ST122PROGB
2 Port High Res. 350 MHz Video Splitter
Split a single high resolution VGA video signal to 2 monitors or projectors
Main Image
Product Images
Product Images
Product Images
Product Name 2 Port High Res. 350 MHz Video Splitter Product Number ST122PROGB UPC 065030800259 Lifecycle status End of Life Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 Video Display Connectivity Category Level 2 Video Splitters Category Level 3 VGA Splitters Family VGA Splitter Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX066X Product Title (Short) 2 Port High Res VGA Video Splitter Product Title (Standard) StarTech.com 2 Port High Resolution VGA Video Splitter - 350 MHz Product Title (Long) 2 Port High Resolution VGA Video Splitter - 350 MHz Product Title (AMZ) 2 Port High Resolution VGA Video Splitter - 350 MHz - Video splitter - 2 ports (ST122PROGB) Title Ingram (Part 1) 2 Port High Resolution VGA Video Title Ingram (Part 2) Splitter - 350 MHz Website Product Headline Split a single high resolution VGA video signal to 2 monitors or projectors Bullet 1 Allows 1 VGA video source to simultaneously display on 2 different monitors Bullet 2 Supports resolutions up to 2048x1536 @ 80Hz Bullet 3 High video bandwidth (350 MHz) Bullet 4 Maximum VGA cable length of 210ft (65m) Bullet 5 Built-in video amplifier boosts the signal to allow a cable length of up to 210 ft or 65m Marketing Copy Applications - Create engaging multimedia presentations for demonstration in lecture halls and classrooms
- Display travel schedules and alerts in airports, bus terminals and train stations etc.
- Create eye-catching displays in trade-shows and auditoriums
- Use for in-store product merchandising in retail environments to give your advertisements greater visibility
- Get your message across multiple displays for trade-shows or information booths/kiosks
- Quick and easy solution to split a video signal in an auditorium or house of worship
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class A Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
Accessory Products - MXT101HQ
- MXT101HQ_100
- MXT101HQ_150
- MXT101HQ_200
- MXT101HQ_25
- MXT101HQ_50
- MXT105HQ
- SVA5N3NEUA
Related Products - ST124PRO
- ST122
- ST124
- ST128
- ST128PRO
- ST122LGB
- ST122WGB
Input Current 0.3 A Input Voltage 100 - 240 AC Output Current 1 A Output Voltage (V) 5 DC Power Consumption (In Watts) 5 Power Source AC Adapter Included Plug Type N Center Tip Polarity Positive Color Black Humidity 0~80% RH non-condensing Material Steel Operating Temperature 5°C to 40°C (41°F to 104°F) Primary Material Steel Product Length (mm) 182 Product Width (mm) 80 Product Height (mm) 21 Product Weight (g) 960 TAA Compliant Yes Bandwidth (-3db): 350 MHz General Specifications Male to Female VGA extension cable required (MXT101HQ) Maximum Analog Resolutions 2048x1536 @ 80Hz Maximum Cable Length (mm) 65000 MTBF (hours) 1,588,136 Hours Audio No Industry Standards DDC compatible - all other monitors must be able to support the highest video resolution of the DDC-type monitor connected to Video Out 1 Regulatory Approvals FCC Part 15 Class A, CE Mark Carton Depth (mm) 404 Carton Height (mm) 322 Carton Quantity 12 Carton Weight Gross (g) 9486 Included in Package - 1 - 2 Port High Res. Video Splitter
- 1 - Power Adapter
- 4 - Rubber Feet
- 1 - Instruction Manual
Package Depth (mm) 186 Package Height (mm) 96 Package Width (mm) 240 Package Quantity 1 Package Weight (g) 682 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 VGA Connector 1 (Quantity) 2 Connector 2 VGA Connector 2 (Quantity) 1 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2014-06-18 Buying Center - AV & Collaboration Yes Buying Center - End User Compute No Buying Center - Networking & Edge No Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) EU,IE,UK Primary Technology None Product Information Creation Specialist (PICS) Dan Dagenais Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Tech Lead Justin Weaver Technical Writer Andrew Richardson Technology Lifecycle None
