ST121UTPSAEU
VGA over Cat5 Video Extender Kit with Audio - RS232 and IR Control
Extend a VGA Signal with Accompanying Audio over Standard UTP/STP Cabling - Includes RS232 and IR Interfaces
Main Image
Product Images
Product Images
Product Name VGA over Cat5 Video Extender Kit with Audio - RS232 and IR Control Product Number ST121UTPSAEU UPC 065030845229 Warranty 3 Years Taxonomy Product > Legacy Discontinued Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) 1 Product Title (Short) VGA over Cat5 Video Extender Kit w/Audio Product Title (Standard) VGA Video Extender over Cat 5 with RS232 Audio and IR Product Title (Long) VGA over Cat5 Video Extender Kit with Audio - RS232 and IR Control Title Ingram (Part 1) VGA over Cat5 Video Extender Kit Title Ingram (Part 2) with Audio - RS232 and IR Website Product Headline Extend a VGA Signal with Accompanying Audio over Standard UTP/STP Cabling - Includes RS232 and IR Interfaces Bullet 1 Extend VGA, Audio, RS232 and IR signals up to 150m (500ft) Bullet 2 Supports resolutions up to 1920x1200 Bullet 3 Durable steel enclosure Bullet 4 Plug and play - No software/drivers required Bullet 5 Serial interface for instant data transfer or Touch Screen function Marketing Copy Applications - Place the display in a convenient viewing area, while the system equipment is placed elsewhere in a clean and secure environment
- Use digital signage to catch the attention of your audience and deliver up to date content the way you want it to be seen and heard
- Perfect for video conferencing solutions in boardrooms and office settings
- Optimize placement of your demo stations at trade-shows and in auditoriums
- Extend serial data communications or touch-screen functionality using the integrated RS232 port
Website Search Keyword - Video Extension
- VGA Extension
- VGA over Cat5
- VGA over Cat 5
- vga and audio extender
- Digital Signage
- Point to Point
- Transmitter and Receiver Kit
Accessory Products - MXT101HQ
- MXT101MMHQ
- MXT105HQ
- RJ45PATCH100
- RJ45PATCH50
Related Products - ST122UTPAL
- ST121UTPMINI
- STUTPWALL
- ST124UTPE
- ST121UTP
- ST1214T
- ST1218T
- ST121R
- ST121UTP232
Input Current 0.4A Input Voltage 110V-240V AC Output Current 2A Output Voltage (V) 5 DC Power Source AC Adapter Included Color Black Humidity 0%~80% RH Operating Temperature 0°C to 40°C (32°F to 104°F) Product Length (mm) 104 Product Width (mm) 76 Product Height (mm) 25 Product Weight (g) 304 Storage Temperature -10°C to 60°C (14°F to 140°F) TAA Compliant No Max Distance 150m [492ft] Maximum Analog Resolutions Maximum Data Transfer Rate 115.2Kbps (RS232) Audio Yes Cabling Cat 5 UTP or better Industry Standards EDID LED Indicators 1 - Link Indicator (Red - Power, Blue - Link) Included in Package - 1 - VGA Extender - Transmitter Unit
- 1 - VGA Extender - Receiver Unit
- 2 - Universal Power Adapter (US/UK/EU)
- 1 - Instruction Manual
- 1 - IR Transmitter
- 1 - IR Receiver
Packaging Description VGA Extender over Cat 5 w/ Audio, RS232, IR Packaging Description India VGA Extender over Cat 5 w/ Audio, RS232, IR Connector 1 VGA Connector 1 (Quantity) 1 Connector 2 3.5mm (3 Conductors, TRS) Connector 2 (Quantity) 2 Connector 3 DB-9 Serial Connector 3 (Quantity) 1 Connector 4 RJ-45 Connector 4 (Quantity) 1 Connector 5 VGA Connector 5 (Quantity) 1 Connector 6 3.5mm (3 Conductors, TRS) Connector 6 (Quantity) 2 Connector 7 DB-9 Serial Connector 7 (Quantity) 1 Connector 8 RJ-45 Connector 8 (Quantity) 1 en-US Content Approved Yes
