Main Image
SFPF1302C
100Base-FX Multi Mode SFP Fiber Transceiver LC
100 Mbps | Multi Mode Fiber | LC | 2 km (1.2 mi) | Lifetime Warranty
Main Image
Product Images
Product Images
Product Images
Product Name 100Base-FX Multi Mode SFP Fiber Transceiver LC Product Number SFPF1302C UPC 065030846370 Lifecycle status Active Warranty Lifetime Taxonomy Product > Networking > SFP Transceivers Category Level 1 Networking Category Level 2 SFP Transceivers Category Level 3 Cisco Compatible Family Cisco Compatible - 100 Mbps SFP Modules Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX091X Product Title (Ultra-Short) 100Mb Fiber SFP LC Product Title (Short) Cisco GLC-FE-100FX Comp. SFP 100MbE DDM Product Title (Medium) Cisco GLC-FE-100FX Compatible SFP Fiber Module - 100BASE-FX - Lifetime Warranty Product Title (Standard) Cisco GLC-FE-100FX Compatible SFP Module - 100BASE-FX - 100 Mbps 100Mbps Multimode Fiber MMF Optic Transceiver - 2km Product Title (Long) Cisco GLC-FE-100FX Compatible SFP Module - 100BASE-FX - 100Mbps Multimode Fiber MMF Optic Transceiver - 100 Mbps - LC 2km - 1310nm - DDM Cisco ASR920, IE2000, IE4000 Product Title (AMZ) Cisco GLC-FE-100FX Compatible SFP Module - 100BASE-FX - 100Mbps Multimode Fiber MMF Optic Transceiver - 100 Mbps - LC 2km - 1310nm - DDM Cisco ASR920, IE2000, IE4000 (SFPF1302C) Title Ingram (Part 1) Cisco GLC-FE-100FX Comp. - Title Ingram (Part 2) SFP Module - Fiber Transceiver Website Product Headline 100 Mbps | Multi Mode Fiber | LC | 2 km (1.2 mi) | Lifetime Warranty Bullet 1 100% CISCO GLC-FE-100FX COMPATIBLE: Works with Cisco switches like ASR920, IE2000, IE4000, IR1101, ISR1100 and others Bullet 2 TECHNICAL SPECS: 100BASE-FX | 100 Mbps | Multi Mode (MMF) | LC Connector | 1310nm | Digital Diagnostic Monitoring (DDM) | Distances up to 2km (1.2mi) Bullet 3 TESTED FOR OEM HOST COMPATIBILITY: Hot-swappable in Cisco routers and switches; DDM support reports the transceiver's status to most SNMP network management tools Bullet 4 THE IT PRO’S CHOICE: Designed and built for IT Professionals, this SFP module is backed for life (lifetime of module, not network switch), including free lifetime 24/5 multi-lingual technical assistance. Bullet 5 WORKS WITH MSA COMPLIANT SWITCHES: Also works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules Bullets (Compact) Cisco GLC-FE-100FX Compatible SFP - 100BASE-FX 100 Mbps - 100MbE Module - 100 Mbps 1310nm - Multi Mode (MMF) Transceiver - 2km (1.2mi) - LC Connector DDM - Hot-Swappable & MSA Compliant - Lifetime Warranty Bullets (Consolidated) Cisco GLC-FE-100FX Compatible SFP 100BASE-FX (100 Mbps) Gigabit Ethernet - 1310nm | Multi Mode (MMF) - Up to 2km (1.2mi) - LC Connector DDM - For Cisco switches like: ASR920 IE2000 IE4000 IR1101 ISR1100 ISR4000 IE1000 IE5000 - Hot-Swappable and MSA Compliant - Backed by a StarTech.com lifetime warranty on the module itself not the life of the OEM switch/router and will not void your OEM warranty Marketing Copy Marketing Copy (No HTML) Applications - Replacing defective or damaged SFPs/Mini GBICs in MSA or Cisco compliant equipment
- Expand your network to remote segments
Website Search Keyword - SFP Module
- GBIC Module
- mini GBIC
- MSA
- Cisco
- Fiber transceiver
- fiber optic transceiver
- fiber optical transceiver
- Fibre transceiver
- fibre optic transceiver
- fibre optical transceiver
- fiber sfp
- fibre sfp
- lc sfp
- multi mode sfp
- GLC-FE-100FX
- Cisco GLC-FE-100FX
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
Special Notes For use in 100 Mbps fiber networking equipment and media converters System and Cable Requirements MSA or Cisco compliant SFP port Accessory Products - 50FIBLCLC3
- 50FIBLCLC2
- 50FIBLCLC10
- 50FIBLCLC30
- 50FIBLCLC1
- 50FIBLCLC5
Related Products - SFPSXMM
- SFPLHSM
- SFPF1340C
- SFPG1320C
- SFPG1340C
- SFPG1580C
- SFPF1320C
Power Consumption (In Watts) < 1 W Humidity 30~70% RH Material Steel Operating Temperature 0°C to 70°C (32°F to 158°F) Primary Material Steel Product Length (mm) 65.000 Product Width (mm) 9.000 Product Height (mm) 14.000 Product Weight (g) 25.000 Storage Temperature -40°C to 85°C (-40°F to 85°F) TAA Compliant No Compatible Networks 100 Mbps Digital Diagnostics Monitoring Support Yes Fiber Operating Mode Half/Full-Duplex Fiber Type Multi Mode Maximum Data Transfer Rate 155 Mbps Max Transfer Distance 2 km (1.2 mi) MTBF (hours) 1,472,572 hours Wavelength 1310nm Fiber Connector LC Industry Standards IEEE 802.3u 100BASE-FX OEM Part Number GLC-FE-100FX SFP Compatible Brand Cisco Wave Division Multiplexing (WDM) No Carton Depth (mm) 260 Carton Height (mm) 201 Carton Quantity 36 Carton Weight Gross (g) 2060 Included in Package 1 - 155 Mbps Multi Mode LC SFP Package Depth (mm) 113 Package Height (mm) 33 Package Width (mm) 92 Package Quantity 1 Package Weight (g) 46 Packaging Description 155 Mbps 1310nm LC Multi Mode Fiber SFP 2km Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Host Connector 1 LC Duplex Fiber Host Connector 1 (Quantity) 1 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2014-06-18 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute No Buying Center - Networking & Edge Yes Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,DE,DK,ES,EU,FR,IE,IN,IT,JP,NL,NZ,SE,UK,US Primary Technology None Product Development Specialist Ray Aoki Product Information Creation Specialist (PICS) Alex Garcia Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Tech Lead Stefan Tirolese Technical Writer Andrew Richardson Technology Lifecycle None
