SFP-25G-SR-S-C-ST
Enhance the networking infrastructure with this Cisco®-compatible 25GBASE-SR optical transceiver, ensuring reliable performance and seamless connectivity at distances of up to 100m
| Product Name | Cisco SFP-25G-SR-S Compatible 25GBASE-SR SFP28 850nm 100m DO |
|---|---|
| Product Number | SFP-25G-SR-S-C-ST |
| UPC | 065030905329 |
| Lifecycle status | Active |
| Warranty | Lifetime |
| Weighted Opportunity | 21762 |
| Taxonomy | Product > Networking > SFP Transceivers |
| Category Level 1 | Networking |
| Category Level 2 | SFP Transceivers |
| Category Level 3 | Cisco Compatible |
| Country of Origin Europe & Japan | China |
| Country of Origin North America | China |
| Country of Origin History (1) | China |
| Country of Origin Revision (1) | XXXXXX091X |
| Product Title (Ultra-Short) | SFP-25G-SR-S Comp. |
|---|---|
| Product Title (Short) | Cisco Comp. SFP-25G-SR-S, 25Gb, SFP28 |
| Product Title (Medium) | StarTech.com Cisco SFP-25G-SR-S Compatible SFP28, 25GbE, MMF, 100m, 850nm, LC |
| Product Title (Standard) | Cisco SFP-25G-SR-S Compatible SFP28 Module, 25Gb Multimode Fiber (MMF), 25GBASE-SR LC Transceiver, 100m (328ft), DDM/DOM |
| Product Title (Long) | Cisco SFP-25G-SR-S Compatible SFP28 Module, 25Gbps Multimode Fiber (MMF), 100m (328ft), LC Connector, 850nm, MSA 25 Gigabit Optical Transceiver |
| Product Title (AMZ) | Cisco SFP-25G-SR-S Compatible SFP28 Module, 25Gb Multimode Fiber (MMF), 25GbE 100m (328ft), LC Transceiver |
| Title Ingram (Part 1) | Cisco SFP-25G-SR-S Compatible - |
| Title Ingram (Part 2) | 25G SFP28, 850nm, 100m, DDM, LC |
| Website Product Headline | Enhance the networking infrastructure with this Cisco®-compatible 25GBASE-SR optical transceiver, ensuring reliable performance and seamless connectivity at distances of up to 100m |
| Bullet 1 | CISCO COMPATIBLE TRANSCEIVER: Equivalent to the Cisco® SFP-25G-SR-S MMF module; Programmed and tested to ensure seamless integration with Cisco® switches and routers to deliver reliable 25G connectivity up to 100m (328ft) |
| Bullet 2 | MAXIMIZE BANDWIDTH: 25Gb multi-mode fiber SFP28 excels at bandwidth-intensive tasks such as data migrations, large-scale transfers, high-performance storage, seamless content streaming, and rapid online content uploads |
| Bullet 3 | TECHNICAL SPECS: 25GBASE-SR SFP28; 25Gbps; Multi Mode Fiber (MMF); LC Connector; 850nm Tx/Rx; Distances up to 100m (328ft); Supports Digital Diagnostics Monitoring (DDM/DOM) |
| Bullet 4 | COMPATIBLE WITH MSA COMPLIANT SWITCHES: Fiber optic transceiver is compatible with switch models from Ubiquiti®, D-Link®, Netgear®, Supermicro®, TP-Link®, and other brands that support uncoded modules |
| Bullet 5 | THE IT PRO'S CHOICE: Designed and built for IT Professionals, this 25 Gigabit optical transceiver is backed for life, including free lifetime 24/5 multi-lingual technical assistance |
| Bullets (Compact) | Equivalent to Cisco SFP-25G-SR-S fiber transceiver - 25GbE connectivity up to 100m - For data migrations, large-scale transfers, high-capacity storage - 25GBASE-SR SFP28, 25Gbps, MMF, LC connector, 850nm, DDM/DOM, MSA-compliant - Lifetime warranty |
| Bullets (Consolidated) | - Cisco-compatible SFP28 transceiver equivalent to SFP-25G-SR-S MMF module; Tested for seamless integration with Cisco switches/routers for reliable 25Gbps connectivity up to 100m (328ft) - Maximize bandwidth for data migrations/high-capacity network storage/Multimedia upload - Technical Specs: 25GBASE-SR SFP28/25GbE/Multimode Fiber (MMF)/LC Duplex connector/850nm/DDM/DOM - Works w/ MSA-compliant switches that accept uncoded fiber modules - This 25 Gigabit optical transceiver is backed for life |
