW
Related Products - SAT3510BUEEU
- SATDOCK2UEEU
- SATDOCKU2EEU
- SAT3540EREU
- SAT2510U2
- SAT2510U2REM
- SAT2510BU2
- SAT2510U2S
- SAT2510U2E
- SAT3510U2REM
Replacement Product SDOCKU33BV Input Voltage 230 AC Output Current 2A Output Voltage (V) 12V DC Power Source AC Adapter Included Plug Type M Center Tip Polarity Positive Color Black Material Plastic Product Length (mm) 140 Product Width (mm) 91 Product Height (mm) 55 Product Weight (g) 220 TAA Compliant No Max Drive Capacity Currently tested with up to 4TB 5400 RPM 3.5" hard drives and 1TB 5400 RPM 2.5" hard drive Maximum Data Transfer Rate 480 Mbps OS Compatibility Linux SATA Type and Rate SATA II (3 Gbps) UASP Support No USB Type and Rate USB 2.0 (480Mbps) Compatible Drive Types SATA Fans Included? Yes/No No Interface/Bridge USB 2.0 LED Indicators 1 - Power/Activity Number of Drives 1 Carton Depth (mm) 476 Carton Height (mm) 368 Carton Quantity 1 Carton Weight Gross (g) 6400 Included in Package - 1 - Instruction Manual
- 1 - Power Adapter
- 1 - SATA hard drive docking station
- 1 - USB Cable
Package Depth (mm) 92 Package Height (mm) 173 Package Width (mm) 170 Package Quantity 1 Package Weight (g) 520 Packaging Description USB 2.0 to SATA HDD Docking Station Packaging Description India USB 2.0 to SATA HDD Docking Station Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 SATA (7-Pin + 15-Pin) Connector 1 (Quantity) 1 Host Connector 1 USB-B (480Mbps, 2.5W) Host Connector 1 (Quantity) 1 Amazon Merchandising Manager Veronica Ye Artwork Due Date 2014-06-18 Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Graphic Designer Shane Arnett Primary Technology None Product Development Specialist Pierre Wheeler Product Information Creation Specialist (PICS) Brian Chan Product Manager Tony Parackal Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Tech Lead Justin Weaver Technical Writer Brian Chan Technology Lifecycle Legacy
