SP123DP2DVI
DisplayPort to DVI Extender Expansion Adapter
DisplayPort graphics expansion module mirrors or expands your desktop across three DVI monitors
Main Image
Product Images
Product Images
Product Images
Product Images
Product Name DisplayPort to DVI Extender Expansion Adapter Product Number SP123DP2DVI UPC 065030839549 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan Malaysia Country of Origin North America Malaysia Product Title (Short) DisplayPort to DVI Multi Monitor Adapter Product Title (Standard) Triple Head DisplayPort to DVI Multi Monitor Adapter Product Title (Long) Triple Head DisplayPort to DVI Multi Monitor Adapter Title Ingram (Part 1) TripleHead DisplayPort to DVI Mu Title Ingram (Part 2) lti Monitor Adapter Website Product Headline DisplayPort graphics expansion module mirrors or expands your desktop across three DVI monitors Bullet 1 Easy to use and works with any operating system Bullet 2 Expand your desktop or clone primary display Bullet 3 Supports resolutions up to 3840x1024 when connected to three displays Bullet 4 External adapter allows use with desktops or notebooks Bullet 5 Supports connection to HDMI monitors using DVI to HDMI adapters (sold separately) Marketing Copy Applications - Increase the maximum resolution that you can output from your video card; add and combine up to three displays at a maximum resolution of 3840x1024
- Use as a video wall for digital signage applications requiring wide screen or panoramic displays
- Clone your primary display and use the SP123DP2DVI as a three port DisplayPort video splitter
- Run multiple applications on separate monitors - edit images, video, audio clips across three displays
Website Search Keyword - Expand desktop
- DisplayPort Desktop Extender
- DVI Display Expander
- Triple Monitor
- DualHead2GO
- External DisplayPort Video Card
- External Multi-Display
- Matrox
- DisplayPort DVI
- Multi-Display DisplayPort
- TripleHead2GO
- DisplayPort Expansion
- DVI Expansion
- DisplayPort to 3 DVI
- DisplayPort to Three DVI
- Graphics Expansion
- GXM
- Graphics expansion module
- Monitor Spanner
- Video Spanner
- DisplayPort Spanner
- Span video
- Dual Triple DP to DVI 3 DVI
Special Notes Maximum Resolution is dependent on video card capabilities. A video card capable of outputting a maximum resolution of 3840x1024 from one DisplayPort port will power three monitors at 1280x1024. Color Silver Material Plastic Product Length (mm) 171 Product Width (mm) 109 Product Height (mm) 38 Product Weight (g) 280 TAA Compliant No Audio Specifications DVI - No Audio Support Maximum Cable Distance To Display 15200 Maximum Digital Resolutions Wide Screen Supported Yes Audio No AV Input DisplayPort - 1.2 AV Output DVI-I (Digital Only) - Single-Link Converter Type Passive Carton Depth (mm) 413 Carton Height (mm) 475 Carton Quantity 20 Carton Weight Gross (g) 10500 Included in Package - 1 - 3 Port DisplayPort Spanner / Splitter
- 1 - Instruction Manual
Package Depth (mm) 195 Package Height (mm) 60 Package Width (mm) 200 Package Weight (g) 435 Packaging Description Triple Head DisplayPort to DVI Adapter Packaging Description India Triple Head DisplayPort to DVI Adapter Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 DisplayPort Connector 1 (Quantity) 1 Connector 2 DVI-I Dual-Link (29-Pin) Connector 2 (Quantity) 3 en-US Content Approved Yes Product Manager Eric Roth