| Marketing Copy | |
| Marketing Copy (No HTML) |
| Required Regulatory Compliance Marks |
|
|---|
| Related Products |
|
|---|
| Power Consumption (In Watts) | <1.2 W |
|---|
| Humidity | 85% RH |
|---|---|
| Operating Temperature | 0°C to 70°C (32°F to 158°F) |
| Product Length (mm) | 56.500 |
| Product Width (mm) | 13.900 |
| Product Height (mm) | 8.500 |
| Product Weight (g) | 200.000 |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| TAA Compliant | No |
| Compatible Networks | 25 Gbps |
|---|---|
| Digital Diagnostics Monitoring Support | Yes |
| Fiber Operating Mode | Full-Duplex |
| Fiber Type | Multi Mode |
| Maximum Data Transfer Rate | 25.78 Gbps |
| Max Transfer Distance | 100m [328ft] |
| MTBF (hours) | 4,020,594 Hours at 55°C (131°F) |
| Wavelength | 850nm |
| Fiber Connector | LC |
|---|---|
| Industry Standards | IEEE 802.3cc 25GBASE-LR |
| SFP Compatible Brand | Cisco |
| Carton Depth (mm) | 340 |
|---|---|
| Carton Height (mm) | 350 |
| Carton Quantity | 100 |
| Carton Weight Gross (g) | 5500 |
| Included in Package | 1 - SFP+ Transceiver |
| Package Depth (mm) | 91 |
| Package Height (mm) | 33 |
| Package Width (mm) | 113 |
| Package Weight (g) | 46 |
| Packaging Description | SFP-25G-SR-S Compatible 25GBase-SR SFP28 Transceiver, MMF/850nm/100m/LC |
| Packaging Description India | SFP-25G-SR-S Compatible 25GBase-SR SFP28 Transceiver, MMF/850nm/100m/LC |
| Sub-Carton Depth (mm) | 0 |
| Sub-Carton Height (mm) | 0 |
| Sub-Carton Width (mm) | 0 |
| Sub-Carton Weight (g) | 0 |
| Connector 1 | SFP Slot |
|---|---|
| Connector 1 (Quantity) | 1 |
| Connector 2 | SFP28 (25Gbps) |
| Connector 2 (Quantity) | 1 |
| Connector 3 | LC Duplex Fiber |
| Connector 3 (Quantity) | 1 |
| Actual Inbox Documents Created | None |
|---|---|
| Amazon Merchandising Manager | Kathleen Marshall |
| Application Photos | Uploaded |
| Artwork Due Date | 2023-11-10 |
| Buying Center - AV & Collaboration | No |
| Buying Center - Data Center | Yes |
| Buying Center - End User Compute | No |
| Buying Center - Networking & Edge | Yes |
| Comparable SKU Comment | Cisco FET-10G Compatible SFP+ Module - 10GBASE-USR - 10GbE Multimode Fiber MMF Optic Transceiver - 10GE Gigabit Ethernet SFP+ - LC 300m - 850nm - DDM Cisco Nexus 2000 |
| Comparable SKU 2 Comment | Cisco QSFP-40G-SR4-S Compatible QSFP+ Module - 40GBASE-SR4 - 40GbE Multimode Fiber MMF Optic Transceiver - 40GE Gigabit Ethernet QSFP+ - MPO 100m - 850nm - DDM Cisco Firepower, ASR9000, ASR1000 |
| Digital Content Due Date | 2023-11-14 |
| Enhanced Gallery Designer | Catherine Almeida |
| en-US Content Approved | Yes |
| Focus Rank | Level 0 - Not Applicable |
| Graphic Designer | Shane Arnett |
| ID Label Silkscreened or a Label | Sticker label - custom size - requires size population below |
| Launch Markets (concatenated) | AT,AU,BE,CA,CH,CL,CO,DE,DK,ES,FI,FR,HK,IE,IN,IT,JP,MX,NL,NZ,PE,SE,SG,UK,US |
| Product Development Specialist | Ray Aoki |
| Product Information Creation Specialist (PICS) | Alex Garcia |
| Product Manager | Rob Fleck |
| Product Performance Specialist | Ray Aoki |
| Product Photographer | Alejandra Valencia |
| Target Development Completion Date | 2023-10-06 |
| Target Production Release | 2023-10-31 |
| Tech Lead | Stefan Tirolese |
| Technical Writer | Alex Garcia |
| Technology Lifecycle | None |
