SFP10GBBXDST
MSA Compliant 10GBase BX SFP Transceiver Module
10 Gbps | Single Mode Fiber | LC | 10 km (6.2 mi) | Lifetime Warranty
Main Image
Product Images
Product Images
Product Name MSA Compliant 10GBase BX SFP Transceiver Module Product Number SFP10GBBXDST UPC 065030873413 Lifecycle status End of Life Warranty Lifetime Taxonomy Product > Networking > SFP Transceivers Category Level 1 Networking Category Level 2 SFP Transceivers Category Level 3 Uncoded SFP Transceivers Family Uncoded 10G SFP Modules - BiDi Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX091X Product Title (Ultra-Short) 10GBase-BX SFP+ - SM Product Title (Short) MSA Uncoded SFP+ Transceiver Module Product Title (Medium) 10GBASE-BX MSA Downstream SFP+ Module - Lifetime Warranty - 10 Gbps - LC SFP+ Product Title (Standard) MSA Uncoded SFP+ Transceiver Module - 10GBASE-BX - 10 GbE Gigabit Ethernet BiDi Fiber (SMF) Product Title (Long) MSA Uncoded SFP+ Transceiver Module - 10GBASE-BX - 10 GbE Gigabit Ethernet BiDi Fiber (SMF) Product Title (AMZ) MSA Uncoded SFP+ Module - 10GBASE-BX - 10 Gigabit Ethernet BiDi Fiber Single Strand SFP+ Transceiver - LC 10km - MSA Compliant (SFP10GBBXDST) Title Ingram (Part 1) 10GBASE-BX MSA Compliant Title Ingram (Part 2) Downstream LC Fiber SFP+ Module Website Product Headline 10 Gbps | Single Mode Fiber | LC | 10 km (6.2 mi) | Lifetime Warranty Bullet 1 MSA UNCODED SFP+ TRANSCEIVER: 10 Gigabit Ethernet BiDi Fiber Single Strand SFP+ designed, programmed and tested to work with compatible MSA Compliant switches and routers to deliver reliable 10GbE connectivity Bullet 2 INCREASE BANDWIDTH ON EXISTING INFRASTRUCTURE: This 10 Gigabit Ethernet bi-directional WDM SFP+ transceiver module sends and receives over a single strand of fiber optic cable instead of two. Bullet 3 TECHNICAL SPECS: 10GBASE-BX | 10Gbps | 10G Bi-Directional Downstream | Single Mode (SMF) | LC Connector | 1330nmTx/1270nmRx | Digital Diagnostic Monitoring (DDM) | Distances up to 10km (6.2mi). Bullet 4 THE IT PRO’S CHOICE: Designed and built for IT Professionals, this SFP module is backed for life (lifetime of module, not network switch), including free lifetime 24/5 multi-lingual technical assistance Bullet 5 WORKS WITH MSA COMPLIANT SWITCHES: Works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules Bullets (Compact) MSA Uncoded Transceiver - 10GBASE-BX WDM SFP+ (10 Gbps) - 10 Gigabit BiDi Module - 1330nmTx/1270nmRx Single Mode (SMF) - 10km (6.2mi) - LC Connector & DDM - Hot-Swappable / MSA Compliant - Lifetime Warranty Bullets (Consolidated) MSA Uncoded SFP+ 10GBASE-BX ([NETWROKSPEED]) - 1330nmTx/1270nmRx Single Mode (SMF) 10GE BiDi Transceiver - Up to 10km (6.2mi) - 10 Gigabit Ethernet - Single Strand WDM SFP+ SMF Connector | DDM - Hot-Swappable | MSA Compliant - Backed by StarTech.com lifetime warranty on the module itself - not the life of the OEM switch/router and will not void OEM warranty Marketing Copy Marketing Copy (No HTML) Applications - Replace defective or damaged SFP+ modules
- Expand your network to remote segments
Website Search Keyword - fiber sfp
- DDM
- DOM
- 10GBase-BX SFP+
- 10GBase-BX SFP+ Module
- MSA Compliant SFP+
- 10G SFP+
- SM SFP+
- Single-mode SFP+
- 10 Gigabit SFP+
- fiber sfp+
- 10 Gigabit SFP+ module
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- UL Recognized - Safety - Electrical - Canada / United States - cURus Recognised Component Mark
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
Accessory Products - SMFIBLCLC1
- SMFIBLCLC4
- SMFIBLCLC7
- SMFIBLCLC10
- PEX20000SFPI
- PEX10000SFP
- PEX10000SFPI
- ET10GSFP
Power Consumption (In Watts) < 1 W Color Silver Humidity 5~95% RH Material Aluminum Operating Temperature 0°C to 70°C (32°F to 158°F) Primary Material Aluminum Product Length (mm) 58.400 Product Width (mm) 13.900 Product Height (mm) 12.600 Product Weight (g) 24.000 Storage Temperature -40°C to 85°C (-40°F to 185°F) TAA Compliant No Compatible Networks 10 Gbps Digital Diagnostics Monitoring Support Yes Fiber Operating Mode Full-Duplex Fiber Type Single Mode Maximum Data Transfer Rate 10 Gbps Max Transfer Distance 10 km (6.2 mi) Wavelength 1330nmTx/1270nmRx Fiber Connector LC Industry Standards IEEE 802.3ae 10GBASE-BX SFP Compatible Brand MSA Compliant Wave Division Multiplexing (WDM) Yes Carton Depth (mm) 315 Carton Height (mm) 315 Carton Quantity 80 Carton Weight Gross (g) 5000 Included in Package 1 - SFP+ transceiver Package Depth (mm) 94 Package Height (mm) 30 Package Width (mm) 114 Package Quantity 1 Package Weight (g) 52 Packaging Description MSA Compliant 10 Gb Fiber SFP+ - 10GBase-BX (Downstream) - SM Packaging Description India MSA Compliant 10 Gb Fiber SFP+ - 10GBase-BX (Downstream) - SM Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Host Connector 1 LC Duplex Fiber Host Connector 1 (Quantity) 1 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2017-05-05 Buying Center - AV & Collaboration No Buying Center - Data Center Yes Buying Center - End User Compute No Buying Center - Networking & Edge Yes Digital Content Due Date 2017-05-09 Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,DE,DK,ES,EU,FR,IE,IN,IT,JP,NL,NZ,SE,UK,US Primary Technology None Product Development Specialist Ray Aoki Product Information Creation Specialist (PICS) Alex Garcia Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Target Development Completion Date 2017-04-14 Target Production Release 2017-05-05 Tech Lead Stefan Tirolese Technical Writer Alex Garcia Technology Lifecycle None
