ST1000SPEXD4
2-Port PCIe Gigabit Network Card
Add dual Gigabit Ethernet ports to a client, server or workstation through a PCI Express slot
Main Image
Product Images
Product Images
Product Images
Product Images
Quick-Start Guide
Product Name 2-Port PCIe Gigabit Network Card Product Number ST1000SPEXD4 UPC 065030859356 Lifecycle status Active Warranty 2 Years Taxonomy Product > Cards & Adapters > Network Cards & Adapters Category Level 1 Networking Category Level 2 Desktop and Server Network Cards Category Level 3 Ethernet Cards Family PCIe Gigabit NIC - Realtek Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX072X Product Title (Ultra-Short) 2Pt PCIe Gigabit NIC Product Title (Short) 2 Port Gigabit PCI Express Network Card Product Title (Medium) Dual Port Gigabit PCI Express Server Network Adapter Card - PCIe NIC Product Title (Standard) Dual Port Gigabit PCI Express Server Network Adapter Card - PCIe NIC Product Title (Long) Dual Port Gigabit PCI Express Server Network Adapter Card - PCIe NIC Product Title (AMZ) Dual Port PCIe Network Card - Low Profile - RJ45 Port - Realtek RTL8111H Chipset - Ethernet Network Card - Dual Port Gigabit NIC (ST1000SPEXD4) Title Ingram (Part 1) 2Port 1 Gbps PCIe Ethernet Title Ingram (Part 2) Network Adapter - Dual NIC Website Product Headline Add dual Gigabit Ethernet ports to a client, server or workstation through a PCI Express slot Bullet 1 Two 10/100/1000Mbps compatible RJ-45 Ethernet ports Bullet 2 Compatible with PCI Express Base Specification 2.0 (backward compatible with 1.0a/1.1) Bullet 3 Fully Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, and supports IEEE 802.1Q VLAN tagging, IEEE 802.1P Layer 2 Priority Encoding and IEEE 802.3x Full Duplex Flow Control Bullet 4 Supports Microsoft NDIS5 Checksum Offload (IP, TCP, UDP) and Large send Offload Bullet 5 Wake-on-LAN / Remote Wake-up support Bullets (Compact) Add dual Gigabit Ethernet ports to a client, server or workstation through a PCI Express slot - Dual Port Gigabit PCI Express Server Network Card - PCIe Gigabit NIC - 2 Port 1 Gbps Dual Port Server Adapter Card - PCIe Dual NIC - Dual-Homed NIC Bullets (Consolidated) Add dual Gigabit Ethernet ports to a client server or workstation through a PCI Express slot - Dual Port Gigabit PCI Expres Server Network Adapter - 1 Gbps Dual Port Network Card - PCIe Gigabit NIC - 2 Port Ethernet Card - PCIe Dual NIC - Dual-Homed NIC - Up to 9K Jumbo Frame support - Wake-on-LAN (WoL)/Remote Wake-up support Marketing Copy Marketing Copy (No HTML) Applications - Ideal for VM environments with multiple operating systems, requiring shared or dedicated NICs
- Provide redundant connectivity to ensure an uninterrupted network connection
- Configure a dual-homed proxy or gateway system for an added layer of security
- Specially designed for desktop PC clients, servers, and workstations with few PCI Express slots available
Website Search Keyword - Dual NIC
- 2 Port NIC
- Dual Port Network Card
- Dual Port NIC
- Dual Network Card
- 2 Port Network Card
- ST1000SPEXD3
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device + accessories
System and Cable Requirements Available PCI Express slot Accessory Products - C6PATCH6BK
- C6PATCH10BL
- C6PATCH15BL
- M45PATCH6BK
- M45PATCH6BL
- M45PATCH10BK
- M45PATCH10BL
Related Products - ST1000SPEX42
- ST2000PEXPSE
- EC2000S
- PEX100S
- ST1000BT32
- EC1000BT
- ST1000SPEX
- ST1000SPEXD3
Constrained SKU Alternatives (Limited Stock) ST2000SPEXI Input Voltage 12V DC Output Voltage (V) 12V DC Color Green Humidity 10~90% RH Material Steel Operating Temperature 0°C to 70°C (32°F to 158°F) Primary Material Steel Product Length (mm) 92.600 Product Width (mm) 18.000 Product Height (mm) 120.000 Product Weight (g) 53.000 Storage Temperature 0°C to 100°C (32°F to 212°F) TAA Compliant No Auto MDIX Yes Compatible Networks 10/100/1000 Mbps Full Duplex Support Yes Jumbo Frame Support 9K max. Maximum Data Transfer Rate 2000 Mbps (full-duplex), 1000 Mbps (half-duplex) OS Compatibility - Windows 8
- Windows Server 2012
- Mac OS X Mavericks (10.9)
- Linux
- Windows 7
- Windows 10
- Windows Server 2016
- Windows Server 2019
- Windows 11
Promiscuous Mode Yes Supported Protocols IEEE 802.1Q VLAN tagging, IEEE 802.1P Layer 2 Priority Encoding and IEEE 802.3x Full Duplex Flow Control Wake-On-LAN (WOL) Yes Bus Type PCI Express Card Type Standard Profile (LP bracket incl.) Chipset ID Industry Standards - IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
- PCI Express Base Specification 2.0
Interface/Bridge RJ45 (Gigabit Ethernet) IO Card Port Style Integrated on Card LED Indicators - 2 - Yellow - Gigabit Mode
- 2 - Green - Link/Activity
Carton Depth (mm) 270 Carton Height (mm) 368 Carton Quantity 50 Carton Weight Gross (g) 7508 Included in Package - 1 - PCIe Network Card
- 1 - Low Profile Bracket
- 1 - Instruction Manual
Included In Package for Label - 1 - PCIe Network Card
- 1 - Low Profile Bracket
- 1 - Instruction Manual
Package Depth (mm) 142 Package Height (mm) 32 Package Width (mm) 172 Package Quantity 1 Package Weight (g) 136 Packaging Description 2 Port PCIe Gigabit Network Card Packaging Description India 2-Port PCIe Gigabit Network Card Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 PCI Express x1 Connector 1 (Quantity) 1 Connector 2 RJ-45 Connector 2 (Quantity) 2 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2014-07-25 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute No Buying Center - Networking & Edge Yes Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level - 1 Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,CO,DE,DK,ES,EU,FI,FR,HK,IE,IN,IT,JP,MX,NL,NZ,PE,SE,SG,UK,US Primary Technology None Product Development Specialist Ray Aoki Product Information Creation Specialist (PICS) Alex Garcia Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Tech Lead Stefan Tirolese Technical Writer Andrew Richardson Technology Lifecycle None
