Main Image
ST124DVI
Main Image
Product Images
Product Images
Product Images
Product Images
Product Name 4 Port DVI Video Splitter/Dist Amplifier Product Number ST124DVI UPC 065030800129 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX011X Product Title (Short) 4 Port DVI-I Video Splitter Product Title (Standard) StarTech.com 2 Port DVI Video Splitter - Video splitter - 4 ports Product Title (Long) 4 Port DVI-I Video Splitter - Digital and Analog Title Ingram (Part 1) 4 Port DVI-I Video Splitter and Title Ingram (Part 2) Signal Amplifier Bullet 1 Supports resolutions of up to 1600 x 1200 pixels @ 60 Hz Bullet 2 Accurate and reliable reproduction of digital video signal, with no signal attenuation or distortion Bullet 3 Fully compliant with the DVI 1.0 standard established by the DDWG Bullet 4 Simple setup for quick connection in minutes Marketing Copy Applications - Connect DVI enabled projectors, monitors, plasma screens, commercial billboards, and wall display systems
- Ideal for graphic design, classroom use and training seminars
- Great for use in tradeshow, POS, healthcare, airport, train station and bus terminal settings
Website Search Keyword DA Accessory Products - DVIDSMF10
- DVIDSMF15
- DVIDSMF6
- DVIDSMM10
- DVIDSMM15
- DVIDSMM20
- DVIMM6
- DVIAEXT10
- DVIAEXT20
- DVIAEXT30
- DVIAEXT50
- DVIAEXT70
- DVIAEXT100
Related Products ST122DVI Replacement Product ST124DVIA Input Current 1.5 Input Voltage 7.5 Color Gray Product Length (mm) 268 Product Width (mm) 105 Product Height (mm) 42 Product Weight (g) 1240 TAA Compliant No General Specifications - Video Bandwidth: 25 ~ 165 MHz (VGA ~ UXGA)
- Max Resolution: 1600 x 1200 @ 60Hz
- Input Connector: 1 x 24-pin DVI-I
- Output Connector: 2 x 24-pin DVI-I
- LED Indicators: 1 x Power
- Power Adapter: 7.5V DC (1.5A)
- Length: 10.5 Inches (268 mm)
- Width: 4.25 Inches (105 mm)
- Height: 1.65 Inches (42 mm)
- Weight: 2.6 lbs (1.24 kg)
- Industry Standards: DVI 1.0
- Cable Distance - Source to Display: Max of 33ft (10m)
- : Note that this product is not intended for use with widescreen displays.
Maximum Analog Resolutions 1600x1200 Carton Depth (mm) 370 Carton Height (mm) 474 Carton Quantity 15 Carton Weight Gross (g) 20400 Package Depth (mm) 65 Package Height (mm) 222 Package Width (mm) 302 Package Weight (g) 1920 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 DVI-I Dual-Link (29-Pin) Connector 1 (Quantity) 3 en-US Content Approved Yes Product Manager Eric Roth
