Main Image
SFPLHSM
Gigabit SM SFP Mini GBIC Fiber Optical Transceiver
Add, replace or upgrade SFP modules on gigabit fiber equipment
Main Image
Product Images
Product Images
Product Name Gigabit SM SFP Mini GBIC Fiber Optical Transceiver Product Number SFPLHSM UPC 065030834957 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX016X Product Title (Short) Gigabit SM SFP Fiber Transceiver LC Product Title (Standard) StarTech.com Gigabit Single Mode SFP Fiber Optical Transceiver - Mini GBIC - 1310 nm - LC - 40km Product Title (Long) Gigabit 1310nm Single Mode SFP Fiber Optical Transceiver - LC 40km Product Title (AMZ) Gigabit 1310nm Single Mode SFP Fiber Optical Transceiver - LC 40km - 1Gbps 1000base-LH Mini-GBIC - MSA Compliant LC Module (SFPLHSM) Title Ingram (Part 1) Gigabit 1310nm SM SFP Fiber Opti Title Ingram (Part 2) cal Transceiver - LC 40km Website Product Headline Add, replace or upgrade SFP modules on gigabit fiber equipment Bullet 1 1.25Gbps IEEE 802.3z 1000BASE-LH Compliant Bullet 2 Complies with SFP Multi-Source Agreements standards (MSA) Bullet 3 Duplex LC receptacle connector Bullet 4 Equipped with a 1310nm DFP Laser with Class 1 laser safety standards IEC825 compliance Bullet 5 Fully Hot Pluggable Marketing Copy Applications - Use in long haul single mode fiber installations
- Expand your network to remote segments over fiber
- Perfect for network extension and fiber backbones
- Replacing defective or damaged SFPs in MSA compliant equipment
Website Search Keyword - 1000Base-LH
- 50/125
- 62.5/125
- 1310nm
- Duplex LC
- Fiber Optic
- Fiber Transceiver
- Fibre Optic
- GBIC Module
- Gigabit Fiber
- miniGBIC
- MSA
- Single Mode Fiber
- singlemode Fiber
- SFP Module
- Cisco
Accessory Products SMFIBLCSC1 Related Products - ET1000SM40LC
- ET90110SM30
- ET90110WDM
- ET91000LC
- ET91000LCEU
- ET91000LCGB
- ET91000MMSM
- ET91000SC
- ET91000SM40
- SFPSXMM
Humidity 5 to 95% RH Operating Temperature 0°C to 70°C (32°F to 158°F) Product Length (mm) 55.000 Product Width (mm) 13.000 Product Height (mm) 9.000 Product Weight (g) 17.200 Storage Temperature -40°C to 85°C (-40°F to 85°F) TAA Compliant No Compatible Networks 1000 Mbps (1 Gbps) Digital Diagnostics Monitoring Support No Fiber Operating Mode Full-Duplex Fiber Type Single Mode Maximum Data Transfer Rate 1.25 Gbps Max Transfer Distance 40 km (24.8 mi) Wavelength 1310nm Fiber Connector LC Industry Standards IEEE 802.3z 1000BASE-LH Carton Depth (mm) 220 Carton Height (mm) 210 Carton Quantity 100 Carton Weight Gross (g) 3746 Included in Package 1 - SFP Single Mode LC Transceiver Package Depth (mm) 25 Package Height (mm) 65 Package Width (mm) 115 Package Weight (g) 40 Packaging Description 1 Gigabit LC Single Mode Fiber SFP 40km Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 LC Duplex Fiber Connector 1 (Quantity) 1 en-US Content Approved Yes Product Manager Daryl Hunt
