ST10GSPEXNB
5 Speed PCIe Network Adapter 10GBase T NBASE T
Add an Ethernet port to a server or workstation, with support for five network speeds: 10G/5G/2.5G/1G/100Mbps
Main Image
Product Images
Product Images
Product Images
Quick-Start Guide
Product Name 5 Speed PCIe Network Adapter 10GBase T NBASE T Product Number ST10GSPEXNB UPC 065030864213 Lifecycle status End of Life Warranty 2 Years Taxonomy Product > Cards & Adapters > Network Cards & Adapters Category Level 1 Networking Category Level 2 Desktop and Server Network Cards Category Level 3 Ethernet Cards Family 10G PCIe Ethernet NICs - Copper Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX076X Product Title (Ultra-Short) 5-Speed Network Card Product Title (Short) 10GBase-T NBASE-T Ethernet Network Card Product Title (Medium) 1-Port PCIe 10GBase-T / NBASE-T Ethernet Network Card w/ 5-Speed Network Support Product Title (Standard) 1 Port PCI Express 10GBase-T / NBASE-T Ethernet Network Card - 5-Speed Network Support: 10G/5G/2.5G/1G/100Mbps - PCIe 2.0 x4 Product Title (Long) 1-Port PCIe 10GBase-T / NBASE-T Ethernet Network Card Product Title (AMZ) 1 Port PCI Express 10GBase-T / NBASE-T Ethernet Network Card - 5-Speed Network Support: 10G/5G/2.5G/1G/100Mbps - PCIe 2.0 x4 (ST10GSPEXNB) Title Ingram (Part 1) 5-Speed PCIe Network Adapter - Title Ingram (Part 2) 10GBase-T / NBase-T Compliant Website Product Headline Add an Ethernet port to a server or workstation, with support for five network speeds: 10G/5G/2.5G/1G/100Mbps Bullet 1 Cost-effective and versatile Ethernet connectivity supporting five network speeds: 10G, 5G, 2.5G 1G and 100Mbps Bullet 2 Compliant with 10GBase-T and NBASE-T specifications Bullet 3 PCIe 2.0 x4 interface Bullet 4 Supports 2.5 and 5Gbps network speeds on Cat5e cabling, and 10Gbps on Cat6a Bullet 5 Up to 9K jumbo frame support Bullets (Compact) Add an Ethernet port to a server or workstation, with support for 5 network speeds: 10G/5G/2.5G/1G/100Mbps - 1-Port PCI Express 10GBase-T / NBASE-T Ethernet Network Card - 5-speed network adapter with PCIe 2.0 x4 interface - 10GBase-T & NBASE-T NIC Bullets (Consolidated) Replacement ST10GSPEXNB2 available - Add an Ethernet port to a server or workstation with support for 5 network speeds: 10G/5G/2.5G/1G/100Mbps - 1-Port PCI Express 10GBase-T/NBASE-T Ethernet Network Card - 5-speed network adapter card w/ PCIe 2.0 x4 - 10GBase-T and NBASE-T NIC - 1 port PCIe network adapter card - 10G PCIe NIC - 10G over copper network card - Supports 2.5 and 5Gbps network speeds on Cat5e cabling/10Gbps on Cat6a cables - Tehuti TN4010 controller / Marvell 88X3310P transceiver Marketing Copy Marketing Copy (No HTML) Applications - A cost-effective way to add an Ethernet port to your server or desktop computer, with 5-speed network access
- The controller card utilizes advanced NBASE-T technology, enabling multigigabit connections over your existing Cat5e cabling
- Supports the latest multigigabit technology including new Cisco campus switches and Aruba Networks access points
Website Search Keyword - 5-Speed Network Adapter
- 5-Speed PCIe Network Adapter
- 10GBase-T / NBase-T Network Adapter
- PCIe NIC
- 1-port Network Adapter
- 1 port PCIe network adapter card
- 10G PCIe nic
- 1 port PCIe network card
- 100M/1G/2.5G/5G/10G Network Adapter Card
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
System and Cable Requirements Available PCI Express x4 slot Accessory Products - C6ASPAT3BL
- C6ASPAT3GR
- C6ASPAT10BL
- C6ASPAT10GR
- N6PATCH3BK
- N6PATCH5BL
- N6PATCH5BK
- N6PATCH10BK
- N6PATCH15BL
- 45PATCH10BK
- 45PATCH3BK
- 45PATCH6BK
- RJ45PATCH15
Related Products - ST2000SPEXI
- PEX1000SFP
- ST1000SPEX2
- ST10000SPEX
- PEX10000SFP
- ST1000SPEXI
Constrained SKU Alternatives (Limited Stock) ST10000SPEXI Color Black Humidity 20% ~ 80% RH Material Steel Operating Temperature 5°C to 50°C (41°F to 122°F) Primary Material Steel Product Length (mm) 83.000 Product Width (mm) 120.000 Product Height (mm) 21.000 Product Weight (g) 54.000 Storage Temperature -20°C to 60°C (-4°F to 140°F) TAA Compliant No Auto MDIX Yes Compatible Networks 10 Gbps/5G/2.5G/1G/100 Mbps Full Duplex Support Yes Jumbo Frame Support 9K max. Maximum Data Transfer Rate 10 Gbps OS Compatibility - Windows 10
- Windows 8
- Windows 7
- Windows Server 2012
- Linux
- macOS Sierra (10.12)
- Windows Server 2016
- macOS High Sierra (10.13)
- macOS Mojave (10.14)
- Windows Server 2019
- Windows 11
- Windows Server 2022
Promiscuous Mode Yes PXE No Supported Protocols Bus Type PCI Express Card Type Standard Profile (LP bracket incl.) Chipset ID Industry Standards Interface/Bridge RJ45 (10 Gigabit Ethernet) LED Indicators - 1 - Link/Speed
- 1 - Link/Activity
Carton Depth (mm) 312 Carton Height (mm) 364 Carton Quantity 80 Carton Weight Gross (g) 11592 Included in Package - 1 - 1 Port PCIe 5-speed Ethernet network card
- 1 - driver CD
- 1 - low profile mounting bracket
- 1 - instruction manual
Package Depth (mm) 144 Package Height (mm) 30 Package Width (mm) 168 Package Quantity 1 Package Weight (g) 134 Packaging Description 1-Port PCIe 10GBase-T / NBase-T Ethernet Network Card Packaging Description India 1-Port PCIe 10GBase-T / NBase-T Ethernet Network Card Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 PCI Express x4 Connector 1 (Quantity) 1 Connector 2 RJ-45 Connector 2 (Quantity) 1 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2015-11-10 Buying Center - AV & Collaboration No Buying Center - End User Compute No Buying Center - Networking & Edge Yes Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,DE,DK,ES,EU,FR,HK,IE,IT,JP,NL,NZ,SE,UK,US Primary Technology None Product Development Specialist Ray Aoki Product Information Creation Specialist (PICS) Alex Garcia Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Target Production Release 2016-03-11 Tech Lead Stefan Tirolese Technical Writer Andrew Richardson Technology Lifecycle None
