Main Image
ST122LEU
2/ port 250MHz VGA Video Splitter
Split a VGA signal to 2 VGA monitors or projectors
Main Image
Product Images
Product Images
Product Name 2/ port 250MHz VGA Video Splitter Product Number ST122LEU UPC 065030820110 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX083X Product Title (Short) 2 Port VGA Video Splitter - 250 MHz Product Title (Standard) StarTech.com 2-Port VGA Video Splitter/Distribution Amplifier Product Title (Long) 2 Port VGA Video Splitter - 250 MHz Product Title (AMZ) 2 Port VGA Video Splitter - 250 MHz (ST122LEU) Title Ingram (Part 1) 2 Port VGA Video Splitter - 250 Title Ingram (Part 2) MHz Website Product Headline Split a VGA signal to 2 VGA monitors or projectors Bullet 1 250 MHz video bandwidth Bullet 2 Compatible with VGA, SVGA and Multisync monitors Bullet 3 Supports Cascading up to 3 levels Bullet 4 Supports resolutions up to 1920x1440 Bullet 5 Maximum cable distance 210 feet (65m) Marketing Copy Applications - Use for in-store product merchandising in retail environments to give your advertisements greater visibility
- Display travel schedules and alerts in airports, bus terminals and train stations
- Create engaging multimedia presentations for demonstration in lecture halls and classrooms
- Get your message across multiple displays for trade-shows or information booths/kiosks
- Quick and easy solution to split a video signal in an auditorium or house of worship
Website Search Keyword - 2 Port VGA Splitter
- 2 Port Video Splitter
- Distribution Amplifier
- VGA Splitter
- Video Splitter
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
Accessory Products - MXT101MMHQ10
- MXT101MMHQ25
- MXT101MMHQ50
- MXT101HQ
- SVA5M3NEUA
Related Products - ST124LEU
- ST128LEU
Replacement Product ST122PROEU Input Current 0.5 Output Current 0.5 A Output Voltage (V) 9V DC Power Consumption (In Watts) 4.5 Power Source AC Adapter Included Plug Type M Center Tip Polarity Positive Color Black Humidity 0~90% RH, non-condensing Material Steel Operating Temperature 0°C to 40°C (32°F to 104°F) Product Length (mm) 65.024 Product Width (mm) 131.064 Product Height (mm) 25.908 Product Weight (g) 221.000 Storage Temperature -20°C to 60°C (-4°F to 140°F) TAA Compliant No Bandwidth 250 MHz General Specifications Male to Female VGA extension cable required (MXT101HQ) Maximum Analog Resolutions 1920x1440 Maximum Cable Length (mm) 65000 Carton Depth (mm) 428 Carton Height (mm) 301 Carton Quantity 10 Carton Weight Gross (g) 9600 Included in Package - 1 - 2 Port VGA Splitter
- 1 - Power Adapter
- 1 - User Manual
Package Depth (mm) 81 Package Height (mm) 190 Package Width (mm) 274 Package Quantity 1 Package Weight (g) 840 Packaging Description 2 Port VGA Video Splitter - 250MHz Packaging Description India 2 Port VGA Video Splitter - 250MHz Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 VGA Connector 1 (Quantity) 1 Connector 2 USB-A (480Mbps, 2.5W) Connector 2 (Quantity) 1 Connector 3 VGA Connector 3 (Quantity) 2 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2014-06-18 Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Graphic Designer Shane Arnett Primary Technology None Product Information Creation Specialist (PICS) Dan Dagenais Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Tech Lead Justin Weaver Technical Writer Andrew Richardson Technology Lifecycle Legacy Vending Machine Not Compatible with Vending Machine
