SMDOS2LCLC2M
Duplex Singlemode 9 125 OS2 Fiber Patch Cable LC LC 2M 6
Enhance the performance capabilities of CWDM applications over an OS2 fiber network
Main Image
Product Images
Product Images
Product Images
BOM Image
Product Name Duplex Singlemode 9 125 OS2 Fiber Patch Cable LC LC 2M 6 Product Number SMDOS2LCLC2M UPC 065030902083 Lifecycle status Active Warranty Lifetime Taxonomy Product > Cables > Fiber Network Cables Category Level 1 Network Cables Category Level 2 Fiber Cables Category Level 3 Singlemode Fiber Cables Family OS2 Single Mode Country of Origin Europe & Japan Vietnam Country of Origin North America Vietnam Country of Origin History (1) Vietnam Country of Origin Revision (1) XXXXXX001X Country of Origin History (2) Vietnam Country of Origin Revision (2) XXXXXX145X Product Title (Ultra-Short) OS2 LC Fiber Cable Product Title (Short) 2m LC/LC OS2 Single Mode Fiber Cable Product Title (Medium) 2m (6.6ft) LC to LC (UPC) OS2 Single Mode Duplex Fiber Cable, 9/125µm, LSZH Product Title (Standard) 2m (6.6ft) LC to LC (UPC) OS2 Single Mode Duplex Fiber Optic Cable, 9/125, 100G, Low Insertion Loss, LSZH Fiber Jumper Cord Product Title (Long) 2m (6.6ft) LC to LC (UPC) OS2 Single Mode Duplex Fiber Optic Cable, 9/125µm, 100G, Bend Insensitive, Low Insertion Loss - LSZH Fiber Jumper Cord Product Title (AMZ) 2m (6.6ft) LC to LC (UPC) OS2 Single Mode Duplex Fiber Optic Cable, 9/125, 100G, LSZH Fiber Jumper Cord Title Ingram (Part 1) LC/LC Single Mode Fiber Cable Title Ingram (Part 2) OS2/UPC/Duplex/LSZH Website Product Headline Enhance the performance capabilities of CWDM applications over an OS2 fiber network Bullet 1 OS2 FIBER CABLE: Single Mode OS2 Fiber Cable is immune to EMI and optimized for 100Gbps networks; Coarse Wavelength Division Multiplexing (CWDM) enables extended 1260-1625nm wavelength support for greater channel isolation over long distances Bullet 2 QUALITY CONSTRUCTION: LC/LC-UPC ends for improved return loss over PC polish; Numbered and color-coded connectors to indicate polarity; Bend Insensitive fiber core housed in Aramid-reinforced jacket for a loaded bend radius of 10mm Bullet 3 SAFETY AND RELIABILITY: Individually tested for guaranteed performance; Test report included; LSZH jacket emits low toxic fumes if combusted; Safe for enclosed/poorly ventilated spaces; Attenuation value under 0.35dB/km outperforms industry standards Bullet 4 COMPATIBILITY: Single Mode Fiber Patch Cord supports 100G networks; Backward compatible with OS1; High micro-bend resistance facilitates tight bends in complex installations; Ideal for connecting between servers/switches and data center equipment Bullet 5 SPECS: 2 meter (6.6 foot); OS2 Single Mode; LC/LC (UPC) Duplex; 100Gbps; 9/125um; 1260-1625nm Laser Optimized; Insertion Loss: ≤0.3dB; Return Loss: ≥55dB; Cable OD: 2mm; Bend Radius: 10mm (0.39in) loaded/unloaded Bullets (Compact) 6.6ft LC/LC-UPC OS2 Single Mode Fiber Cable supports 100G networks and CWDM; 9/125um core/cladding; 1260-1625nm Laser Optimized; LSZH jacket w/molded strain reliefs; Bend Radius: 10mm (loaded/unloaded); Insertion Loss: ≤0.3dB; Return Loss: ≥55dB Bullets (Consolidated) - 6.6ft LC/LC-UPC OS2 Single Mode fiber cable is optimized for 100G networks; Coarse Wavelength Division Multiplexing (CWDM) enables extended 1260-1625nm wavelength support for long distance channel isolation - UPC-polished ends for minimal return loss; Molded strain reliefs; Bend Insensitive Fiber Core in Aramid-reinforced LSZH Jacket for a loaded bend radius of 10mm - Connect between servers/switches and data center equipment - 9/125µm; OD: 2mm; Temp Range: -20 to 60C (-4 to 140F) Marketing Copy Marketing Copy (No HTML) Applications - Use in 100 Gigabit Ethernet and fiber-channel applications
