Main Image
SFPSXMM
Gigabit MM SFP Mini GBIC Fiber Optical Transceiver
1000 Mbps (1 Gbps) | Multi Mode Fiber | LC | 550 m (1804 ft) | TAA | Lifetime Warranty
Main Image
Product Images
Product Images
Product Images
Product Name Gigabit MM SFP Mini GBIC Fiber Optical Transceiver Product Number SFPSXMM UPC 065030834940 Lifecycle status Active Warranty 2 Years Taxonomy Product > Networking > SFP Transceivers Category Level 1 Networking Category Level 2 SFP Transceivers Category Level 3 Uncoded SFP Transceivers Family Uncoded 1G SFP Modules Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX016X Product Title (Short) MSA Uncoded SFP Transceiver - 1GbE DDM Product Title (Medium) 1000BASE-SX MSA Compliant SFP Module - TAA - Lifetime Warranty - 1 Gbps - LC SFP Product Title (Standard) MSA Uncoded SFP Module, 1000BASE-SX, 1GE Gigabit Ethernet SFP 1GbE Multi Mode Fiber (MMF) Optic Transceiver, 550m DDM, TAA Product Title (Long) MSA Uncoded SFP Module - 1000BASE-SX - 1GbE Multi Mode Fiber (MMF) Optic Transceiver - 1GE Gigabit Ethernet SFP - LC 550m - 850nm - DDM - TAA Product Title (AMZ) MSA Uncoded Compatible SFP Module - 1000BASE-SX - 1GbE Multi Mode Fiber (MMF) Optic Transceiver - 1GE Gigabit Ethernet SFP - LC 550m - 850nm - DDM , TAA (SFPSXMM) Title Ingram (Part 1) 1000BASE-SX MSA Compliant Title Ingram (Part 2) LC Fiber SFP Module - TAA Compliant Website Product Headline 1000 Mbps (1 Gbps) | Multi Mode Fiber | LC | 550 m (1804 ft) | TAA | Lifetime Warranty Bullet 1 TESTED FOR COMPATIBILITY: Hot-swappable in MSA Compliant routers and switches Bullet 2 WORKS WITH MSA COMPLIANT SWITCHES: Works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules Bullet 3 100% MSA UNCODED SFP TRANSCEIVER: Designed, programmed and tested to work with compatible MSA Compliant switches and routers to deliver reliable 1GbE connectivity Bullet 4 TECHNICAL SPECS: 1000BASE-SX | 1Gbps | Multi Mode (MMF) | LC Connector | 850nm | Digital Diagnostic Monitoring (DDM) | Distances up to 550m (1804ft) Bullet 5 THE IT PRO’S CHOICE: Designed and built for IT Professionals, this SFP module is backed for life (lifetime of module, not network switch), including free lifetime 24/5 multi-lingual technical assistance Bullets (Compact) MSA Uncoded SFP - 1000BASE-SX 1Gbps - 1GbE Module - 1GE Gigabit Ethernet SFP 850nm Multi Mode (MMF) Transceiver - 550m (1804ft) - LC Connector DDM - Hot-Swappable & MSA Compliant - Lifetime Warranty Bullets (Consolidated) MSA Uncoded SFP Module - 1000BASE-SX 1Gbps Gigabit Ethernet - 850nm Multi Mode (MMF) - Up to 550m (1804') - LC Connector DDM - Designed, programmed and tested to work with compatible MSA compliant switches and routers - Hot-Swappable and MSA Compliant - Backed by a StarTech.com lifetime warranty on the module itself not the life of the OEM switch/router and will not void your OEM warranty Marketing Copy Marketing Copy (No HTML) Applications - Replace defective or damaged SFP modules
- Expand your network to remote segments
Website Search Keyword - SFP Module
- GBIC Module
- miniGBIC
- Gigabit Fiber
- Fiber Optic
- Fibre Optic
- MSA
- multimode Fiber
- Multi Mode Fiber
- 50/125
- 62.5/125
- 1000Base-SX
- 850nm
- Duplex LC
- Fiber Transceiver
- Cisco
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
Accessory Products - 50FIBLCLC1
- 50FIBLCLC2
- 50FIBLCLC3
- 50FIBLCLC5
- 50FIBLCLC10
- PEX1000SFP2
- IES101002SFP
- IES101GP2SFW
- IES101G2SFPW
- MCM1110SFP
Related Products - SFPLHSM
- ET91000LC
- ET91000LCGB
- ET91000LCEU
- ET1000SM40LC
- ET91000SM40
- ET90110WDM
- ET91000MMSM
- ET90110SM30
- ET91000SC
Output Voltage (V) 3.3V DC Power Consumption (In Watts) < 1 W Color Silver Humidity 5 to 95% RH Material Steel Operating Temperature 0°C to 70°C (32°F to 158°F) Primary Material Steel Product Length (mm) 55.000 Product Width (mm) 13.000 Product Height (mm) 9.000 Product Weight (g) 18.000 Storage Temperature -40°C to 85°C (-40°F to 85°F) TAA Compliant Yes Compatible Networks 1000 Mbps (1 Gbps) Digital Diagnostics Monitoring Support Yes Fiber Operating Mode Full-Duplex Fiber Type Multi Mode Maximum Data Transfer Rate 1.25 Gbps Max Transfer Distance 550m [1804ft] MTBF (hours) 78,286 hours Wavelength 850nm Fiber Connector LC Industry Standards IEEE 802.3z 1000BASE-SX SFP Compatible Brand MSA Compliant Carton Depth (mm) 284 Carton Height (mm) 376 Carton Quantity 100 Carton Weight Gross (g) 5764 Included in Package 1 - SFP Multimode LC Transceiver Number of Sub-Cartons 10 Package Depth (mm) 65 Package Height (mm) 27 Package Width (mm) 113 Package Quantity 1 Package Weight (g) 40 Packaging Description Gigabit Multimode LC Fiber SFP - 550m Sub-Carton Depth (mm) 342 Sub-Carton Height (mm) 146 Sub-Carton Width (mm) 256 Sub-Carton Quantity 10 Sub-Carton Weight (g) 462 Host Connector 1 LC Duplex Fiber Host Connector 1 (Quantity) 1 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2014-06-18 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute No Buying Center - Networking & Edge Yes Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,DE,DK,ES,EU,FR,IE,IN,IT,JP,MX,NL,NZ,SE,SG,UK,US Primary Technology None Product Development Specialist Ray Aoki Product Information Creation Specialist (PICS) Alex Garcia Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Tech Lead Stefan Tirolese Technical Writer Andrew Richardson Technology Lifecycle None