- For high-speed, low-latency connections between servers, switches, and storage devices
- Enable seamless data transmission with minimal signal loss
Website Search Keyword - fiber optic patch cord
- single mode fiber optic cable
- single mode fiber patch cable
- duplex fiber patch cable
- fiber optic patch cable
- Single Mode Fiber Cable
Required Regulatory Compliance Marks - Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- EU RIC + Italian Sorting - Packaging - Waste - European Union - Corrugated Fiberboard
- Triman/Info-Tri - Packaging - Waste - European Union - Paper Box
Cable Length (mm) 2000 Cable OD 2 Color Yellow Connector Style Straight Humidity 40% - 70% Material Polypropylene (PP) Operating Temperature -20°C - 60°C (-4°F - 140°F) Product Length (mm) 2000.000 Product Width (mm) 12.500 Product Height (mm) 10.200 Product Weight (g) 20.000 Storage Temperature -20°C - 60°C (-4°F - 140°F) TAA Compliant No Cable Rating 10Gbps / 40Gbps / 100Gbps Fiber Type Single Mode General Specifications Maximum Data Transfer Rate 100Gbps Wavelength 1260nm to 1625nm Active or Passive Adapter Passive Cable Jacket Material Low Smoke Zero Halogen Classification OS2 Fiber Cable Type Duplex Fiber Classification OS2 Fiber Size 9/125 Fire Rating LSZH Rated (Low Smoke Zero Halogen) Carton Depth (mm) 450 Carton Height (mm) 300 Carton Quantity 350 Carton Weight Gross (g) 12000 Included in Package - 1 - 2m OS2 Single Mode Fiber Optic Cable - LC to LC
- 1 - Test Report
Number of Sub-Cartons 35 Package Depth (mm) 200 Package Height (mm) 18 Package Width (mm) 149 Package Weight (g) 28 Packaging Description 2m (6ft) OS2 Single Mode Duplex Fiber Optic Cable - LC to LC Packaging Description India 2m OS2 Single Mode Duplex Fiber Optic Cable - LC to LC Sub-Carton Depth (mm) 221 Sub-Carton Height (mm) 57 Sub-Carton Width (mm) 223 Sub-Carton Quantity 10 Sub-Carton Weight (g) 322 Connector 1 LC Duplex Fiber Connector 1 (Quantity) 1 Connector 2 LC Duplex Fiber Connector 2 (Quantity) 1 A+ Not Required Actual Inbox Documents Created None Amazon Merchandising Manager Kathleen Marshall Application Photos Required Artwork Due Date 2023-11-17 Buying Center - AV & Collaboration No Buying Center - Data Center Yes Buying Center - End User Compute No Buying Center - Networking & Edge Yes Comparable SKU Comment No direct comparable SKU from our current line up Comparable SKU 2 Comment This is 1m version, not exact match. But it is the close one. Digital Content Due Date 2024-01-10 Enhanced Gallery Not Required Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Graphic Design SKU Logic Naming Convention SMDOS2LCLCxM Launch Markets (concatenated) AT,AU,BE,CA,CH,DE,DK,ES,FI,FR,IE,IT,JP,MX,NL,NZ,SE,UK,US Product Development Specialist Sam Bushell Product Information Creation Specialist (PICS) Brian Chan Product Manager Tim North Product Performance Specialist Ray Aoki Product Photographer Caleigh Le Grand Target Development Completion Date 2023-11-10 Target Production Release 2023-11-17 Tech Lead Justin Weaver Technical Writer Brian Chan Technology Lifecycle Mainstream Video Not Required
